未标题

1) CCPM mixing control system and collective pitch control system make perfect 3D maneuvers such as rolls, inverted, and swoop

flights.

:-),A<7.4A:+0-41+78<-:

Overall Length: 650 mm Battery: 11.1V 1200mAh Li-Po

Specifications:

Main Rotor Dia. : 630 mm

Tail Rotor Dia. : 136 mm

Main Motor Type: 380 PF Transmitter: WK-2601

All-up Weight: 510g (Battery included)

Gyro: Built-in

Receiver: RX-2601

Servo: weight 8.5g / speed 0.11sec/60Ĩ(4.8V)torque 0.9kg/cm (4.8V) / dimension 22.5X11.5X24mm

User Handbook

Features:

2) The compact structure characterized by metal main frame and metal tail boom makes the helicopter more stable. Easy-to-be

mounted parts like servo are used.

3) 380PF brushed motors as drive are powerful and make you fly with much more enjoyment.

4) The flight time on the saturated Li-Po battery will be up to 6-8 minutes, depending on your flight.

Tail Motor Type: 1627FE33

5) The usage of 2.4G technology is prompter in reaction, more sensitive in operation, and stronger in anti-interference.

Summary of content (7 pages)

PAGE 1
User Handbook Specifications: Main Rotor Dia. : 630 mm Main Motor Type: 380 PF Transmitter: WK-2601 Tail Rotor Dia. : 136 mm Tail Motor Type: 1627FE33 Gyro: Built-in Overall Length: 650 mm Battery: 11.1V 1200mAh Li-Po Receiver: RX-2601 All-up Weight: 510g (Battery included) Servo: weight 8.5g / speed 0.11sec/60Ĩ(4.8V) torque 0.9kg/cm (4.8V) / dimension 22.5X11.
PAGE 2
Contents Introduction 2 Warning 2 Cautions 3 Transmitter Features 3 Receiver Identification 5 Switch Between Model I and Model II 5 Battery Mounting and Adjustment 6 Swashplate Adjustment 6 Exponential Function 6 PIT adjustment and locking 7 Gyro sensitivity and Rudder Mixing adjustment 8 Main Rotor Blade Adjustment 8 Tail Rotor Blade Adjustment 8 Technical Data for Adjustment 9 The Disassembly Steps of Rotor Head 9 The Assembly Steps of Rotor Head 11 Exploded Diagram for 59#
PAGE 3
Introduction Thank you for your purchase of our product. In order to fly your helicopter more easily and conveniently, we kindly recommend you to read carefully the whole user handbook and keep it in a safe way as a reference book for maintenance and adjustment in the future. Warning 1. The HM 59#D is not a toy. It is a complex combination of electronics, mechanics, and aerodynami cs. It requires proper setup and fine adjustment to avoid accident.
PAGE 4
Cautions 1. Because the helicopter is operated by radio control, it is important to make sure you are always using fresh and/ or fully charged batteries. Never allow the batteries to run low, or you could lose control of the helicopter. 2. Do not allow any of the electrical components to get wet. Otherwise electrical damage may occur. 3. You should complete a successful range check of your radio equipment prior to each new day of flying, or prior to the first flight of a new or repaired model. 4.
PAGE 5
6-CH Transmitter Features: (MODE l - EUROPE & AUSTRALIA) Gear 1. The DIP switches are available for various servos. It can perform the flight actions such as ascending, descending, forward, backward, leftward, rightward and so on. PIT limit / Exponential / Rudder mixing (V2) Power indicator 2. 4-channel micro-computer as the encoder; output power: ≤ 10mW; current drain: 50mA; power source: 1.2V X 8 Ni-Cd battery ( 9.6V 600mAh) or 1.5V X 8 AA dry cell battery.
PAGE 6
Receiver Identification Fig. 3 Receiver Identification (Fig. 3): ų 1. ELEV. : Connect to the elevator servo. Ų ű Ű ů Ů ŭ Ŭ 2. AILE. : Connect to the aileron servo. 3. PIT. : Connect to the PIT servo. 4. RUDD. : Connect to the tail servo. 5. THRO. : Connect to the speed controller Ŵ 6. Not used. 7. Main motor signal cable : Connect to the main motor signal cable. 8. Tail motor signal cable : Connect to the tail motor signal cable. 9.
PAGE 7
FCC WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for and radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.
