LCD TV with LED Backlight 55 VLE 9480 SL EN
Contents------------------------------------------------------------------------------------------------------------------------------------4 Setup AND SAFETY 6 6 7 7 7 7 General information Special features of your television set Receiving digital channels Grundig SCR system Important notes on environmental protection Notes on still images 8 8 9 Connection and preparation Connecting the antenna and power cord Inserting batteries into the remote control 10 Overview 10 Connections on the television set
Contents------------------------------------------------------------------------------------------------------------------------------------66 66 66 67 67 68 70 70 70 Convenience functions Opening the SETTINGS menu Language settings Setting the date and time Timer functions Parental control settings Updating software (OAD) Updating software (Online) Restoring the television to the default settings 71 OPERATION USING EXTERNAL DEVICES 71 DIGI LINK 71 The DIGI LINK functions on your television 72 Device ope
Setup AND SAFETY-----------------------------------------------------------------------------------------------------Please note the following instructions when setting up the television set: This television is designed to receive and display video and audio signals. All other uses are expressly prohibited. 7 Make sure the power cord or the power supply unit (if provided) are not damaged. 7 Only operate the television with the power supply/power cord provided.
Setup AND SAFETY-----------------------------------------------------------------------------------------------------Do not connect any other equipment while the device is switched on. Also switch off other equipment before connecting it. 7 Do not plug in the power cord of the device until you have connected the external equipment and the antenna. 7 Make sure the mains plug is freely accessible.
General information--------------------------------------------------------------------------------Special features of your television set You can receive and watch digital TV channels using your television set (via DVB-S, DVB-T and DVB-C) – including High Definition programmes (HD). However, the reception of digital TV channels in HD is currently limited to a few countries in Europe.
General information--------------------------------------------------------------------------------Receiving digital channels You require a satellite antenna to receive digital satellite channels (DVB-S). 7 You require a digital roof antenna or indoor antenna (passive or active indoor antenna with its own power supply) to receive digital television channels (DVB-T).
Connection and preparation----------------------------------------------Connecting the antenna and power cord 2 3 1 1 To receive digital satellite channels (DVB-S), connect the satellite antenna cable to the antenna socket »SATELLITE« on the television set. Note: When connecting an indoor antenna you may have to try it out at different positions until you get the best reception.
Connection and preparation----------------------------------------------Inserting batteries into the remote control Environmental note 7 This symbol on rechargeable batteries/batteries or on the packaging indicates that the rechargeable battery/battery may not be disposed of with regular household rubbish. For certain rechargeable batteries/batteries, this symbol may be supplemented by a chemical symbol.
Overview------------------------------------------------------------------------------------------------------------------------------------Connections on the television set AV1 / S-VHS COMPONENT Y Pb Pr L R Optic Out 10 ENGLISH CART socket (CVBS signal, S RGB signal); Video and sound socket for S-Video camcorder. Sockets for video input (YUV signal). Sockets for audio input (YUV signal). ocket for audio output S (optical) for PCM/Dolby Digital signals.
Overview------------------------------------------------------------------------------------------------------------------------------------HDMI4 HDMI socket, audio/video input. USB2 (HDD) SB socket for external U data media and PVR function; Wireless keyboard, mouse port. LAN etwork cable connection N socket. U eadphone jack (3.5 mm H jack plug); Sockets for audio output. Controls on the television set ON • OFF Power switch, switches the television into standby mode and off.
Overview------------------------------------------------------------------------------------------------------------------------------------The remote control – Main functions Switches on from standby; selects channel – directly. elects the channel list S (»All«, »FAV 1« to »FAV 4«). Switches on and off (Standby). witches between S teletext and TV mode. Opens the 3D menu. Displays information. Opens the main menu. Opens the channel list. Opens the TOOLS menu.
Overview------------------------------------------------------------------------------------------------------------------------------------The remote control – All functions ! F reeze frame, if no external data medium is connected; Playback pause; Time shift mode (only for digital television channels and when an external data medium is connected); pauses the file being played in DLNA menu.
Settings-----------------------------------------------------------------------------------------------------------------------------------------Initial set-up and tuning television channels Selecting language, country and operating mode The television set is equipped with automatic channel search, which searches for satellite channels (DVB-S), terrestrial channels (DVB-T), cable channels (DVB-C) and analogue channels. 1 Switch the television to standby with the power switch »ON • OFF«.
Settings-----------------------------------------------------------------------------------------------------------------------------------------Tuning the television channels from satellite (DVB-S) Advanced installation You have two options for tuning digital satellite channels. 1 In the »Source Setup« menu, in the »Connection Type« line, select the option »Satellite« with »<« or »>«. A The easy installation, which pre-configures all antenna settings for the satellite channels on Astra 19.2° East.
Settings-----------------------------------------------------------------------------------------------------------------------------------------6 Select the line »DISEqC Mode« with »V« or »Λ«. Select »DiSEqC 1.0« or »DiSEqC 1.1« in accordance with the existing antenna system with »<« or »>«. – DiSEqC 1.0 allows up to four satellites to be received simultaneously. – DiSEqC 1.1 allows up to 16 satellites to be received simultaneously. 7 Select the line »LNB Selection« with »V« or »Λ«.
Settings-----------------------------------------------------------------------------------------------------------------------------------------Tuning terrestrial television channels (DVB-T) Tuning television channels from the cable provider (DVB-C) 1 In the »Source Setup« menu, in the »Connection Type« line, select the option »Air« with »<« or »>«. 1 In the »Source Setup« menu, in the »Connection Type« line, select the option »Cable« with »<« or »>«. 2 Select the line »Scan Type« with »V« or »Λ«.
Settings-----------------------------------------------------------------------------------------------------------------------------------------Changing the program table for the digital channels Selecting channel lists Channels which are found using the scan are saved in the »PROGRAM TABLE«. 2 Select the »SOURCE SETUP« menu with »V« or »Λ« and press »OK« to confirm. – The »SOURCE SETUP« menu appears.
Settings-----------------------------------------------------------------------------------------------------------------------------------------Deleting channels in the program table 1 In the »PROGRAM TABLE« menu, select the Edit mode by pressing »« (red). 2 Select the television channel to be deleted with »V«, »Λ«, »<« or »>« and press »« (yellow) to delete. Note: 7 You can delete all channels with »« (blue).
Settings-----------------------------------------------------------------------------------------------------------------------------------------Notes: 7 Channels can also be deleted from the favourites lists. Select the channel to be deleted with »V«, »Λ«, »<« or »>« and press »OK« to delete it. 7 When deleting a channel from the favourites list, the order within the favourites list will be updated. 4 Quit the program table with »MENU«.
Settings-----------------------------------------------------------------------------------------------------------------------------------------Picture settings 1 Open the menu with »MENU«. 2 Select the menu item »PICTURE SETTINGS« with »V« or »Λ« and press »OK« to confirm. – The »PICTURE SETTINGS« menu appears. PICTURE SETTINGS 20.09.
Settings-----------------------------------------------------------------------------------------------------------------------------------------Sound settings Automatic volume 1 Open the menu with »MENU«. Television stations broadcast at different volumes. The automatic volume limiting (AVL) function means the volume is kept the same when you switch between channels. 2 Select the menu item »SOUND SETTINGS« with »V« or »Λ« and press »OK« to confirm. – The »SOUND SETTINGS« menu appears. 20.09.
Settings-----------------------------------------------------------------------------------------------------------------------------------------Stereo width Equalizer This broadens the sound output for stereo programmes and improves the sound with mono reception. Equalizer offers a sound setting ”User” that you can create. 1 Select the line »Audio Mode« with »V« or »Λ«. 2 Select the option »Spatial« with »<« or »>«.
Television - OPERATION-------------------------------------------------------------------------------Basic functions Switching on and off 1 Switch the television to standby with the power switch »ON • OFF«. 2 Press »8«, »1…0« or »P+« or »P-« to switch on the television from standby mode. 3 Press »8« to switch the television to standby. 4 Switch the television to standby with the power switch »ON • OFF«. Selecting channels 1 Press »1…0« to select presets directly.
Television - OPERATION-------------------------------------------------------------------------------Audio settings Zoom function 1 Open the Tools menu with »TOOLS«. This function allows you to enlarge the picture as required. 2 Select the menu item »Sound Preset« with »V« or »Λ«. 3 Select the audio setting by pressing »<« or »>«. – You can change the »User« audio setting – see the “Soundeffects” chapter on page 23.
Television - OPERATION-------------------------------------------------------------------------------Zapping function Electronic TV guide This function remembers the channel you are currently watching while you switch over to other ones (zapping). The electronic TV guide provides an overview of all programmes that will be broadcast in the next week (for digital channels only). 1 Press »1…0« or »P+«, »P–« to select the channel to be stored in the zapping memory and press »<« to confirm.
Television - OPERATION-------------------------------------------------------------------------------Changing the picture format »Panorama« format The television automatically switches to the 16:9 format if this format is detected via the SCART socket. This setting is suitable for films in an especially wide format. 1 Open the Tools menu with »TOOLS«. 2 Select the menu item »Picture Format« with »V« or »Λ« and press »OK« to confirm. 3 Select the picture format with »<« or »>« and press »OK« to confirm.
3D FUNCTION------------------------------------------------------------------------------------------------------------------------Important information about the 3D function 7 7 7 7 7 7 7 7 Keep a sufficient distance from the television. The optimum distance is three times the height of the screen. Watching 3D films from a close distance for a long time could impair your vision. Never use the 3D function for longer than 3 hours without a break.
3D FUNCTION------------------------------------------------------------------------------------------------------------------------Your TV will switch from 3D mode to 2D mode for the following: if the program table or EPG information is displayed, the channel or the source are changed, playback of a 3D film is completed or the next film starts to play in USB or PVR mode. 7 1 Open the »Select Source« menu with » «.
3D FUNCTION------------------------------------------------------------------------------------------------------------------------Adjusting 2D → 3D effects Formats supported by HDMI 1.4 When you change 2D broadcasting to 3D, you can adjust the most suitable effect depending on your personal preferences. With HDMI 1.4, your TV can recognise and play 3D content. 1 Select »Effect mode« with »V« or »Λ« and set it to »On« with »<« or »>«. – »3D Perspective« and »Depth« options are activated.
3D FUNCTION------------------------------------------------------------------------------------------------------------------------Dual Gaming Dual Gaming enables full-screen display of games in the "two-player mode". To do this, both gamers must use the correct Dual Gaming glasses. Notes: Dual Gaming only works with 2D games in the "two-player mode". 3D games are not supported. 7 7 7 7 7 7 To ensure that each player can see the corresponding game view, the correct glasses must be used.
NETWORK INSTALLATION-----------------------------------------------------------------------------To use the functions "GRUNDIG AppLICATION store" and "Operation with Digital Media Server", you must connect the television to your home network with internet access and log on. When you have logged your television onto the home network, it can also be operated remotely from an Apple iPhone or Android smartphone. The options available are dependent on the functions offered by the television.
NETWORK INSTALLATION-----------------------------------------------------------------------------Wired network setting There are two ways of making the wired network settings. A Automatic connection, all data regarding connection settings (»IP Address«, »Netmask«, »Gateway« and »DNS«) are obtained from modem automatically. B Manual connection, all data regarding connection settings (»IP Address«, »Netmask«, »Gateway« and »DNS«) must be configured manually.
NETWORK INSTALLATION-----------------------------------------------------------------------------Manual connection Certain networks require Static IP address. If your network requires a Static IP address, you must enter the »IP Address«, »Netmask«, »Gateway « and »DNS« values manually. You can obtain your »IP Address«, »Netmask«, »Gateway« and »DNS« values from your Internet Service Provider (ISP). 1 Open the menu with »MENU«. 2 Select menu item »INTER@CTIVE TV« with »V« or »Λ« and press »OK« to confirm.
NETWORK INSTALLATION-----------------------------------------------------------------------------Wireless network connection Notes: Wireless LAN adaptor supports IEEE 802.11B/G and N communication protocols. We recommend you to use IEEE 802.11N protocol to obtain the best performance in HD video playback. 7 If you use a modem that supports IEEE 802.11B/G, video playback performance may be poor when compared to a modem that supports IEEE 802.11N since the data transfer rate of IEEE 802.
NETWORK INSTALLATION-----------------------------------------------------------------------------Automatic connection Most of the home networks are Dynamic. If you have a dynamic network, you must use a DSL modem that supports DHCP. Modems and IP sharers that support DHCP obtain the »IP Address«, »Netmask«, »Gateway« and »DNS« values required for internet access automatically, and thus you are not required to enter those values manually. 1 Open the menu with »MENU«.
NETWORK INSTALLATION-----------------------------------------------------------------------------Manual connection Certain networks require Static IP address. If your network requires a Static IP address, you must enter the »IP Address«, »Netmask«, »Gateway« and »DNS« values manually. You can obtain your »IP Address«, »Netmask«, »Gateway« and »DNS« values from your Internet Service Provider (ISP). 1 Open the menu with »MENU«. 2 Select menu item »INTER@CTIVE TV« with »V« or »Λ« and press »OK« to confirm.
SMART Inter@active TV 2.0 FUNCTION-------------------------Smart Inter@active TV 2.0 Applikationen Smart Inter@ctive TV 2.0 provides your television with Internet applications when connected to Internet. Through Smart Inter@ctive TV feature you can run many local and global Internet applications. GRUNDIG AppLICATION store is a depot where you can find various applications that you may use on your Grundig TV. You can download many applications from GRUNDIG AppLICATION store.
SMART Inter@active TV 2.0 FUNCTION-------------------------Navigation and text input during registration Creating a GRUNDIG SMART APPS account 1 Open the menu »Inter@ctive Applications« with »@«. – The registration screen for GRUNDIG AppLICATION store will be displayed. If you are using the function »GRUNDIG appLICATION store« for the first time, you should set up personal access. By registering you receive varied information on the Grundig applications.
SMART Inter@active TV 2.0 FUNCTION-------------------------Log on to GRUNDIG AppLICATION store 6 Enter the location: Enter the data, after entry use »V«, »Λ«, »<« and »>« to select the button »<« and confirm with »OK«. – The message »You are ....« is displayed, registration was successful. If you reset the television to factory settings and have not set the „check mark“ in the field »Save installed applications« during reset, all installed applications will be deleted.
SMART Inter@active TV 2.0 FUNCTION-------------------------Selecting applications GRUNDIG Online Store 1 Select the »Quick Apps« menu with »@«. GRUNDIG online store is an online depot where you can download many applications that you may use on your TV. 2 Press »▯« (red) button to enter the »GRUNDIG appLICATION store« menu. User dd.mm.yyyy hh:mm In the »GRUNDIG appLICATION store« menu, some applications are installed at the factory.
SMART Inter@active TV 2.0 FUNCTION-------------------------2 Select the application you want to download with »V«, »Λ«, »<« and »>« and press »OK« to confirm. – Information on the application will be displayed. 3 Press »« (blue) to download and install the application. – Application will be downloaded and installed. Notes: 7 You can start the application by pressing »« (blue) button. Continue to download applications by pressing »« (red) button.
SMART Inter@active TV 2.0 FUNCTION-------------------------Browser main menu 1 Application gallery. 2 2 Applications. 3 Kategorie der Applikationen. 4 Switch to the Application Store. 1 User dd.mm.yyyy hh:mm My Apps All Apps Social Video News Life 3 HELP AREA 4 Navigating in the main menu 1 Select the desired category with »V« or »Λ« and press »>« to enter application field. 2 Select the required application with »V«, »Λ«, »<« and »>« and press »OK« to confirm.
SMART Inter@active TV 2.0 FUNCTION-------------------------Plugged into Skype Connecting and settings Your TV is Plugged Into SkypeTM. Plugged Into SkypeTM feature allows you to make audio and video calls from SkypeTM to SkypeTM for free anywhere in the world via internet connection.
SMART Inter@active TV 2.0 FUNCTION-------------------------Creating an Skype account 1 Open the menu »Quick Apps« with »@«. 2 Select the »plugged into SkypeTM application with »V«, »Λ«, »<« and »>« and press »OK« to confirm. – Main menu of the application will be displayed after a short while. 8 After entering all log on data, select the »I Agree« button with »V«, »Λ«, »<« and »>« confirm with »OK«. – Registration will be completed and main menu of the application will be displayed after a short while.
SMART Inter@active TV 2.0 FUNCTION-------------------------Creating a Skype contact list Making a call with Skype 1 Open the menu »Quick Apps« with »@«. You can make audio and video calls with different methods. TM 2 Select the »plugged into Skype application with »V«, »Λ«, »<« and »>« and press »OK« to confirm. 3 To create a new contact press »▯▯▯«(yellow). – »Add Account Type« menu will be displayed. 4 Select the option »Skype Contact« with »V« or »Λ« and press »OK« to confirm.
SMART Inter@active TV 2.0 FUNCTION-------------------------Making a call with a phone number Skype Credit or a subscription is required to make a call by phone number. 1 Select the option »Diale« with »V« or »Λ« and press »>« to confirm. – The line »Please input the country code« is activated. 2 Confirm the line »Please input the country code« with »OK«. Select the country code with »V« or »Λ« and press »OK« to confirm. 3 Select the line »Please input the phone with »V« or »Λ« and press »OK« to confirm.
SMART Inter@active TV 2.0 FUNCTION-------------------------Skype options The application BABYWATCH The „History“ option The BABYWATCH application enables you to keep an eye on your children. This section provides information on incoming and outgoing calls. 1 In the »Skype mains menu« select the menu item »History« with »V« or »Λ«and press »>« to confirm. – The »History« will be displayed. 2 Press »<« to backspace to the zum Skype main menu.
MULTI MEDIA SERVER MODE---------------------------------------------------------------------Playing the video, music and image files with home network connection With DLNA menu of your television, you can easily access Video, music and photo files on server; and thanks to DMR feature, you can automatically start and stop media playing on devices with DMC feature. Selecting the Digital Media Server 1 Open the »Select Source« menu with » «. 2 Select »DLNA« with »V«, »Λ«, »<« or »>« and confirm with »OK«.
MULTI MEDIA SERVER MODE---------------------------------------------------------------------7 7 Audio files played through DMS device support following formats that have obtained DLNA certificate: »AAC_ADTS_320«, »LPCM«, »MP3«, »WMABASE« and »WMAFULL«. Image files played through DMS device support following formats that have obtained DLNA certificate: »JPEG_LRG«, »JPEG_MED« and »JPEG_SM«. Start playback 1 Select the content folder on DMS device with »V«, »Λ«, »<« or »>« and confirm with »OK«.
USB RECORDING- ------------------------------------------------------------------------------------------------------------Information on recording and playing television programmes Possible limitations when using an external data medium ■ Recording Depending on the broadcaster, you may experience various restrictions on some of the functions from some television channels. and playback of television programmes is only possible with digital television channels (DVB-S, DVB-T and DVB-C).
USB RECORDING- ------------------------------------------------------------------------------------------------------------Connecting external data media Notes: 7 Before connecting the external data medium it is recommended to switch the television to stand-by mode. 7 Before removing the external data medium, the television must be switched to standby, so that no data loss occurs. Your television features two USB sockets, »USB1« and »USB2 (HDD)«.
USB RECORDING- ------------------------------------------------------------------------------------------------------------Switching on automatic preview If the automatic preview is switched on, a preview of the selected file appears in the file browser. 1 Select the line »Auto Preview« with »V« or »Λ«. 2 Switch on the function with »<« or »>« (»On«). 3 Press »MENU« to end the setting.
USB RECORDING- ------------------------------------------------------------------------------------------------------------″Pausing” time shift programmes You can pause the programme you are watching. This is a useful function, for example if the telephone rings while you are watching a film and you do not want to miss anything. A freeze-frame display of the last scene appears on the screen and the programme is recorded in the time shift memory of the external data medium.
USB RECORDING- ------------------------------------------------------------------------------------------------------------Recording a programme from the channel list 1 Open the »CHANNEL LIST« with »OK«. 2 Select a television channel with »V«, »Λ«, »<« or »>« and press »OK« to confirm. 3 Press »MENU« to exit the channel list. « to start recording. 4 Press » – Information on the recording is displayed: the recording symbol, the channel name, the programme, the recording time and the available memory space.
USB RECORDING- ------------------------------------------------------------------------------------------------------------... by manual data entry You can preset up to 25 programmes for timer recording. 1 Press »GUIDE« to display channel information. – The electronic TV guide appears. 2 Open the »MAKE SCHEDULE« menu by pressing »« (yellow) twice. 3 Select the line »Type« with »V« or »Λ« and select the option »Recording« with »<« or »>«.
USB RECORDING- ------------------------------------------------------------------------------------------------------------Playback The recorded programmes – whether started manually or using the timer function – are stored on the external data medium. You can open the archive on the external data medium by pressing »REC.LIST«. Selecting a programme from the archive 1 Open the »Recorded Event« menu with »REC.LIST«. – The menu appears.
USB OPERATION---------------------------------------------------------------------------------------------------------------File formats Image data Your television can work with the following file formats using the USB sockets: Your television can display pictures in the formats JPEG, PNG and BMP. JPEG stands for Joint Picture Experts Group. It denotes a process for compressing picture files. PNG and BMP are process used to save image data with no, or very little, losses.
USB OPERATION---------------------------------------------------------------------------------------------------------------Connecting external data media Before connecting the external data medium it is recommended to switch the television to stand-by mode. Before removing the external data medium, the television set must be switched to standby, so that no data loss occurs. Notes: 7 The »USB1« socket of the television set supplies a maximum power of 500 mA in accordance with USB specifications.
USB OPERATION---------------------------------------------------------------------------------------------------------------The file browser Settings in the USB setup menu The file browser displays video, audio and picture files stored on external data media. Selecting the menu If an external data medium contains files in different formats, you can, when necessary, filter out the formats not required.
USB OPERATION---------------------------------------------------------------------------------------------------------------DivX® VOD Basic playback functions You must have your device registered in order to play the protected video that you will buy from DivX®. 1 Select the data medium by pressing » «, use »V«, »Λ«, »<« or »>« to select the option »USB« and press »OK« to confirm. – The file browser appears. 1 Select »DivX® VOD« with »V« or »Λ« and confirm with »OK«. – Registration Code appears.
USB OPERATION---------------------------------------------------------------------------------------------------------------Notes: 7 Use »Λ« to select »Up Folder«, when you would like to return to the last folder. Use »Root« (and then press »OK«) to return to the main folder. It is possible that files which are actually supported do not function correctly in USB mode. This is because certain files are not recorded with standardised compression processes, although they feature the “right” file ending.
USB OPERATION---------------------------------------------------------------------------------------------------------------Selecting a track or picture in steps (SKIP) 1 During playback, select the next track/ picture with »6«. 2 During playback, select the previous track/ picture with »5«. – Playback begins with the track or picture you selected. Selecting a certain passage for playback (video files only) 1 During playback, press »OK«.
Teletext OPERATION----------------------------------------------------------------------------------------------Note: If you only want to use this “normal” video text, disable the digital video text, see page 90. 7 TOP text or FLOF text mode 1 Press »TXT« to switch on teletext. 2 Select teletext pages directly with »1...0« or step by step with »V« and »Λ«. Return to teletext page 100 with »?«.
INTERACTIVE PORTAL (HbBTV)--------------------------------------------------------------What is HbbTV? The ARD offering includes, for example, a detailed programme overview, the full offering of "Das Erste Mediathek" as well as graphical restructured teletext with high-definition pictures. The ZDF offering includes the "ZDF mediathek" and other programme information (as of jull 2012). The HBBTV Service is only available in some countries.
Convenience functions------------------------------------------------------------------------Opening the SETTINGS menu Changing the audio language 1 Open the menu with »MENU«. (only for digital television channels) 2 Select the menu item »SETTINGS« menu with »V« or »Λ« and press »OK« to confirm. – The »SETTINGS« menu appears. You can define a primary and a secondary audio language. 20.09.
Convenience functions------------------------------------------------------------------------Setting the date and time Timer functions Automatic setting Entering the switch-off time (sleep timer) Your television set detects the difference in time to Greenwich Mean Time (GMT) automatically, as long as the channel selected transmits a time signal. 1 Select the line »Date & Time« with »V« or »Λ« and press »OK« to confirm. In the »Sleep Timer« menu you can enter a time for the television to switch off.
Convenience functions------------------------------------------------------------------------6 Select the line »Volume« with »V« or »Λ« and use »<« or »>« to set the volume. 7 Select the line »Set Hour« with »V« or »Λ« and enter the time with »1…0«. 8 Save the data with »« (green). Note: 7 You can abort the entry by pressing »« (red). 9 Press »MENU« to end the setting. Switch-off timer In the »Auto Off« menu, you can enter a time for the television to switch off.
Convenience functions------------------------------------------------------------------------Locking keys (Parental lock) Locking television channels When the key lock is activated, the buttons on the television set do not function. You can lock individual television channels, for example channels unsuitable for children, using a personal PIN code. 1 Select the line »Keypad Lock« with »V« or »Λ«. 2 Enter the PIN code »1234« with »1 ... 0«.
Convenience functions------------------------------------------------------------------------Power LED Brightness Updating software (Online) You can adjust the stand-by LED. In stand by mode, the LED is always flashing with reduced brightness. (from the internet, for digital channels only) 1 In the »SETTINGS« menu, select the line »Power LED Brightness« with »V« or »Λ«. 2 Use »<« or »>« to select options »High« or »Low«. 3 Press »MENU« to end the setting.
OPERATION USING EXTERNAL DEVICES-----------------------------DIGI LINK Your television is equipped with the DIGI LINK function. This function uses the CEC (Consumer Electronics Control) protocol. CEC allows external devices which are connected to the »HDMI« sockets by an HDMI cable (e.g. DVD player) to be operated with a remote control. Prerequisite is that the devices connected support CEC. Read the operating manual for the external device to find out how to activate the corresponding function.
OPERATION USING EXTERNAL DEVICES-----------------------------Device operation Switching the device to standby You can decide whether external devices should react to your television's remote control. This option switches the external device to standby. «, use »V«, »Λ«, »<« or »>« to 1 Press » select the preset »HDMI1« to »HDMI4« and press »OK« to confirm. «, use »V«, »Λ«, »<« or »>« to 1 Press » select the preset »HDMI1« to »HDMI4« and press »OK« to confirm. 2 Open the menu with »MENU«.
OPERATION USING EXTERNAL DEVICES-----------------------------High definition HD ready Connect the corresponding input sources (e.g. HDTV receiver or HD-DVD player) to the »HDMI« sockets (for digital HDTV sources). This ensures that you can view digital HDTV programmes, even if they are copy-protected (HDCP High Bandwidth Digital Content Protection), without encountering problems.
OPERATION USING EXTERNAL DEVICES-----------------------------Connecting external devices ... with digital audio/video signals Suitable devices: Digital satellite receivers, Playstation, BluRay player, DVD player/ recorder, set-top box, notebook, PCs. 7 Video signal: Digital video; resolution: standard 576p; HDTV 720p, 1080i, 1080p. 7 Audio signal: digital audio (stereo, multi-channel compression, uncompressed). 7 Presets »HDMI 1«, »HDMI 2«, »HDMI 3« or »HDMI4«.
OPERATION USING EXTERNAL DEVICES-----------------------------... with an analogue TV signal Suitable devices: Digital satellite receiver, DVD player/recorder, set-top box, camera recorder. 7 Video signal: CVBS. 7 Audio signal: stereo, analogue. 7 Preset »AV2«. 7 1 Connect the »Video« socket on the television to the corresponding socket of the external device with an RCA cable (video signal).
OPERATION USING EXTERNAL DEVICES-----------------------------Hi-fi System Connecting digital multi-channel amplifier/AV receiver With this connection, you can playback the audio signal of the television channel via the HDMI cable sur the multi-channel amplifier or the AV receiver.
OPERATION USING EXTERNAL DEVICES-----------------------------Playing the audio signal via the HiFi system 1 Connect the »AUDIO OUT L R« sockets on the television to the corresponding socket of the AV receiver with an RCA cable (digital audio signal). Note: If this function is not activated, the audio signal is transmitted to the HiFi system/AV receiver (connected to »AUDIO OUT L R«). 7 1 Open the menu with »MENU«. 2 Select the menu item »SOUND SETTINGS« with »V« or »Λ« and press »OK« to confirm.
OPERATION AS A PC MONITOR---------------------------------------------------------- Connecting a PC 1 Connect the »PC-IN« socket on the television to the corresponding socket on the PC using a VGA cable (video signal). 2 Connect the »Audio« socket on the television to the corresponding socket on the PC using a suitable cable (audio signal). Note: 7 Adjust your PC to the monitor (for example, picture resolution 1280 x 768, picture frequency 60 Hz). 20.09.
Operation with a Common Interface------------------ What is a Common Interface? Common Interface (CI) is an interface for DVB receivers. 7 Encrypted channels can only be viewed with a CA module suitable for the encryption system and in conjunction with the corresponding smart card. 7 The television set is equipped with a Common Interface slot into which CI modules from various providers can be inserted.
Special settings---------------------------------------------------------------------------------------------------------Searching for digital television channels from a satellite automatically Satellite data changes frequently, new channels are constantly being added. You should therefore perform an automatic search from time to time. This searches all transponders for new channels. 1 Open the menu with »MENU«. 2 Select the menu item »SOURCE SETUP« with »V« or »Λ« and press »OK« to confirm.
Special settings---------------------------------------------------------------------------------------------------------Searching for digital television channels from a satellite manually If you know the parameters of a new television channel, you can also search for it manually. Current transponder data can be found in the teletext, in satellite TV magazines or on the Internet. 1 Open the menu with »MENU«. 2 Select the menu item »SOURCE SETUP« with »V« or »Λ« and press »OK« to confirm.
Special settings---------------------------------------------------------------------------------------------------------» KB Frequency (MHz)«: Enter the user band frequency assigned to the user band with »1...0« buttons. » LNB Selection«: If more than one satellites are used in the current SCR system, select »1/2« to»2/2« for the satellite corresponding to the relevant positions using »<« or »>« buttons. Notes: Use installation equipment supported / suggested by your Multiswitch.
Special settings---------------------------------------------------------------------------------------------------------DiSEqC 1.2 Settings You can adjust the alignment of the satellite antenna to each individual satellite. These settings will be saved so that the antenna can later be easily guided to each saved alignment. 1 Select the line »DiSEqC 1.2 SETTINGS« with »V« or »Λ« and press »OK« to confirm. – The »DiSEqC 1.2 SETTINGS« menu appears. 2 Select the preferred option with »V« or »Λ«.
Special settings---------------------------------------------------------------------------------------------------------Note: 7 You can accelerate the search. To do this, you need information about the frequency and network ID. You are usually able to get this data from your cable operator or find it in forums on the Internet. For example, the frequency 402MHz and network ID 61441 can be entered for Germany.
Special settings---------------------------------------------------------------------------------------------------------Searching for digital terrestrial TV channels automatically 1 Open the menu with »MENU«. 2 Select the menu item »SOURCE SETUP« with »V« or »Λ« and press »OK« to confirm. – The »SOURCE SETUP« menu appears. 3 Select the line »Source« with »V« or »Λ« and press »OK« to confirm. Select the option »Air« with »<«, »>«, »V« or »Λ« and press »OK« to confirm.
Special settings---------------------------------------------------------------------------------------------------------Searching for digital terrestrial TV channels manually Tuning analogue television channels 1 Open the menu with »MENU«. This setting is only necessary if you cannot receive any digital channels and you have not carried out an analogue search during initial setup. The television channels can be set directly or using the scan.
Special settings---------------------------------------------------------------------------------------------------------4 Select the line »Automatic Channel Search« with »V« or »Λ« and press »OK« to confirm. 20.09.2010 15:46 SOURECE SETUP Source Air Automativ Channel Search OK Digital Manual Tuning Tuning the television channels by entering the channel numbers 1 Open the menu with »MENU«. 2 Select the menu item »SOURCE SETUP« with »V« or »Λ« and press »OK« to confirm.
Special settings---------------------------------------------------------------------------------------------------------Note: If you wish to remedy other television channels, repeat steps 4 to 7. 8 Press »MENU« to end the setting. 7 Changing stored analogue channels If channels were stored with the automatic channel search while tuning the television channels, you can delete them. You can also store channels in a different preset, change or enter the name of a channel as well as skip channels.
Special settings---------------------------------------------------------------------------------------------------------Creating lists of favourites Displaying signal information You can select your favourite channels and save them in up to four favourites lists (Fav 1 to Fav 4). (for digital channels only) 1 In the »PROGRAME TABLE« menu, switch over to the list view with »« (yellow). 2 Select the preferred channel with »V« or »Λ«.
Special settings---------------------------------------------------------------------------------------------------------Deactivate and activate HbbTV This option allows switching off HbbTV feature, the hint for HbbTV function shall not be displayed during selecting the channels. 1 Open the menu with »MENU«. 2 Select the menu item »SOURCE SETUP« with »V« or »Λ« and press »OK« to confirm. 3 Select the line »HBB TV« with »V« or »Λ«. 4 Select the option (»Off«) with »<« or »>«.
INFORMATION---------------------------------------------------------------------------------------------------------------------GRUNDIG 55 VLE 9480 SL Product Fiche Energy Efficiency class: A+ Screen size: 140 cm/55 inch Screen (dm²): 83 dm² Operating voltage: 220–240 V,~, 50–60 Hz Power consumption: On mode 86 W Standby <0.
INFORMATION---------------------------------------------------------------------------------------------------------------------Service information for dealers The product complies with the following EU directives and regulations: 2006/95/EC: Directive on the harmonisation of the laws of Member States relating to designed for use within certain voltage limits. 2004/108/EC: Directive relating to electromagnetic compatibility.
INFORMATION---------------------------------------------------------------------------------------------------------------------Network interfaces This product is intended for connection to the ADSL network. Note for the Product Package Packaging materials of your product are recyclable.
INFORMATION---------------------------------------------------------------------------------------------------------------------Troubleshooting If the information provided below does not help, please consult an authorised GRUNDIG dealer. Please bear in mind that malfunctions can also be caused by external devices such as video recorders or satellite receivers.
INFORMATION---------------------------------------------------------------------------------------------------------------------Problem Possible cause Remedy Low image quality (pixel) in WLAN mode Signal is lost based on structural conditions. Place the modem so that the signal to the television is not interrupted. Internet connection speed low. Low Internet speed is a problem that is related with the speed of your subscription or a failure in the Internet infrastructure.
