Fully Automatic Washing Machine This manual is for HWMP50F Please read this manual carefully before using. Retain it for future reference.
CONTENTS CONTENTS the 2nd cover Names of the parts 1 Safety precautions 2 Installation and adjustment 4 Install the water inlet hose 5 Preparation before washing 6 Put in the laundries 7 Usage of the detergent 7 Close the top lid 7 Use the operation buttons 8 Finish washing 10 Disposal after washing 11 Trouble-shooting Answer to question 12 Packing list 13 Specification table The back cover
Names of the parts Cold water valve Top lid component Detergent box Control pannel Lint filter Water absorption cushion Power cord Hot water valve Handle Balance ring Inner tub Pulsater Front control board Cabinet Fixed leg (3 pieces) Adjustable leg Drain bushing Adjustable leg film Drain Back cover protective lid Meaning and description of the symbols Warning sign Contents marked with that symbol are related to the safety of the product and the personal safety of the users.
Safety precautions Please plug the power plug on special receptacle. Be sure to use three-pins power receptacle. Ensure that the earthing prong of the power receptacle is earthed reliably. Use leakage protector if possible. Earth The washing machine must be positioned so that the plug is accessible. Be sure to pull the plug off and close the water faucet in following cases: power failure, delivering the machine, setting the machine idle or cleaning the machine.
Safety precautions Do not put hand into the rotating tub. It is dangerous even if the rotation speed is slow. Take special care of the children. Keep children away from the washing machine to avoid them climbing on it. The appliance is not instruct for use of young children of infirm persons without supervision. Young children should be supervised to ensure that they do not play with the appliance. Do not decompose, repair or alter the machine by yourself.
Installation and adjustment Please install and adjust the machine according to the requirement of the mannual. It is very important to your security and correct operating the machine. Install the lint filter After opening the package, please take out the lint filter from the document bag, install it to the inner tub. See to the figure. Inner tub Lint filter Install the bottom plate After you open the package, please lean the washing machine gently down on Soft object ( like the towel cloth,blanket, etc.
Install the water inlet hose Install the water inlet hose Use the new hose and the old hose should not be reused. 1. Insert a new flat washer into each end of the inlet hoses. Firmly put the washers in the coupling. Note: Use the new hose sets supplied with the washer. Any other old hose sets should not be used. You may have to use pliers to tighten the coupling. Do not over tighten because you may cause damage to the valve. 2. Connect the water inlet hoses to the water faucet. 3.
1.Preparation before washing Preparation before washing 1.Connect the water inlet hose 2.Confirm that the washing machine is earthed reliably.Then insert the power plug into the receptacle.Do not connect the earth terminal to the gas pipe and tap water pipe. 3.Do not put down the drain hose. 4.Slanting or uneven ground may result 0.8m H 1.2m in unstable working or abnormal noise. Please make the machine stand horizontally.
2.Put in the laundries The capacity of washing of the machine refer to the largest weight of the standard laundries under dry condition that can be washed in one time. Laundries quantity in one washing cycle shall be lower than the rated capacity. The thickness ,size , type of the cloth will influence the actual washing capacity. It is suitable to put inreasonable amount of laundries and the laundries can be turned round in washing for one time washing.
5 Use the operation buttons a Description of operation button Process,remain time digitron "POWER ON/OFF" button Push the " POWER ON/OFF" button to switch on the power. Under power-on mode, push it to switch off the power. Push the " POWER ON/OFF" button to switch on the power. If the " POWER ON/OFF" button is not pushed, the machine will switch off the power automatically after 5 minutes. It displays "--" during detecting. It displays total remained time (min).
12 b Steps of using the operation buttons and description of the steps HWMP50F WASH CYCLE TEMP SELECT FUZZY NORMAL HEAVY QUICK WASH SPIN ONLY SOAK WASH RINSE SPIN WARM HOT COLD POWER ON/OFF TIME REMAINING WASH CYCLE START PAUSE WATER LEVEL 1.Push "POWER ON/OFF"button to switch on the power POWER ON/OFF 2.Push " WASH CYCLE " button to select suitable automatic program WASH CYCLE After the power is switched on, " NORMAL " is automatically set.
When "NORMAL" program is selected, the washing machine will perform fully-automatically controlled fuzzy program to set water level, water flow and wash duration according to the cloth nature and weight. 3 Push the " WATER LEVEL "button,select suitable water level WATER LEVEL After switching on the power, the washing machine will execute fuzzy program automatically to detect the cloth. After defection, it can set the water level automatically.
7 Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Clean the detergent box and set it on the control panel seat. Dismantle The lint filter must be used during washing. It must be cleaned in time after each using. Lint filter: 1.Pull it up to dismantle. 2.Push it down to install. 3.Clean the filter screen after washing.
Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company. Do not repair it by yourself. Phenomenan The reason How to settle The digitron displays E0. The top lid is opened during reserve procedure. Close the top lid.
Common phenomena Phenomena Explanation The spinning is intermittent when it starts. Balance the laundries to avoid slanting. The wash procedure pauses. The cloth sensor is detecting , it will add water after about 48 senconds. Select spin program, but it does not work. The program is setting the drain time , certain period is needed before it starts spinning. There may be some water flowing out of the drain hose in the first use of the machine.
Specification table Type Fully Automatic Washing Machine Model HWMP50F Rated voltage/frequency 220-240V Rated washing power 380W Rated spinning power 300W Weight About 35kg Dimensions (mm) L 520 W 530 H 890 Water inlet pressure 0.03Mpa-1.0MPa (when water temperature is 70 ~90 , the water inlet pressure of hot water shall not exceed 0.
