GDS-3000 Programming Manual
88
:TRIGger:VIDeo:FIELd
Set
Query
Description
Sets or queries the video trigger field.
Syntax
:TRIGger:VIDeo:FIELd {FIELD1 | FIELD2 | ALLFields |
ALLLines | ?}
Parameter
FIELD1
Trigger on field 1
FIELD2
Trigger on field 2
ALLFields
Trigger on all fields
ALLLines
Trigger on all lines
Return parameter
Returns the video trigger field.
Example
:TRIGger:VIDeo:FIELd ALLFields
Sets the video trigger to trigger on all field.
:TRIGger:VIDeo:LINe
Set
Query
Description
Sets or queries the video trigger line.
Syntax
:TRIGger:VIDeo:LINe {<NR1> | ?}
Parameter
<NR1>
Video line
Return parameter
Returns the video trigger line.
Example
:TRIGger:VIDeo:LINe 1
Sets the video trigger to line 1.
:TRIGger:VIDeo:POLarity
Set
Query
Description
Sets or queries the video trigger polarity.
Syntax
:TRIGger:VIDeo:POLarity {POSitive | NEGative | ?}
Parameter
POSitive
Positive polarity
NEGative
Negative polarity
Return parameter
Returns the video trigger polarity.
