BDA 387/2 Table of Contents A Product Description A1 A2 A3 Concise Operating Instructions .................................................................... 4 Introduction........................................................................................................ 5 Instrument Set-Up ............................................................................................ 5 B Operation B1 B2 Controls ........................................................................................
BDA 387/2 A Product Description A1 Concise Operating Instructions To turn spectro-color® on and off, press the flush button on the top of the instrument. The warning „Instrument not calibrated for 24 hours!“ appears after 24 hours without calibration at the latest. Press the centre black key yes to call the calibration function directly. If you do not wish to calibrate, because e.g. the calibration standard is not available, you can also measure without previous calibration.
BDA 387/2 A2 Introduction spectro-color® is a colorimeter operating on the spectral method described in DIN 5033 using the d/8° circular viewing geometry, i.e. the sample is illuminated with polychromatic light with the optical unit observing the reflected light from a 8° position towards the sample surface. spectro-color® is a genuine grating colorimeter measuring the visible spectral range (400nm to 700nm) at intervals of 10nm. A special reference beam system ensures highly reproducible measurings.
BDA 387/2 B Operation B1 Controls spectro-color® are operate with the 3 keys e beside the display d. Measurement is triggerd with the measure button g. fig. 1 front view c d e f g h i j 6 fig. 2 back view Measuring area, place spectro-color® in perpendicular position to the sample. Display Control keys (Softkeys). The functions of these keys are given in the display. On switch, to switch on the spectro-color® press the switch aprox. 2 sec. 2 measure buttons. Battery compartment.
BDA 387/2 c ON button, to turn spectro-color® on, hold the button down for pprox. 2 sec. d e f B2 Mains connection PC- and printer port. Barcode-reader port. fig. 3 top view Initial Start-Up Battery Operation Open the battery compartment on the back of your spectrocolor® and insert the batteries enclosed. Attention, be sure to place the batteries with the pole tips in correct direction ! Mains operation: spectro-color® comes with a power pack. Connect it to the mains/charging socket (fig.
BDA 387/2 B2.1 Program flow The following program flow shows the program structure of spectro-color®. From the main menu you can call the subroutines as follows: Key measurement directly and key C selects colour ΔC colour difference measurement. Key Ø opens the configuration menu. Main menu: LANGE spectro color d/8° LMG183 D65/10° Version 2.11 12.02.
BDA 387/2 B2.2 How to use the Barcode-reader With accessory „barcode reader pen“, it is easy to assign sample names to the measured values or load references from the memory. To create the corresponding barcodes you need the PC-Software spectral-qc. First turn spectro-color® off. Then connect the 9-pole D-sub plug of the barcode reader pen to spectro-color® (fig. 3, item 4). Hold the barcode reader pen loosely at an angle of. 10 to 30 degrees to the perpendicular.
BDA 387/2 B3 Configuration Configuration means the selection of a colour system or difference measuring program. The following basic program functions can be chosen with the selector key × or Ø . Confirm you choice with ok . B3.1 Colour measurement configuration Calibration Colour measurement Colour difference Memory Settings Illuminant Observer Back × Ø ok Select Colour measurement with key Ø . Press key ok . The display shows all the selectable colour values.
BDA 387/2 B3.4 Settings Select item Settings in the main configuration menu and then press key ok . The display shows the selectable instrument settings. Move to the desired settings with keys × and Ø. Press key ok to confirm the indicated setting. Settings Date Time Language Gloss subtr. OFF Beeper on Pass/Fail Settings Back × Ø ok B3.4.1 Setting Date and Time Select item date or time and confirm with ok . Date × Date: Press key × or Ø to change the given day.
BDA 387/2 B3.4.3 Gloss subtraction Select in the configuration menu Settings and press key ok . Press key Ø several times to select Gloss subtr. OFF. Press key ok to change the Gloss subtr. OFF. Now message Gloss subtr. ON appears and the gloss value is subtracted in the calculation of the measuring value. Settings Date Time Language Gloss subtr.
BDA 387/2 B3.5 Standard illuminant selection Select item Illuminant in the main configuration Illuminant menu and confirm with ok . Then the choice of standard illuminants is displayed. Move with the × or Ø keys to the desired standard illuminant. To select the highlighted standard illuminant, apply the ok key. D65 A C F2 F11/TL84 Standard illuminants D65, A, C, F2 and F11 are at choice for colour calculation. B3.
BDA 387/2 C Applications C1 Calibration It is recommended to calibrate spectro-color® at least once a day. spectro-color® should also be calibrated before every set-off measurement or after extended breaks (several days). After 24 hours without calibration, a warning is issued on the display Go for yes to skip directly to the calibration routine. If you don’t want to calibrate, because e.g. your calibration standard is not on hand, you can continue measuring without recalibration.
BDA 387/2 C2 Colour Measurement Preparing the measurement • Turn spectro-color® on and calibrate the instrument, if required (see chapter C1) • Select the required colour values (see Configuration). • C D65/10/SPIN _ M L* a* b* (CIE) Press key C for colour measurement. × Measuring Procedure • Place spectro-color® in perpendicular position to the sample.
BDA 387/2 • Press the Grf key (graphics) to display the spectral reflectance curve and the lettering of key T1 changes to Lab (CIEL*a*b*-diagram). R% Lab 80 60 Prt 40 • Press the Prt key (print) to open the print menu. 20 × 0 400 • Press the Lab key to display the CIE- L*a*b*-diagram. 500 100 5 ‐‐a 25 menu.
BDA 387/2 From the second measurement on, the sigma sign ∑ appears next to key T1 and Cl for „clear“ next to key T2. • After pressing the Cl key, the latest measured value is deleted. • Measure 2 L* = 83.03 a* = 0.09 b* = 7.82 ∑ Cl × ∑ Pressing the Colour measurement key finishes the mean value calculation and displays the result. • Press the ∑ key to indicate the mean value over the measurements and the number of measurements. • • C D65/10/SPIN L* a* b* (CIE) reflectance curve. L* = 83.
BDA 387/2 Measuring Procedure • Place spectro-color® in perpendicular C D65/10/SPIN Wi Yi W (CIE) position to the sample. • C3 Press the measure key to trigger measurement. Do not move spectro-color® as long as the display shows a clock. • Measuring is signalled by a measuring start and end beep. • The display shows the values in the selected colour system. • Press key DIM Wi Yi Wb CIE TPI = = = = = 34.5 15.2 36.0 30.1 59.8 Grf DIM × to switch the next colour system.
BDA 387/2 Measuring procedure • Place spectro-color® Reference values in perpendicular _ M position to the reference sample. • Press the measure button to trigger measurement. Do not move spectro-color® as long as the display shows a clock. • Measuring is signalled by a measuring start and end beep. • The display shows the colour values of the reference in the selected colour system. • Place spectro-color® in L* = 83.03 a* = 0.09 b* = 7.
BDA 387/2 In the print options menu you can choose to print the graphics (reflectance curve or CIEL*a*b*-diagram) or the single reflectance values. • Go for Grf to print the graphics. • Go for Rfl Print option Grf: Print Graph Grf Rfl Rfl: Rflec. values × to print the single reflectance values. Mean value calculation • Press the M key to select mean value Difference meas. calculation. • Place spectro-color® on the sample. • Trigger measurement with the measure button.
BDA 387/2 With a barcode reader, the reference values can be scanned directly from the barcode. To load the reference value from the memory without using a barcode reader, press the MEM key. Reference Measure button: Measure reference MEM MEM : Reference taken from memory × Go to the desired memory page with the arrow Memory page keys × or Ø and confirm with ok . You can freely choose names for the memory pages (e.g. page 1, page 2, etc.) when managing the memory with the PC-software.
BDA 387/2 C3.2 Pass/Fail Difference Measurement The pass/fail program is designed for routine analyses of test elements. The instrument monitors a given maximum colour tolerance without reading the display after each measurement but just signals deviations outside the tolerance with a double-beep. Preparing the measurement • and Turn spectro-color necessary (see chapter C1). • Select Pass/Failchapter B3.2). • Press the ® ΔC measurement.
BDA 387/2 C3.4 Relative opacity measurement DIN 53146 defines the opacity of paper as the relation of the reflectance Ro of a single sheet on a black backing to the reflectance R∞ of the same sheet on a pile of identical sheets. • Select item [colour difference] in the main configuration menu [colour difference] and confirm with ok. The display now shows a choice of colour systems for difference measurement (see page 10). • To highlight option [rel. Opacity] press the Ø key and confirm with ok.
BDA 387/2 C4 Memory spectro-color® can store up to 1000 measurements. The stored values are available for later printing or loading to a PC (optional QC-software). At item [Memory] you can activate or deactivate (on or off) the memory and print or clear the contents. This item comes at [value memory] in the main configuration menu. Then you see the menu shown on the right. C4.1 Memory activation Memory active passive print clear . × Ø ok Press key × or Ø to select [aktiv].
BDA 387/2 C5 Mean Value calculation In colour and colour difference measurements it is sometimes required to take the mean of several single measurements. For mean value calculation, press key M . All following measurements are stored for the mean value calculation. • Press the M key to select mean value calculation. Then you see the display shown on the right. • Place spectro-color® on the sample. • Trigger measurement with the measure button.
BDA 387/2 C6 Printer All measuring and calibration values can be documented with an optional Hach Lange printer. There are two types of prints, i.e. protocol and memory print. In the protocol print, all values are printed at once. In the memory print, however, the entire memory is printed. The printout shows measurings, number of the measurement and identification of the measuring values. Calibration Colour measurement e.g.: CIE- L*a*b* Colour difference z.B.: CIE-dE* Key M . Key Cl .
BDA 387/2 D Technical Information D1 Service Addresses For further information please contact your local service agent or one of the Hach Lange branches: D HACH LANGE GmbH ⋅ Willstätterstr. 11 ⋅ 40549 Düsseldorf ⋅ Tel.:(0211) 5288-0 ⋅ Fax:(0211) 5288-143 GB HACH LANGE LTD Pacific Way, Salford, Manchester. M50 1DL, Tel +44(0)161 872 1487, Fax +44(0)161 848 7324 I HACH LANGE S.r.l. ⋅ Via Riccione, 14 ⋅ I-20156 Milano ⋅ Tel.:(02) 39 23 14.1 ⋅ Fax:(02) 39 23 14.39 NL HACH LANGE Nederland B.V.
BDA 387/2 D4 Service and Maintenance Even a perfected product like spectro-color® requires careful handling and a little regular maintenance. To clean the housing, use a dry cloth or a mild household cleaner. Do never use solvents like e.g. naphta, acetone or the like. The optical parts should only be cleaned by our service personnel. No further maintenance is required from you. D4.
BDA 387/2 4. Then click Start and Run... . 5. Now the following dialogue box is opened. At „open“ type A:\TRANSCAL and press OK . Then the installation programm starts. Now choose the language and the PC-interface for communication with spectro-color® and PC. 6. Select item File in the menu bar and choose the command Load calibration values from file . 7. Select the file with bration data 00001234.scd) confirm your choice cali(e.g and with OK . Now the calibration 8. 9.
BDA 387/2 E Annex E1 Accessories and Spare Parts Part • printer for spectro-color® • Barcode-reader • Windows® 98/NT- software spectral-qc • certified standard acc. to DIN 5033 • external battery charger • set of Ni-MH rechargeable batteries (6 pcs.), type AA • PC-connection cable for spectro-color® • printer cable for spectro-color® • box for spectro-color® • instrument case • tripod E2 order no.
