HI-406BT Bluetooth GPS receiver with Digital Compass 1
Table of Contents 1.1 Overview ........................................... 1.2 Main Features ..................................... 3 5 2.1 Setting up: Bluetooth GPS receiver ........ 6 2.2 Setting up: Digital Compass ................. 12 3. Dimensions .......................................... 14 4. Packaging 4.1 Standard Packaging .............................. 15 4.2 Optional Packaging ............................... 17 5. System Specifications ............................. 20 6.
1.1 Overview Introduction HI-406BT-C is a GPS (Global Positioning System) receiver in wireless Bluetooth interface with buildin active antenna and extra digital compass functions. With HI-406BT-C, your mobile devices, such as, Smartphone, PocketPC, laptopPC, tabletPC, etc. can receive GPS data wirelessly and perform the GPS applications, such as, car navigation, personal navigation, route planning, tracking, etc.
4
1.2 Main Features: • 20 Channels "All- In-View" Tracking • P osition accuracy of 10 meters 2D RMS • Cold/W arm/Hot Start Time: 42/38/1 Seconds (Signal Strength > 30 dB-HZ) • R eacquisition Time: 0.
2.1 Setting up: Bluetooth GPS receiver STEP 1: Open the battery cap and put the battery (406-BTT) into the battery compartment.
STEP 2 Connect the inclusive AC charger to home electronics outlet or connect the inclusive DC charger to the car cigarette lighter. As soon as they connected, the solid amber light on the right side in front of HI-406BT-C will turned on (stay on) meaning the battery charging.
STEP 3 As soon as the battery fully charged, the amber light will turned off, then, up-plug the charger.
STEP 4 There is one of each switch on both side of HI-406BTC. The switch on the right side is for Bluetooth GPS receiver. The switch on the left side is for digital compass. As soon as turn on the switch on the right side, the GPS receiver will start to function and search the satellites.
Bluetooth GPS Switch LED indicator color Status Amber LED off Green (blinking) Green (Stay on) HI-406BT-C battery charging HI-406BT-C battery fully charged GPS in 3D fixed GPS searching more satellite and not in 3D fixed yet Blue (blinking) Blue (stay on) Red Bluetooth searching host device Bluetooth paired and connected HI-406BT-C battery low 10
STEP 5: As soon as turn on the switch on the right side, the Bluetooth will also start to function and searching. The blue light on the left side in front of HI-406BT-C will turned on (Blinking) meaning the Bluetooth is searching the host device and not get paired yet. Please consult the Bluetooth step by step connection guide from this manual on section . The pin code is " 0000 " when asked the pin code. After the Bluetooth paired and connected, the blue light will stay on.
2.2 Setting up: Digital Compass As soon as turn on the switch on the left side, the digital compass will start to function and indicating the north (LED on red) and the south (LED on green) based on the earth magnetic field. Since the HI-406BT-C equipped with 2-axiel digital compass chip, please make sure place the HI-406BT-C on horizontal surfaced and no grater than 30 degree angle. The digital compass or the Bluetooth GPS receiver can work independently or work simultaneously.
13
3. Dimensions Unit: mm Top View Button View 64.80 46.40 Side View Front View Back View 24.
4. Packaging 4.1 Standard Packaging: Model Name 1. Bluetooth GPS receiver with digital compass 2. Rechargeable Li-Polymer 3.7V 1100 mAh battery 3. Mini1394 to USB cable 4. AC power adaptor with USB female plug 5. Cigarette lighter adaptor with USB female plug 6. Carrying pouch 7. HI-406BT-C user manual 8.
3 6 4 7 5 8 16
4.2 Optional Packaging: Model Name 1. MMCX external antenna 2.
MMCX antenna Under blocking area, the external antenna can extend the signal reception from HI-406BT-C PS2-1394 By connecting to different optional connecting cables, HI-406BT-C can be a wired PS/II GPS receivr and used with all kinds of mobile devices.
HI-406BT-C as a GPS mouse By counecting different optional counecting cables, HI-406BT-C can be all kinds of wired GPS receiver solutions.
5. System Specifications Main Features GPS General Chipset SiRF Star III Channel Supports 20-channel Frequency L1 (1575.42MHz), CA code TTFF (Open Sky) Hot Start 8 sec. Warm Start 38 sec. Cold Start 42 sec.
Bluetooth General Frequency Modulation Method Max. Data rate Transmission Power (Maximum) Hoping Receiving Signal Range Receiver IF Frequency Baseband Crystal OSC Compliant 2400MHz to 2483.5MHz GFSK, 1Mbps, 0.5BT Gaussian Asynchronous: 723.2kbps/57.6kbps Synchronous: 433.9kbps/433.9kbps 4dBm(Class 2) 1600hops/sec,1MHz channel space -84 to -15dBm 1.5MHZ center frequency 16MHz Bluetooth Specification v1.1 Electrical Main power input Power consumption Backup Power Operation time 5±5%VDC 0.4W @ 3.
GPS Firmware Protocol Baud Rate Update Rate Datum NMEA/SiRF Binary 19200 bps 1Hz WGS84 Environmental Temperature Operating Temperature 10°C to +55°C Storage Temperature 20°C to +65°C Relative Humidity 5% to 95%, non-condensing LED Indicator LED 1 Color Blue Flashing Blue Red BT Active Yes No - Low Power Yes GPS Fix Status No Yes - Battery Charging Yes LED 2 Color Green Flashing Green Orange 22
6. Get Connected; Installation Guide 6.
Double Click "GPS OUTPUT on HI-406BT" 24
Key in pin code: “0000” Connected 25
6.
Double click “HI-406BT” 27
Key in pin code: “0000” Found the host device 28
For Connected with device Select the correct com port 29
Start GPS, NMEA message inflow 30 More satellites info
