MODEL H8210 10 PIECE AIR HAMMER KIT INSTRUCTION MANUAL COPYRIGHT © AUGUST, 2007 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
����������������������������������������������������������������������� �������������������������������������������������������������� ���������������������������������������������������������������������� �������������������������������������������������������������������� ������������������������ ������������������������������������������������������������������ �������������������������������������������������������������������� ����������������������������������������������������������������� ����������
SAFETY For Your Own Safety Read Instruction Manual Before Operating This Equipment The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words which are intended to convey the level of importance of the safety messages. The progression of symbols is described below. Remember that safety messages by themselves do not eliminate danger and are not a substitute for proper accident prevention measures.
7. AVOID ENTANGLEMENTS. Do not wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry, which may get caught in moving parts, when operating this tool. Wear a protective hair covering to contain long hair. 8. USE CORRECT AIR PRESSURE. Exceeding the maximum PSI rating of this tool may cause unpredictable operation or bursting. 9. DISCONNECT AIR PRESSURE before servicing, changing accessories, or moving to another location. Never leave this tool unattended when connected to air. 10.
INTRODUCTION Foreword Specifications The specifications, details, and photographs in this manual represent the Model H8210 as supplied when the manual was prepared. However, owing to Grizzly’s policy of continuous improvement, changes may be made at any time with no obligation on the part of Grizzly. Bit Size....................................10mm (13/32") Bore Diameter.......................................... 3 /4" Blows Per Minute.......................4,500 BPM Air Consumption.......................
OPERATIONS 3. Insert the bit by bending the retainer spring out of the way of the cylinder bore and slide the bit in as shown in Figure 2. Note: If you have difficultly bending the retainer spring to fit the bit, remove the spring and insert the bit into the spring prior to threading it on the hammer. Read the manual before operation. Become familiar with this tool, its safety instructions, and its operation before beginning any work.
EYE INJURY HAZARD! Wear protective equipment when using this tool. EAR/LUNG INJURY HAZARD! Wear protective equipment when using this tool. ACCIDENTAL START HAZARD! Disconnect before service or tool changes. To use the air hammer: 1. Attach the 1/4" NPT male quick connect fitting to the air inlet plug. AIR PRESSURE HAZARD! Never exceed max PSI rating for tool. 2. Attach the air hammer to an air supply set at 90 PSI. 3. Hold the air hammer securely. 4. Use the trigger to START and STOP the air hammer.
H8210 PARTS LIST �� � �� �� �� �� � �� � �� � � � �� �� � � �� �� �� �� �� �� REF PART # DESCRIPTION REF PART # DESCRIPTION 1 2 3 4 5 6 8 9 10 11 12 13 HANDLE ROLL PIN 3 X 14 O-RING 7.8 X 1.9 P8 O-RING 7.8 X 1.
