4600g, 4600r, 4800i User’s Guide 12 - 11
Preferred Symbology
On PREFENA1 3-15
*Off PREFENA0 3-15
High Priority Symbology PRFCOD## 3-15
Low Priority Symbology PRFBLK## 3-15
Preferred Symbology Timeout PRFPTO#### 3-16
Preferred Symbology Default PRFDFT 3-16
Output Sequence Editor
Enter Sequence SEQBLK 3-19
Default Sequence SEQDFT 3-19
Require Output
Sequence
Required SEQ_EN2 3-19
On/Not Required SEQ_EN1 3-19
*Off SEQ_EN0 3-19
Multiple Symbols
On SHOTGN1 3-20
*Off SHOTGN0 3-20
No Read
On SHWNRD1 3-20
*Off SHWNRD0 3-20
Print Weight
Set Print Weight (1-7) PRTWGT 3-21
*Default (4) PRTWGT4 3-21
Video Reverse
On VIDREV1 3-21
*Off VIDREV0 3-21
Working Orientation
*Upright ROTATN0 3-22
Rotate Code Clockwise 90° ROTATN1 3-22
Upside Down ROTATN2 3-22
Rotate Code
Counterclockwise 90°
ROTATN3 3-22
Prefix/Suffix Selections
Add CR Suffix to All Symbologies VSUFCR 4-3
Prefix
Add Prefix PREBK2## 4-4
Clear One Prefix PRECL2 4-4
Clear All Prefixes PRECA2 4-4
Suffix
Add Suffix SUFBK2## 4-4
Clear One Suffix SUFCL2 4-4
Clear All Suffixes SUFCA2 4-4
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
