12 - 8 4600g, 4600r, 4800i User’s Guide
RS-232 Handshaking
*RTS/CTS Off 232CTS0 2-11
RTS/CTS On 232CTS1 2-11
*XON/XOFF Off 232XON0 2-11
XON/XOFF On 232XON1 2-11
*ACK/NAK Off 232ACK0 2-11
ACK/NAK On 232ACK1 2-11
Wand Emulation Connec-
tion
Same Code Format TERMID64 2-12
Code 39 Format TERMID61 2-12
Data Block Size
20 WNDBLK0 2-13
*40 WNDBLK1 2-13
60 WNDBLK2 2-13
80 WNDBLK3 2-13
Delay Between Blocks
5ms WNDDLY0 2-13
*50ms WNDDLY1 2-13
150ms WNDDLY2 2-13
500ms WNDDLY3 2-13
Overall Checksum
On WNDCHK1 2-14
*Off WNDCHK0 2-14
Wand Emulation Trans-
mission Rate
10 WNDSPD0 2-14
*25 WNDSPD1 2-14
40 WNDSPD2 2-14
80 WNDSPD3 2-14
120 WNDSPD4 2-14
150 WNDSPD5 2-14
200 WNDSPD6 2-14
Wand Emulation Polarity
*Black High WNDPOL0 2-15
White High WNDPOL1 2-15
Wand Emulation Idle
Idle Low WNDIDL0 2-15
*Idle High WNDIDL1 2-15
Output Selections
Beeper - Good Read
Off BEPBEP0 3-1
*On BEPBEP1 3-1
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
