Specifications

HANDBLOWN
GLASS METEO
CLOTH
BRAIDED
CORD
CANOPY
INNER GLASS
DIFFUSER
2.1
15.6
1.0
OAH ADJUSTABLE
FROM 19" TO137"
14.0
1.0
67.9
1.0
62.5
8.4
5.5
11.1
1.0
8.0
1.0
MOUNTS DIRECTLY TO J-BOX
MOUNTS TO BUILDING STRUCTURE
MOUNTS TO J-BOX AND CEILING
Forward/Reverse Phase To 1%
Forward/Reverse Phase
or 0-10V To 1%
9
CAST GLASS
CAST GLASS
Geo
Zircon
Floret
INNER GLASS DIFFFUSER OPTIONS QTY:
HAND-FORMED GLASS
HANDBLOWN GLASS DIMENSIONS
MAY VARY
1"
QTY: 9
REVISIONS
REV. DESCRIPTION Drawn By: Drawn Date: Approved By:
Approved
Date:
A CREATED TRAVIS 12/5/2019
SPECIFICATION DRAWING
Collection: Product #:
Mounting Packet:
Weight(lbs.):
Finish:
Electrical Type:
Elec. Qty: Voltage:
UL Location:
All fixtures created by Hammerton are handcrafted by artisans. Dimensions may vary up to 7/8".
Hammerton Inc. 217 Wright Brothers Dr. Salt Lake City, UT 84116 [phone]
All dimensions are shown in inches unless otherwise stated.
Visit hammertonstudio.com for product options.
Canopy Mounting Detail
SEE WEBSITE FOR OPTIONS
R 93
LED
DRY
CRI:
METEO (NEBULA)
Wattage:
Power Factor:
CCT:
© Copyright 2020. All rights in design, detail or invention of this drawing are reserved as the property of
Hammerton. Any imitation or adaptation without written consent is strictly prohibited.
PLB0067-09
2/13/2020
>0.9 93+
120479
2700 K
3060 0
A
Source Lumens: Ambient: Down:
N/A Top Diffuser:
Bottom Diffuser: CLOSED GLASS
Dimmable:
