Replacement Part List

Green-Power America,LLC
GPG3500iE Parts List
Ref.No. Parts No. Factory Parts No. DESCRIPTION Qty Price（$）
Comments
1-1
GPG3500iE-1-1 QL3000i-JY201506001
tapping screw
6
1-2
GPG3500iE-1-2 QL3000i-JY201506002
cross screw M4X14
8
1-3
GPG3500iE-1-3 QL3000i-JY201506003
cross screw M4X16
1
1-4
GPG3500iE-1-4 QL3000i-JY201506004
pilot light
3
1-5
GPG3500iE-1-5 QL3000i-JY201506005 EU socket 2
1-6
GPG3500iE-1-6 QL3000i-JY201506006 DC socket 1
1-7
GPG3500iE-1-7 QL3000i-JY201506007 smart switch 1
1-8
GPG3500iE-1-8 QL3000i-JY201506008 fuel switch rod 1
1-9
GPG3500iE-1-9 QL3000i-JY201506009 earth point 1
1-10
GPG3500iE-1-10 QL3000i-JY201506010 electric lock 1
1-11
GPG3500iE-1-11 QL3000i-JY201506011 panel 1
1-12
GPG3500iE-1-12 QL3000i-JY201506012 M4 nut 8
1-13
GPG3500iE-1-13 QL3000i-JY201506013 DC protector 1
1-14
GPG3500iE-1-14 QL3000i-JY201506014 side cover 2
1-15
GPG3500iE-1-15 QL3000i-JY201506015 M4 tapping screw 8
1-16
GPG3500iE-1-16 QL3000i-JY201506016 fuel switch 1
1-17
GPG3500iE-1-17 QL3000i-JY201506017 fuel pipe 2
1-18
GPG3500iE-1-18 QL3000i-JY201506018 cross screw M5X20 1
1-19
GPG3500iE-1-19 QL3000i-JY201506019 panel housing 1
1-20
GPG3500iE-1-20 QL3000i-JY201506020 cross screw M6X30 4
1-21
GPG3500iE-1-21 QL3000i-JY201506021 USB port 1
GPG3500iE Inverter Generator Parts List
FIG.1 Control Panel
20
2
21
USA Market panel
20
-4105/5
