Technical Specifications

ManualsBrandsGT-Lite ManualsElectrical150W Equivalent COB Daylight LED Light Bulb

WARNINGCAUTION

• When using product, basic precautions should always be followed.

• Read and follow these instructions and observe all warnings.

• Carefully read and understand the information given in this manual

before beginning installation. Failure to do so could lead to electric

shock, fire, or other injuries which could be hazardous or even fatal.

• Save these instructions and warnings.

This product may represent a possible shock or fire hazard if improperly

installed or mounted. Products should be installed following these instructions,

local electrical codes, and the current National Electric Code (NEC).

• The use of socket adapters with this product is discouraged.

• NEVER submerge this product in water!

• Do not use in on hot surfaces.

• Do not use in areas near a gas source.

• It is NOT possible to change the LED light source.

• This light is not intended for use in potentially explosive

environments. This is NOT a vapor proof light.

• This work light is NOT A TOY and is not suitable for use by children.

Assembly & Installation: GT-CB-25A | High Lumen 25W/2,500LM LED Bulb

Complete LED Lighting Solutions

WARNING:

TO AVOID RISK OF ELECTRICAL SHOCK,

SHUT OFF POWER BEFORE

INSTALLING OR SERVICING THIS FIXTURE

• Lumen: 2500 LM

• Watts: 25W

• Luminous Efficacy: 100

• LED Lifespan: 25,000 Hours

• Color temperature (Kelvin): 5000K

• Operating Voltage: AC120-277V 50/60Hz

• Beam Angle: 360°

• CRI: 80

• Base: E26 / Standard Edison Base

• Equivalent: 150W Incandescent

• Damp Rated

• Minimum starting temperature: -10°F (-23°C)

(Temporary flashing may occur during startup in cold temperatures.)

• Suitable for use in temperatures: -10°F to 104°F (-23°C to 40°C)

• Not suitable for use in enclosed fixtures.

7.9”

2.76”

Summary of content (4 pages)

PAGE 1
WARNING: TO AVOID RISK OF ELECTRICAL SHOCK, Complete LED Lighting Solutions SHUT OFF POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE Assembly & Installation: GT-CB-25A | High Lumen 25W/2,500LM LED Bulb 7.9” 2.
PAGE 2
Assembly & Installation: GT-CB-25A | High Lumen 25W/2,500LM LED Bulb ADDITIONAL WARNINGS: • This product is not rated for enclosed fixtures. • DO NOT USE WITH DIMMER. This bulb is not compatible with dimmer switches. (Using this lamp with dimmer of any kind will void the warranty.) • Not compatible with photocell/motion sensors rated less than 150W. • Not compatible with ballasted fixtures. Ballast must be bypassed if present. If unsure how to retrofit MHZ/HPS light fixtures call a qualified electrician.
PAGE 3
Assembly & Installation: GT-CB-25A | High Lumen 25W/2,500LM LED Bulb INSTALLATION INSTRUCTIONS: 1. Before installing the bulb, shut off power supply at the circuit breaker panel to avoid electrical shock. Ballast must be bypassed. It is recommended that surge/lightning protection be installed. 2. Bulb may be mounted with the base up, down, or horizontal. 3. Remove old bulb. 4. Screw in new high lumen LED bulb. 5. Restore power & turn on light switch.
PAGE 4
Assembly & Installation: GT-CB-25A | High Lumen 25W/2,500LM LED Bulb TROUBLESHOOTING GUIDE: Problem Probable Cause Solution Fixture does not turn on. Bad connection. Check wiring connections. Faulty switch. Test switch or replace it. Power is off. Verify power supply is on. Discontinue use immediately. Call customer service at 1-800-865-6799 Circuit breaker trips or fuse blows when light is turned on. Call an electrician. CLEANING INSTRUCTIONS: EYES 1. Turn power OFF. 2.
