Owner’s Manual and Installation Instructions Liquid-cooled Recreational Vehicle Generator • Model: 004270-2 QUIETPACT™ 75D This manual should remain with the unit.
INTRODUCTION Thank you for purchasing this model of the QUIETPACT™ product line by Generac Power Systems, Inc. This model is designed and manufactured to supply electrical power for recreational vehicles. ◆ READ THIS MANUAL THOROUGHLY If any portion of this manual is not understood, contact the nearest Generac Authorized Service Dealer for starting, operating, and servicing procedures.
Table of Contents QUIETPACT™ 75D Recreational Vehicle Generator Part I – Owner’s Manual Introduction ......................................Inside Front Cover Read This Manual Thoroughly ....................................IFC Contents ......................................................................IFC Operation and Maintenance ........................................IFC How to Obtain Service..................................................IFC Authorized Service Dealer Locator Number ..............
Safety Rules QUIETPACT™ 75D Recreational Vehicle Generator SAVE THESE INSTRUCTIONS – The manufacturer suggests that these rules for safe operation be copied and posted in potential hazard areas of the recreational vehicle. Safety should be stressed to all operators and potential operators of this equipment. ! ! WARNING: ! The engine exhaust from this product contains chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm.
Safety Rules QUIETPACT™ 75D Recreational Vehicle Generator • When working on this equipment, remain alert at all times. Never work on the equipment when physically or mentally fatigued. • Inspect the generator regularly, and contact the nearest Generac Authorized Service Dealer immediately for parts needing repair or replacement. • Before performing any maintenance on the generator, disconnect its battery cables to prevent accidental startup.
Section 1 – General Information QUIETPACT™ 75D Recreational Vehicle Generator 1.1 GENERATOR IDENTIFICATION Please record the following information from the generator DATA DECAL or information decal, located below the user control panel. 1. Model Number ____________________ 2. Serial Number __________________ 3. kW Rating__________________________ 4. Rated Voltage __________________ Model: 04270-2 QUIETPACT™ 75D 1. 2-Pole, 35-amp Circuit Breaker 2. Hourmeter 3. Oil Fill Opening and Plug 4.
Section 1 – General Information QUIETPACT™ 75D Recreational Vehicle Generator 1.2 GENERATOR APPLICABILITY These generators have been designed and manufactured for supplying electrical power to recreational vehicles. DO NOT modify the generator nor use it for any application other than for what it was designed. If there are any questions pertaining to its application, write or call the factory. Do not use the unit until advised by a competent authority.
Section 1 – General Information QUIETPACT™ 75D Recreational Vehicle Generator ◆ 1.5.2 FUEL CONSUMPTION (GAL/HR) Model QUIETPACT™ 75D (004270-0) No Load 0.28 ◆ 1.5.5 ENGINE Half Load Full Load 0.45 0.78 ◆ 1.5.3 ENGINE OIL REQUIREMENTS Use a high-quality detergent oil with American Petroleum Institute (API) classification “For Service CC.” Detergent oils keep the engine cleaner and reduce carbon deposits.
Section 2 – Operation QUIETPACT™ 75D Recreational Vehicle Generator 2.1 GENERATOR CONTROL PANEL The following features are mounted on the generator control panel (Figure 2.1): Figure 2.1 – Generator Control Panel ◆ 2.1.4 LINE BREAKER The line (i.e., main) breaker protects the generator’s AC output circuit against overload and provides a method of turning OFF the generator’s 120/240-volt AC output to the vehicle circuits. The QUIETPACT™ 75D has two 35-amp breakers. NOTE: Refer to Section 1.
Section 2 – Operation QUIETPACT™ 75D Recreational Vehicle Generator ◆ 2.3.2 ENGINE LUBRICATION Before starting the engine, have the engine crankcase properly serviced with the recommended oil. Refer to Section 1.5.3 and Sections 3.1 and 3.2 for oil servicing procedures and recommendations. ! DANGER ! Any attempt to crank or start the engine before it has been properly serviced it with the recommended oil may result in an engine failure. ◆ 2.3.
Section 2 – Operation QUIETPACT™ 75D Recreational Vehicle Generator 2. If the engine is cold, press the Preheat switch for a maximum of 15 to 30 seconds. 3. While pressing the Preheat switch to crank the engine, hold the engine Start/Stop switch in the START position. When the engine starts, release the switches. If the engine does not start after it has been cranking for 15 seconds, release the Start/Stop switch, wait 15 seconds, and try again.
Section 2 – Operation QUIETPACT™ 75D Recreational Vehicle Generator Figure 2.2 – Engine Protective Devices The voltage regulator also incorporates a “voltage surge protection circuit.” This circuit prevents troublesome surges in the generator AC output voltage. Voltage surge is a common cause of damage to electronic equipment. 2.8 ADDITIONAL INFORMATION ◆ 2.8.1 25-HOUR BREAK-IN PERIOD The first 25 hours of operation is the break-in period for the generator.
Section 3 – Maintenance QUIETPACT™ 75D Recreational Vehicle Generator ◆ 2.8.4 OPERATION IN HIGH GRASS Figure 3.1 – Oil Maintenance Features OR BRUSH Never operate the generator while the vehicle is parked over high grass, weeds, brush, leaves, or other combustible substance. Such materials can ignite and burn from the heat of the exhaust system. The generator exhaust system becomes extremely hot during operation and remains hot for a long time after it has shut down.
Section 3 – Maintenance QUIETPACT™ 75D Recreational Vehicle Generator 9. Remove the dipstick, and wipe it dry with a clean, lint-free cloth. This will be used later to check the oil level. 10. Remove the oil-fill plug, and slowly add the proper type and amount of recommended oil (see Section 1.5.3). Periodically use the dipstick to check the oil level and continue to fill the crankcase until the oil reaches the dipstick “FULL” mark. DO NOT FILL ABOVE THE “FULL” MARK. 11.
Section 3 – Maintenance QUIETPACT™ 75D Recreational Vehicle Generator 3.6 Be sure to reinstall the hex pipe cap tightly to the spark arrestor cleanout pipe. Vibration could cause a loose cap to fall out, resulting in hot engine exhaust being drawn through the centrifugal cooling fan and out beneath the unit. This could result in damage to the generator or in discharge of hot exhaust sparks beneath the unit. Figure 3.
Section 3 – Maintenance QUIETPACT™ 75D Recreational Vehicle Generator DANGER ! Do not open or mutilate the battery. Released electrolyte has been known to be harmful to the skin and eyes, and to be toxic. ! Do not remove the radiator pressure cap while the engine is hot; otherwise, serious burns from boiling liquid or steam could result. ! The electrolyte is a dilute sulfuric acid that is harmful to the skin and eyes. It is electrically conductive and corrosive.
Section 3 – Maintenance QUIETPACT™ 75D Recreational Vehicle Generator 3.12 OUT-OF-SERVICE PROCEDURE ◆ 3.12.1 REMOVAL FROM SERVICE Prepare the generator for storage as follows: 1. Start the engine and let it run until it is thoroughly warmed up (at least five minutes), then shut off the engine. 2. While the engine is still warm from running, drain the oil completely (see Section 3.2). Refill the crankcase with the recommended oil (see Section 1.5.3). 3.
Section 3 – Maintenance QUIETPACT™ 75D Recreational Vehicle Generator 3.13 SERVICE SCHEDULE ATTENTION: It is recommended that all service work be performed by the nearest Generac Authorized Service Dealer. SYSTEM/COMPONENT X = Action R = Replace/Adjust as Needed * = To Be Completed by a Generac Authorized Service Dealer.
PART II – INSTALLATION INSTRUCTIONS DANGER ONLY QUALIFIED ELECTRICIANS OR CONTRACTORS SHOULD ATTEMPT INSTALLATION!!
Safety Rules QUIETPACT™ 75D Recreational Vehicle Generator ! DANGER: For fire safety, installation of a generator into a recreational vehicle must comply strictly with NFPA 70 (latest edition), “National Electrical Code”, Article 551, and NFPA 1192 (latest edition), “Standard for Recreational Vehicles”. In addition, installation must comply with the manufacturer’s instructions and recommendations.
Safety Rules QUIETPACT™ 75D Recreational Vehicle Generator ELECTRICAL HAZARDS FIRE HAZARDS • The generator covered by this manual produces dangerous electrical voltages that can cause fatal electrical shock. Avoid contact with bare wires, terminals, connections, etc., while the unit is running. Ensure all appropriate covers, guards, and barriers are in place before operating the generator. If work must be done around an operating unit, stand on an insulated, dry surface to reduce shock hazard.
Section 1 – General Information QUIETPACT™ 75D Recreational Vehicle Generator 1.1 PURPOSE AND SCOPE OF THE MANUAL These Installation Instructions have been prepared especially for the purpose of familiarizing installers and owners of the applicable equipment with the product's installation requirements. Give serious consideration to all information and instructions in the manual, both for safety and for continued reliable operation of the equipment.
45 [1.77"] F 421 [16.57"] 371 [14.61"] 63 [2.48"] 26 [1.02"] [.94"] 567 [22.32"] OVER SCREWS 2 [1.16"] EXHAUST OUTLET 99 [3.90"] 516.5 [20.33"] 536.3 [21.12"] [11.38"] 3/8-16 UNC MOUNTING HOLES [4 PLCS] BATTERY CONNECTION NEGATIVE (-) BATTERY CONNECTION POSITIVE (+) ] 929 [36.57"] OVER SCREWS FRONT SERVICE DOOR REAR SERVICE PANEL 376.5 [14.82"] HOUR METER COOLANT FILL COO SPARK ARRESTOR CENTER OF GRAVITY 291.5 [11.48"] .
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator 2.1 LOCATION AND SUPPORT ◆ 2.1.1 GENERATOR LOCATION The most desirable location for the generator set is between the vehicle's main frame members. Many recreational vehicles have been factoryequipped with an area for the generator set. Some may even have a generator compartment provided by the vehicle manufacturer.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator ◆ 2.1.4 GENERATOR RESTRAINT Figure 2.3 – Typical Compartment Construction Use four 3/8"-16 hardened steel bolts (Grade 5) to fasten the generator to the supporting frame or the support tubing. These bolts must pass through (a) the generator mounting base, (b) the compartment floor (if a compartment is used), and (c) the supporting framework (Figure 2.2).
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator • Seams and joints of the galvanized steel (whether used as a liner or for the compartment itself) must be lapped and mechanically secured. Such seams may be manufactured, welded, bolted, riveted, or screwed. Manufactured lock seams are shown in Figure 2.4. Installer-constructed compartments typically utilize a standard lap joint. Figure 2.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator Figure 2.5 – Typical Noise Abatement ◆ 2.2.4 COMPARTMENT FLOOR CUTOUTS Provide openings in the generator compartment for the following items (Figure 2.6): • Engine exhaust and cooling air outlets • Generator cooling air inlet and front service door • Four holes for passage of generator mounting bolts. See Section 2.1.4. • Rear service door. DANGER ! Fuel lines and exhaust piping must not penetrate into the vehicle living area.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator 2.3 COOLING AND VENTILATING AIR It is absolutely essential that an adequate flow of air for cooling, ventilation, and engine combustion be supplied to the generator set. Without sufficient airflow, the engine/generator quickly overheats. Such overheating can cause serious operating difficulties and also may cause fire and personal injury.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator Figure 2.10 – Air Inlet Using Ductwork ◆ 2.3.4 TESTING THE INSTALLATION Generac recommends testing the installation to be sure adequate cooling airflow is available to the unit, before placing the unit into service. If the unit shows signs of overheating, enlarge the air openings. Never place a unit into service until absolutely certain that cooling and ventilation is adequate.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator Dirt that enters the fuel system also may cause problems. Lines and piping must be properly installed and tightened to prevent dirt from entering. Diesel fuel must be kept clean. Factory-installed generator fuel system components include (a) a fuel filter, (b) a 12-volt DC electric pump, (c) an injection pump, and (d) interconnecting lines and fittings.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator 2.5 EXHAUST SYSTEM The generator exhaust system must be safely and properly installed. Only approved exhaust system parts must be used. A properly installed exhaust system must be vapor-tight, quiet, and completely safe. DANGER ! ! The generator engine gives off DEADLY carbon monoxide gas through its exhaust system. This dangerous gas, if breathed in sufficient concentrations, can cause unconsciousness or even death.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator • Use exhaust system parts recommended by Generac. Using unapproved exhaust mufflers and exhaust system parts is the responsibility of the person(s) installing such unauthorized parts. • Do not terminate the exhaust system under any opening, window, or vent that can be opened or is not permanently sealed from the vehicle interior. • Exhaust piping must be large enough to prevent excessive back pressure on the generator engine.
Section 2 – Installation ▼ QUIETPACT™ 75D Recreational Vehicle Generator 2.6.3.1 Generator Coversion to 120 Volts Only — Dual Circuits NOTE: Conversion of a QUIETPACT™ generator from "120/240 volt dual voltage" to "120 volts only dual circuits" (or vice-versa) requires rerouting wires within the unit enclosure. It is recommended that this conversion be performed by a Generac Authorized Service Dealer. Figure 2.16 shows the stator power winding connections for 120 volts only - dual circuits.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator ◆ 2.6.4 CONDUIT ◆ 2.6.6 GROUND FAULT CIRCUIT INTERRUPTERS Route the connections between the generator and the junction box through approved, flexible conduit. The following general rules apply: • All wiring, conduit, and interconnections must be installed in compliance with applicable codes, standards, and regulations. • Cut wiring to the required length, and allow extra wire for junction box connections.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator Figure 2.18 – Installation With Isolation Receptacle 2.7 BATTERY INSTALLATION ◆ 2.7.1 RECOMMENDED BATTERY Install a battery that meets the following requirements: • The battery must be a 12-volt, automotive-type storage battery. • Use a battery with minimum ratings of 70 amphours and 360 cold-cranking amps.
Section 2 – Installation QUIETPACT™ 75D Recreational Vehicle Generator ◆ 2.7.4 BATTERY COMPARTMENT Install the generator battery in its own, vented compartment. Place the battery compartment away from any source of heat, sparks, or flame. Provide ventilation openings in the battery compartment. The minimum size of openings should be 2 square inches at the top of the compartment. Mount the battery on a strong, rigid supporting structure, where leaks and spills of battery fluid will not cause damage.
Section 3 – Post-installation Start-up Checks QUIETPACT™ 75D Recreational Vehicle Generator CHECKS 3.1 POST INSTALLATION TESTS The generator set was factory-tested and adjusted. It is not necessary to adjust the unit any further, except under special circumstances. ! 3.2 Do not make any unnecessary adjustments. Factory settings are correct for most applications. When making adjustments, however, be careful to avoid overspeeding the engine.
Section 3 – Post-installation Start-up Checks QUIETPACT™ 75D Recreational Vehicle Generator CHECKS 3.5 INSTALLATION CHECKLIST ◆ LOCATION AND SUPPORT ❑ Generator is properly located. ❑ Generator is properly supported. ❑ Generator is properly restrained. ◆ GENERATOR COMPARTMENT ◆ EXHAUST SYSTEM ❑ Exhaust system complies with all applicable codes. ❑ Exhaust system is properly and safely installed.
Appendix 1 – Troubleshooting QUIETPACT™ 75D Recreational Vehicle Generator TROUBLESHOOTING GUIDE PROBLEM CAUSE CORRECTION The engine will not crank. 1. System control fuse blown 2. Loose corroded or defective battery cables 3. Defective engine Start/Stop switch 4. Defective starter contactor 5. Defective starter motor 6. Low or defective battery 7. Defective engine control board 1. Vehicle fuel shutoff valve closed 2. Out of fuel 3. Defective fuel solenoid (FS) 4. Defective fuel pump (FP) 5.
Appendix 2 – Notes QUIETPACT™ 75D Recreational Vehicle Generator 38 Generac® Power Systems, Inc.
Appendix 2 – Notes QUIETPACT™ 75D Recreational Vehicle Generator Generac® Power Systems, Inc.
Appendix 3 — Electrical Data QUIETPACT™ 75D Recreational Vehicle Generator Electrical Schematic – 120/240 VAC Output– Drawing No. 0D2792-A 40 Generac® Power Systems, Inc.
Appendix 3 — Electrical Data QUIETPACT™ 75D Recreational Vehicle Generator Electrical Schematic – 120/240 VAC Output – Drawing No. 0D2792-A Generac® Power Systems, Inc.
Appendix 3 — Electrical Data QUIETPACT™ 75D Recreational Vehicle Generator Wiring Diagram 120/240 Dual Voltage– Drawing No. - 0D2793-B Part 1 42 Generac® Power Systems, Inc.
Appendix 3 — Electrical Data QUIETPACT™ 75D Recreational Vehicle Generator Wiring Diagram 120 VAC– Drawing No. - 0D2793-B Part 2 Generac® Power Systems, Inc.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator Engine, Alternator Drive and Starter Assembly – Drawing No. 0D2355-C 26 25 27 11 41 39 21 49 22 22 43 26 25 7 42 28 49 46 45 4 21 3 39 23 26 44 24 29 28 32 13 35 18 9 50 6 33 6 34 5 1 21 37 12 17 36 14 30 31 40 38 21 10 9 20 22 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator Base Frame – Drawing No. 0D2357-A ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 PART NO. QTY. DESCRIPTION 0D2126 0D2131 0C5088 0C5644 056326 029451 0C7857 070936E 0C6721 0C6722 042907 022129 022097 Base Frame Weldment Door, Service Rear Door, Service Front Slide Latch Flush Vinyl Trim -Black 180mm Rubber Tape 1/8 x ½" Grommet 1/8 x 13/32 Vibration Mount Gasket, Cleanout Plate, Cleanout HHCS M8-1.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator Enclosure – Drawing No. 0D2358-D 25 12 17 11 24 17 17 2 13 20 34 VIEW "A" 27 10 17 17 1 30 38 32 9 31 26 22 35 8 14 5 15 17 28 21 A 33 29 16 19 2 23 7 17 6 17 36 37 17 4 3 17 ITEM PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator Cooling System – Drawing No. 0D2360-B 18 19 45 44 43 41 21 20 39 14 25 42 47 48 39 14 21 4 41 14 13 14 3 21 40 34 6 49 16 32 42 25 35 27 4 17 2 1 5 12 46 8 7 15 30 34 3 18 9 11 3 10 34 46 29 34 26 34 33 50 28 25 53 37 55 38 23 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator Electrical Enclosure Assembly – Drawing No. 0D2361-E 28 1 27 18 29 2 31 11 31 3 9 25 26 27 16 20 33 28 19 8 25 17 27 13 12 6 26 0 7 28 4 15 11 14 32 5 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator Intake and Exhaust System – Drawing No. 0D2362-C 16 6 22 15 8 24 29 15 22 15 27 21 19 10 1 18 26 2 5 20 15 28 16 9 3 O ENGINE AIR INTAKE 3 4 9 7 11 17 12 15 14 16 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator Fuel and Electrical Systems – Drawing No. 0D2363-D 18 20 TO STATOR 7 TO GROUND 16 22 4 9 23 24 17 29 17 15 TO STARTER MOTOR BOLT 14 16 TO STARTER MOTOR 9 4 TO GLOW PLUGS 16 7 3 2 12 27 21 6 10 11 25 4 19 26 4 5 27 13 25 10 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator Customer Controls Assembly – Drawing No. 0D2364-D 13 15 28 24 23 31 26 2 17 19 18 21 5 14 25 2 7 9 20 22 16 34 26 1 27 22 12 8 30 11 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Camshaft – Drawing No. 075677 ITEM 1 2 3 4 5 6 7 PART NO. QTY. DESCRIPTION 0709390232 0709390233 0709390195 0709390234 0709390235 0709390236 0709390237 CAMSHAFT ASSEMBLY CAMSHAFT GEAR KEY GEAR SPACER BALL BEARING SLIDER 1 1 1 1 3 1 1 52 Generac® Power Systems, Inc. ITEM 8 9 10 11 12 13 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Cylinder Block– Drawing No. 075676 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Cylinder Head – Drawing No. 0D2794 ITEM 1 2 3 4 5 6 7 8 9 10 11 12 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Crankshaft, Piston and Flywheel – Drawing No. 075679-B ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Oil Pump – Drawing No. 075682 ITEM 1 2 3 4 5 6 PART NO. QTY. DESCRIPTION 0709390250 0709390252 0709390251 0709390253 0709390254 0709390255 0709390532 0709390533 0709390258 IDLER GEAR ASSEMBLY SPRING THRUST WASHER ROTOR OIL PUMP COVER 0.10MM SHIM 0.15MM SHIM 0.20MM SHIM 0.50MM SHIM 1 1 1 1 1 AR AR AR AR 56 Generac® Power Systems, Inc. ITEM 7 8 9 10 11 12 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Rocker Arm Assembly – Drawing No. 075683-A ITEM 1 2 3 4 5 6 7 8 9 10 11 12 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Injector Pump – Drawing No. 075686-C ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 PART NO. QTY. DESCRIPTION 0709390316 0709390317 0709390318 0709390319 0709390320 0709390298 0709390321 0709390322 0709390323 0709390324 0709390325 0709390326 0709390327 0709390328 0709390329 0709390330 INJECTOR PUMP ASSEMBLY SHIM-0.2MM SHIM-0.3MM SHIM-0.5MM SHIM-1.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Fuel Supply – Drawing No. 075693-C ITEM PART NO. QTY. DESCRIPTION 1 2 3 4 5 6 7 8 9 10 0709390661 1 069858 1 0C8008 AR 0C8008 250MM 040173 3 0709390378 2 0709390379 1 074808 1 052233 2 039450 2 11 030096 FUEL FILTER SUPPORT FUEL FILTER HOSE, 5/16" SAE 30R7 HOSE, 5/16" SAE 30R7 HOSE CLAMP GASKET BANJO FITTING FUEL BLEED FITTING 1/8" NPT TEE (BRASS) 1/8" NPT x 3/16" 90 DEG.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Timing and Governor – Drawing No. 082067-B ITEM 1 2 3 4 5 6 7 8 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Engine Block – Drawing No. 082961-C 24 23 22 25 18 28 17 15 20 13 19 12 14 14 3 33 30 29 1 14 31 2 ITEM PART NO. QTY.
Appendix 4 — Exploded Views and Parts Lists QUIETPACT™ 75D Recreational Vehicle Generator 1.0 Liter Diesel Water Pump – Drawing No. 082962 ITEM 1 2 3 4 5 6 7 PART NO. QTY. DESCRIPTION 0709390265 0709390266 0709390267 0709390268 0709390269 0709390270 0709390271 WATER PUMP ASSEMBLY PLUG THERMOSTAT SPRING GASKET SET PLATE BOLT 1 1 1 1 3 1 1 62 Generac® Power Systems, Inc. ITEM 8 9 10 11 12 15 PART NO. QTY.
Appendix 5 — Notes QUIETPACT™ 75D Recreational Vehicle Generator Generac® Power Systems, Inc.
Appendix 6 – Warranty QUIETPACT™ 75D Recreational Vehicle Generator FEDERAL AND CALIFORNIA EMISSIONS CONTROL WARRANTY STATEMENT (for non-road Diesel engines rated under 19 kW) YOUR WARRANTY RIGHTS AND OBLIGATIONS The U.S. Environmental Protection Agency (EPA), the California Air Resources Board (CARB), Generac Power Systems, Inc. (GENERAC), and the engine manufacturer for this equipment, Ishikawajima Shibaura Machinery Co., Ltd.
Appendix 6 – Warranty QUIETPACT™ 75D Recreational Vehicle Generator OBLIGATIONS AND RIGHTS OF THE MANUFACTURER AND OWNER The new model year, class of diesel engine, and emission application determination for your engine are identified on the emission control information label affixed to the right-hand side of your engine's timing gear case. The warranty period begins on the date the new equipment is sold to the first retail purchaser.
Appendix 6 – Warranty QUIETPACT™ 75D Recreational Vehicle Generator GENERAC POWER SYSTEMS’ THREE-YEAR LIMITED WARRANTY FOR GUARDIAN RECREATIONAL VEHICLE GENERATORS NOTE: ALL UNITS MUST BE INSTALLED BY GENERAC POWER SYSTEMS AUTHORIZED SERVICE FACILITIES. For a period of 3 (three) years of operation from the date of original sale, Generac Power Systems, Inc.
