Specification

Linear LED High Bay Series
www.halcolighting.com | [e-mail] | call 800.677.3334
ProLED
®
Linear LED High Bay Series is a long life and energy
ecient replacement for existing linear uorescent or HID
installations. Ideal for high mounting heights, the ProLED
Linear LED High Bays deliver instant-on capabilities, uniform
illumination, and reduced maintenance costs. Wiring and control
options and accessories are available to help reduce installation
times and save energy. Applications include; retail, distribution
centers, industrial facilities, gymnasiums, warehouses, and
grocery stores. ProLED
®
Linear LED High Bay Series is backed
by a 5-year warranty.
Construction
Performance Specications
Energy Savings
Installation
-40°C (-40°F)
55°C (131°F)
>95%
5-Year Limited
Dimming (0-10V DC)
16/20/26 lb
Min. Start Temp.
Max. Operating Temp.
Power Factor
Warranty
Control
Weight
• UL listed for damp locations
• 5000K color temperature
• Dimming (0-10V DC)
• Instant on
80
110,000 hours
111W, 161W and 221W
15,140/21,944/30,122
>130
120-277V
60 Hz
CRI
Rated Life
Watts
Lumens
Lumens per Watt (LPW)
Input Line Voltage
Input Line Frequency
Catalog Number: Type:
Project:
Comments: Date:
• Durable steel housing finished in a polyester powder coating
Standard High Bay HID System Watts Replacement LED Energy Savings
400W 458W 221W 51%
• 110,000 hour rated life
• 6' or 12' NEMA twist lock cord assembly (optional)
• Motion Sensor (optional)
• Emergency Battery (optional)
Ordering Information
NEW ITEM
* Useful Life is dened as the point in time at which the lamp will maintain at least 70% of its initial lumens. The lamp will continue to burn past this point, but at decreased light levels.
Warranty Commercial/Industrial: This product is warranted for 5 years from the date purchase.
May not be compatible with all dimmable systems, dimming performance may vary by system, please check the website www.halcolighting.com for up-to-date dimmer compatibility information. Use on incompatible systems may
shorten lamp life.
Ordering information.
Watt
§
Product # Product Code Volts
†
Color
Temp.
CRI Lumens Useful
Life*
Pkg.
Qty.
Height, Width,
Length
Dimmable DLC
®
Product ID
111 99649 LHB1/111/850/UNV/LED2 120-277V 5000K 80 15,140 110,00 1/1 3" x 13" x 24" Yes (0-10V) PL3BF1G73REC
161 99650 LHB2/161/850/UNV/LED2 120-277V 5000K 80 21,944 110,00 1/1 3" x 17" x 24" Yes (0-10V) PLSGT4CIBQG5
221 99651 LHB3/221/850/UNV/LED2 120-277V 5000K 80 30,122 110,00 1/1 3" x 17" x 48" Yes (0-10V) PLVP3TJYQJSV
99652 LHB/PMA Pendent Mounting Assembly 1/24
81981
VPL/EM/LED3 16W
Emergency Battery
120-277V 1/1
