3. When moving the rudder stick left or right, the head of FF120 accordingly flies left or right.
4. When moving the elevator stick up or down, the FF120 accordingly flies forward or backward.
[END POINT]
1 AILE 100% / 100% 2 ELEV 100%/ 100% 3 THRO 100%/ 100% 4 RUDD 120%/ 120% 5 GEAR 100%/100%
[REVERSE]
1 AILE NOR 2 ELEV NOR 3 THRO NOR 4 RUDD REV 5 GEAR NOR
2. Advice parameters to RF Module with FUTABA radio controller
Fist, set FUTABA radio controller to Plane Mode, then adjust the radio controller to PPM transmit
format.
FUTABA radio controller
1. XC-IS2 Charger is suitable for 1 or 2 cell (3.7V) Li-ion or li-polymer battery.
Please plug the pin of your battery into the jack of the XC-IS2 Charger. 2.Please plug the pin of your battery into the jack of the USB first and then connect to
the power. Otherwise, the LED may not become red and the voltage may be hight than
3.8V. You need to disconnect the USB power supply and reconnect it. 3. When USB power supply is well connected and battery is charging, the LED will
become red. After your battery is full charged, the LED will not become Green.
6. Instruction for XC-IS2 Charger
7. Steps of flight
7.1 Installation of battery pack
Install the battery to the pack
1. Install the battery pack in the battery compartment
2. Connect the power cable of FF120 to receive signal from transmitter
(1) Please followe this rules: "Open the radio first, connect the Quadcopter FF120
power last". After open the radio power button, please connect the FF120 power in 10S,
the signal indicator light begins flashing, the light will solid after 1-3 seconds, and the
four motor will self-checking rotation, then the receiver has received the signal of the
radio successfully, binding finished. (2) If more than 10 seconds passed before the power cable was connected binding will
fail.When binding fails, disconnect the battery.
1. When moving the aileron stick left or right, the FF120 accordingly flies left or right.
2. When moving the throttle stick up or down, the FF120 accordingly flies up or down.
7.2 Matters needing attention
8.1 Flight in Normal Status
Mode 1 (throttle stick at right hand)
7.3 Trouble shooting a flashing receiver LED after connecting the power cable
8. Flight Control diagram
Possible causes Solutions
Code paring failed The throttle stick of transmitter is not at the lowest position
Turn transmitter off then on and re-connect Ff120
power cable
Pull down the throttle stick to the lowest position and re-code pair
The transmitter battery is low and empty
Replace transmitter battery and re-codepair(re-bind)
The FF120 battery is low and empty
Replace the FF120 battery with a fresh pack and re-code pair
No function in receiver or transmitter
Replace faulty receiver or transmitter and re-code pair
