Atrio 21 046 Atrio English Français Español .....1 .....2 .....1 .....3 .....2 Design & Quality Engineering GROHE Germany 94.239.131/ÄM 222970/03.
Please pass these instructions on to the end user of the fitting! S.v.
II
English Application Can be used in conjunction with: Pressurized storage heaters, thermally and hydraulically controlled instantaneous heaters. Operation with low-pressure displacement water heaters is not possible. Specifications • Max. flow 5.7 L/min or 1.5 gpm/60 psi • Flow pressure - min. 7.25 psi - recommended 14.5 - 72.5 psi - greater than 72.5 psi, fit with pressure reducing valves • Max. operating pressure 145 psi • Test pressure 232 psi • Temperature - max.
Español Campo de aplicación Es posible el funcionamiento con: acumuladores de presión, calentadores instantáneos con control térmico e hidráulico. ¡No es posible el funcionamiento con acumuladores sin presión (calentadores de agua sin presión)! Datos técnicos • Caudal máx. 5.7 L/min o 1.5 gpm/60 psi • Presión - mín. 7.25 psi - recomendada 14.5 - 72.5 psi - si la presión es superior a 72.5 psi, se deberá instalar una válvula reductora de presión • Presión de utilización máx.
2 1 13mm = 92° *19 017 mm 16 = 360° 3 4 B A C D 17mm III
www.grohe.com Grohe America Inc. 241 Covington Drive Bloomingdale, IL 60108 U.S.A. Technical Services Phone: 630/582-7711 Fax: 630/582-7722 Grohe Canada Inc.
