Specification

LED Large Flood Light
Catalog Number: Type:
Project:
Comments: Date:
LED Large Flood Lights are energy efcient alternatives - only
75W delivering up-to 5984 lumens - replacing up-to 400W Metal
Halide xtures. The performance driven LED Large Flood offers
0-10V dimming standard with low voltage leads supplied in the
integrated driver. These ood lights can be used in indoor and
outdoor markets. LED Large Floods are IP65 Rated for outdoor
use.
1
Applications include parking areas, walkways and work
areas. Provides visual interest for signs, billboards, statues,
architecture and landscapes. The LED Large Flood Light is
backed by a 5-Year Limited Warranty.
• Die-cast aluminum housing with hinged lens frame
• Clear flat glass lens
• Silicone gaskets
• Textured architectural bronze powdercoat finish
• CSA listed for wet locations
• Small yoke swivel wall bracket
• Hinged lens frame
• Removable 1/2" threaded plugs with O-rings for 1/2" conduit
access and photocell provision
Performance Specications
Installation
Ordering Information
Watt Product # Product Code Volts
Color
Temp. CRI Lumens
Useful
Life* Dimmable
DLC
®
Qualied
Fixture Size
L x H
Wattage
Equivalent
75 Watt 99903 FL3/CL75BZ50/LED 100-277V 5000K 75 5984 50000 0-10V Yes 16" x 10" 400W Metal Halide
* Useful Life is dened as the point in time at which the lamp will maintain at least 70% of its initial lumens. The lamp will continue to operate past this point at decreased light levels.
May not be compatible with all dimming systems, dimming performance may vary by system. Requires a 0-10V dimmer, with 2 additional wires for dimming control.
www.halcolighting.com | [e-mail] | call 800.677.3334
75
50,000 hour life
75W
5984
79
100-277V
50/60 Hz
CRI
Rated Life
Watt
Lumens
Lumens per Watt (LPW)
Input Line Voltage
Input Line Frequency
-40°F (-40°C)
113°F (45°C)
>90%
<20%
5-Year Limited
0-10V Dimmable
15.25 lbs.
Min. Start Temp.
Max. Operating Temp.
Power Factor
THD
Warranty
Control
Weight
• Glare Shield - GS3/FL3 - 99808
• Large Yoke - LY/FL3 - 99809
• Slip Fitter Flood - SF/FL - 99810
• Pole Tenon Mount Flood - PTM/FL - 99812
• Photocell 110-130V (SWIVEL) - PCS/120V - 99815
• Photocell 208-277V (SWIVEL) - PCS/277V - 99816
Construction Accessories
Energy Savings
System System Wattage Replacement LED Wattage Energy Savings
400W Metal Halide 452W
FL3/CL75BZ50/LED
75W 83%
• 100V-277V input range
• 50/60 Hz input frequency
• 0-10V dimming standard
• Voltage sensing 100-277V dimmable driver
• Electrical snap-in connectors to simplify wiring and installation
Electrical
1
IP65 Rated xtures are rated for use outdoors where exposed directly to water from rain or irrigation.
Accessories include hardware.
