User's Manual

1 5
1
2
3
4
DC power input interface
Power switch: Long press to turn on
OLED display: It can display mode, brightness, color temperature,
hue, color purity, scene, period, etc.
Compound knob buttons: Press the button to enter the sub-menu
and parameter adjustment; rotate up and down to select the menu
and adjust the light parameters.
6 7 8 9 1042
GVM-RGB20W
3
Angle fixing knob
Hot shoe lock knob
Light interface
Hot shoe
GVM-RGB20W
Hot Shoe Bracket
Compound
knob buttons
Return
button
Adapter
interface
Battery
Installation
Slot
Cooling
hole
Bracket interface
OLED display
Hot shoe interface
ON/OFF
Adapter Interface
D
C IN
Battery Installation Slot
1
2
4
3
DCIN
5
5
return button: Press to return to the previous menu and exit the
parameter adjustment.
11
Rotate the compound knob to select the mode, and lightly press the
compound knob to enter the mode.
CCT : Adjust the brightness and color temperature through the compound
knob or APP.
SCENE : There are 8 scenes:Lightning, Cop Car, Candle, TV, Bad
Bulb, Party, Disco, Paparazzi , Use the compound knob to select the
scene and adjust the brightness, color temperature, time and other
parameters.
Any mode has brightness adjustment. Rotate the compound knob
to select the desired mode → press the compound knob to enter the
mode → rotate the compound knob to select brightness adjustment
→ lightly press the compound knob to enter brightness adjustment
→ rotate the compound knob to adjust the brightness.
The brightness can be adjusted by APP when connected to APP.
Rotate the compound knob to select CCT mode → press the compound
knob to enter CCT mode → Rotate the compound knob to select color
temperature adjustment → press the compound knob to enter color
The color temperature can be adjusted by APP when connected to APP.
Turn on the video light, open the "GVM LED" APP application on your
phone ( phone needs to turn on Bluetooth), after registering the APP
account and log in, you will enter the Bluetooth search interface →
find the Bluetooth named "BT_LED" and connect → wait for
connection → successful connection Then automatically enter the
APP control interface. At this time, you can control the brightness,
color temperature, hue, color purity, scene light, period and on / off of
the connected video light through the APP.
Rotate the compound knob to select HSI mode → press the compound
knob to enter HSI mode → Rotate the compound knob to select hue
adjustment → press the compound knob to enter hue adjustment →
Rotate the compound knob to adjust the hue.
The HUE can be adjusted by APP when connected to APP.
Rotate the compound knob to select the HSI mode → press the
compound knob to enter the HSI mode → rotate the compound knob
to select the SAT adjustment → press the compound knob to enter
the SAT adjustment → Rotate the compound knob to adjust the
color purity.
TheSAT can be adjusted by APP when connected to APP.
⑥ Adjust the scene mode(SCENCE):
Rotate the compound knob to select SCENE mode → press the
compound knob to enter SCENE mode → rotate the compound knob
to select the desired scene light → press the compound knob to enter
the menu of this scene light → rotate the compound knob to select the
item to be adjusted → press the compound knob to enter this item →
rotate The compound knob can adjust the parameters of this item.
Connect the APP, set scene light mode through the APP.
(Press the return button to return to the previous menu)
If you have forgotten your login password,
enter the email address of the user who
registered for the APP on the login interface
and click "Reset Password" at the bottom
right to reset the login password.
1213
C O N T E N T S
Product introduction Page 1-------------------------------------------
Disclaimers Page 2--------------------------------------------------------
Precautions Page 2-------------------------------------------------------
Product parameter Page 3---------------------------------------------
Product structure analysis Page 4------------------------------------
Installation method Page 5,6,7----------------------------------------
Description of product control keys Page 8-----------------------
Function introduction and instruction for use Page 9,10-------
APP connection and APP control Page 11,12---------------------
Simple faults and troubleshooting Page 12------------------------
Use and preservation Page 13-----------------------------------------
1.
PRECAUTIONS
① Please use the matching power adapter or lithium battery with the same
specification to power the product. Do not use power adapter with
different output voltage parameters.
The product is not waterproof, please use it in rainproof environment.②
The product is not anti-corrosion, therefore do not let the product touch
any corrosive liquid.
③
When using the product, make sure the product is put firmly and prevent
from falling and damage.
④
If the product will not be used for a long time, please switch off the power
to reduce energy loss.
⑤
DISCLAIMERS
Before using this product, please read the instructions carefully and make sure
use the product correctly. If you don’t obey the instructions and warnings, you
maybe cause harm to yourself and the people around, or even damage the
product and other things around.
2. Once you use this product, you are deemed to have read the disclaimer and warning
carefully, understand and acknowledge all the terms and contents of this statement,
and promise to take full responsibility for the use of this product and possible
consequences.
PRODUCT PARAMETER
Brand : GVM
Product Name : Photography lights
Product Type : Photography Fill Light
Product model : GVM-RGB20W
Product material : Plastic
Lamp beads quantity : 162
Color rendering index : ≥97
Color temperature : 2700K~10000K
Hue : RGB 0°~360°
SAT : 0%~100%
Brightness : 3500lux/0.5m, 1100lux/1m
Light adjustment method : Step-less adjustment
Function / Feature : High color rendering index light beads, APP control,
portable, Scene light, RGB light
Power : 20W
Voltage : DC 9V
Power supply mode : DC input&Battery
Power supply : DC 9V/3A
Battery Capacity : NP series battery
Product Weight : 0.4KG
Product Size ( mm ) : 242×106×30
Cooling : Natural heat dissipation
Commodity origin : Huizhou. China
Welcome to "GVM-RGB20W". This product is specially designed for senior
photography enthusiasts. The product is suitable for live / outdoor / studio
photography, and also for YouTube video shooting. The main features of
the product are:
PRODUCT
INTRODUCTION
①
②
Step-less adjustable RGB color and dual color temperature feature, color
range 2700K ~ 10000k, with 162 LED bulbs, which is helpful to restore
and enrich the color of objects and provide you with natural and vivid
shooting effect.
App intelligent control system, which can be controlled by your intelligent
mobile device.
③ With OLED screen display and stable system. Supports 180 ° rotation,
which can effectively control the light, allows you to easily shoot the
desired results at will.
We believe that once using our product correctly, you can make huge progress
when shooting. Before using the product, you are strongly recommended to
read the instructions below carefully.
④ The product can simulate 8 kinds of scene lights: Lightning, Police car,
Candlelight, TV, Bad light bulb, Party, disco, Paparazzi.
PRODUCT
STRUCTURE ANALYSIS
2
3
INSTALLATION
METHOD
1
The s teps o f hot shoe brac ket in s tallati on are show n in t he
figure belo w.
4
There are two power supply modes to choose.
② Insert a suitable lithium battery and use a battery power supply.
Install it on the camera as shown below.
Loosen the angle locking knob of the hot shoe bracket, adjust it
to the proper angle, and tighten the knob.
① Connect the adapter for power supply.
DESCRIPTION OF
PRODUCT CONTROL KEYS
USE AND
PRESERVATION
Do not put the product in a highly humid, strong electromagnetic field,
direct sunlight, high-temperature environment. If not use the product for a
long time, disconnect the power and take out the battery.
Clean：Before clean, disconnect the power plug. And use wet cloth rather than any
detergent or soluble liquid, avoiding damaging the surface layer.
Repairing：If there is fault or performance degradation, do not unpack the shell by
yourself, avoiding damage the machine and lose the right of maintenance. When there
is a fault, do not hesitate to contact us, and we will do our best to deal with the problem.
Accessories：Please use the accessories provided by manufacturer and approved
ones, in order to maximize the performance.
Guarantee：Do does not modify the product, or you will lose the right of maintenance.
Clean：
Repairing：
Accessories：
Guarantee：
Power：Make sure the power is in the demanded range, not too high or too low. Correctly
load the battery, in order not the damage to machine.
Power：
SIMPIE FAULTS
AND TROUBLESHOOTING
Phenomenon
①
②
Make sure the adapter is well
contacted with the power plug.
Charge the battery before using
it.
Check the product
Troubleshooting
The switch
indicator
does not light up
Check the matching power
adapter indicator light up
or not.
When using lithium battery,
make sure there's no "low
power" protection.
Check whether the phone is
turned on Bluetooth and the
Bluetooth connection is
successful.
Normal steps:
APP can't
connect / can't
control
①
Check if the product is “OFF”
because of the APP of the
mobile phone.
Press the “ON/OFF” button once
again.
The product is in
the "ON" state,
the display and
lights are not on
Check whether the color purity
SAT value is too low or 0; the
color purity value is 100, the
color difference is most obvious.
The light
cannot adjust
RGB color
Increase the SAT value in
HSI mode
② Adjust brightness (BRG): range 0%~100%
① Mode selection：
③ Adjust color temperature (CCT): range 2700K~10000K
④ Adjust HUE: range 0° ~ 360°
⑤ Adjust color purity(SAT): range 0%~100%
FUNCTION INSTRUCTION &
INSTRUCTION FOR USE
Scan the QR code on the back of the manual to download the APP
Modes include : CCT, HSI, SCENE
HSI : Adjust the brightness, hue and color purity through the compound
knob or APP.
temperature adjustment → rotate the compound knob to adjust the
color temperature.
(Press the return button to return to the previous menu)
(Press the return button to return to the previous menu)
(Press the return button to return to the previous menu)
(Press the return button to return to the previous menu)
APP CONTROL AND
APP ON-LINE CONTROL
Turn on the lights and turn
on the phone's Bluetooth
② Open APP, connect
Bluetooth BT_ LED
Web: www.gvmled.com
B&H Email: [e-mail]
GVM Email: [e-mail]
Amazon Email: [e-mail]
[e-mail]
FacebookGVM Official website Download APP
