2020/3820 User’s Guide 10 - 11
Beeper Volume - Good
Read
Off BEPLVL0 3-1
Low BEPLVL1 3-1
*Medium BEPLVL2 3-1
High BEPLVL3 3-1
Beeper Pitch - Good Read
(Frequency)
Low (1600) (min 400Hz) BEPFQ11600 3-2
*Medium (3250) BEPFQ13250 3-2
High (4200) (max 9000Hz) BEPFQ14200 3-2
Beeper Duration - Good
Read
*Normal Beep BEPBIP0 3-2
Short Beep BEPBIP1 3-2
LED - Good Read
Off BEPLED0 3-2
*On BEPLED1 3-2
Number of Beeps - Good
Read
*1 BEPRPT1 3-3
Range 1 - 9 BEPRPT# 3-3
Good Read Delay
*No Delay DLYGRD0 3-3
Short Delay (500 ms) DLYGRD500 3-3
Medium Delay (1000 ms) DLYGRD1000 3-3
Long Delay (1500 ms) DLYGRD1500 3-3
User-Specified Good Read
Delay
Range 0 - 30,000 ms
DLYGRD####
#
3-3
Trigger Mode
*Manual Trigger TRGMOD0 3-4
Read Time-Out (0 - 300,000
ms) *300,000
TRGSTO#### 3-4
Scanner Power Time-Out
Timer (0-7200 seconds) *3600
BT_LPT0 3-5
BT_LPT200 3-5
BT_LPT400 3-5
BT_LPT900 3-5
BT_LPT3600 3-5
BT_LPT7200 3-5
Automatic Trigger TRGMOD1 3-5
Presentation Mode TRGMOD3 3-5
Hands Free Time-Out (0-
300,000 seconds) *5000
TRGPTO####
##
3-6
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
