Instruction Manual MODEL: HRF21CDS Hallman Industries 2502 Hwy 304 Smithville, TX 78957 512-444-2775
Welcome to the world of simple handling and no worries Thank you for choosing Hallman. This manual contains all the information you will need to safely and correctly use your refrigerator. Please read all the instructions prior to using the appliance, and keep this manual in a secure place for future reference. Do not remove the attached adhesive identification label containing code, model number, manufacturer and other information from the refrigerator.
Safety For children Please keep children from entering or climbing the refrigerator to avoid locking the children inside the refrigerator and hurting them when the refrigerator falls. Do not let the children near the refrigerator when open and close the doors. Children should be supervised to ensure that they do not play with the appliance. For the user Never pull out the plug by pulling the power cable. Always hold the plug and pull it out from the socket.
Product description 11 12 6 1 13 3 14 2 15 1 5 2 4 17 16 5 6 18 19 7 20 8 21 22 Refrigerator body 8 9 11 12 3 10 9 23 13 7 24 10 4 1 Left door for refrigerator compartment 13 Right door for refrigerator compartment 2 Cantilever rack 14 Butter box 3 Turnover beam 4 Sliding cantilever rack 15 Air duct cover plate 17 Side lamp for refrigerator compartment 16 Folded cantilever rack 1 Display 8 Ice storage box 5 Fruit and vegetable drawer 6 Small drawer 2 Left door for refri
Installation Remove all packaging material before using the new refrigerator. This includes the foam base and all adhesive tape holding the refrigerator accessories inside and outside. Clean both the inside and outside of the refrigerator with wet cloth (a little detergent could be added into the warm water to wash the cloth and then wipe it again with the clean water); Transport and Placing of Your Refrigerator Transport Keep upright and avoid squeezing or vibration during transport.
Start to Use You ought to get a good knowledge of all safety precautions and make sure that your refrigerator has been placed properly in its final position before using. 1. Unpacking Please install the decorative cover for bottom beam onto your refrigerator after unpacking and adjust the front leveling legs to level your refrigerator. 2.
Food suggested to store in refrigerator compartment 2. Ice storage box is used to store the ice. Taking-out and installation of the lower freezer drawer 1. Cooked wheaten food, cans, milk, etc. 3. The lower drawer of the freezer is used to store fish, meat and packaged poultry meat. 1. Pull out the lower freezer drawer first. 2. Snack food, food subject to tainting, dairy product 3. Cooked cold meat, sausage 4. Fruit, vegetables 5. Eggs, butter, cheese 6. Cans, seasoning 7.
Big drawer The big drawer has a maximum load of 10kg. Hook Pull out and install the big drawer 1. Pull out the big drawer; 2. Find the hook at the left and right sides at the drawer bottom (shown in the figure). 3. Hold the hook at two sides with a nose pliers or tweezers and push it up and out of the groove of sliding rail, and take out the hook at the other side with the same method. 4. Take out the drawer. 5. Install the drawer by putting the hook into the right place.
Take out, clean and install the ice cube box lf the ice maker isn't used for a long period, ice cubes that are just produced might have unpleasant smell. You must take out and clean the ice cube box. Open the upper drawer in the freezer compartment, rotate the knob of ice maker counterclockwise by 90, turn the handle from the horizontal position to vertical position to release the lock (as shown in Fig. 1 of Pg. 14), pull it out (as shown in Fig. 2 of Pg. 14) and take out the ice cube box.
Door handles Making minor adjustments between doors Assembly instructions of cold storage door handle: Remember a level refrigerator is necessary for getting the doors perfectly even. If you need help, review the previous section on leveling the refrigerator. When the left doors is lower than the right door(left). Or the right doors is lower than the left door. 1. Firstly, take the handle set bolts out from the refrigerator, use cross recessed screwdriver to set the bolt on the door.
Installing the water line Installing the water line Water line installation kits are available at extra cost from your dealer. 1.First water tubes (supplied) insert Into corresponding hole of water connector (supplied). 2.Second water line installation kit (not included) inserts into another hole of water connector (supplied). 3.Turn water on and check for any leakage Cold water line Pipe clamp Connecting to the water supply line 1. First shut off the main water supply line and turn the ice-maker off.
Introduction of Your Refrigerator's Functions 7 9 13 15 17 18 10 Introduction of Your Refrigerator's Functions Energy saving mode 8 1 2 3 4 5 6 11 14 16 19 12 Control buttons 1 Refrigerator temperature control 3 Energy saving mode 5 Ice-making switch 2 Freezer temperature control 4 Auto mode 6 Child Lock Display items 7 Fast-cooling icon 12 8 Fast-freezing icon 13 9 Energy-saving icon 14 10 Auto icon 15 11 Ice-making icon 16 Auto mode This function will set the temperature
Introduction of Your Refrigerator's Functions Introduction of Your Refrigerator's Functions Fast-freezing mode To set the temperature of the freezer compartment This function is used to counteract a sudden rise in the freezer compartment in order to preserve the nutritional content of the food.It is recommended that this mode be activated at least two hours before a large quantity of items is placed into the freezer. To activate the “Fast-freezing”mode:Press FRZ Temp for three seconds and the Super Frz.
Cleaning and maintenance Solutions to problems Refrigerator's maintenance and repair Cleaning Clean regularly dust from the back of refrigerator and ground. Clean regularly the space inside the refrigerator to avoid any unpleasant smell. Before cleaning, pull out the plug and use soft towels and neutral detergent and clean it finally with clear water. It is recommended to clean once half a year.
