12 - 12 4600g, 4600r, 4800i User’s Guide
Function Code Transmit
*Enable RMVFNC0 4-4
Disable RMVFNC1 4-4
Intercharacter Delay Range 0 - 495 ms DLYCHR## 4-5
User Specified
Intercharacter Delay
Delay Length
(0 - 495 ms)
DLYCRX## 4-6
Character to Trigger Delay DLY_XX### 4-6
Interfunction Delay Range 0 - 495 ms DLYFNC## 4-6
Intermessage Delay Range 0 - 495 ms DLYMSG## 4-7
Data Formatter Selections
Data Format Editor
*Default Data Format (None) DFMDF3 5-5
Enter Data Format DFMBK3## 5-5
Clear One Data Format DFMCL3 5-5
Clear All Data Formats DFMCA3 5-5
Data Formatter
Off DFM_EN0 5-5
*On, but Not Required DFM_EN1 5-5
On, Required DFM_EN2 5-5
Alternate Data Formats
1 VSAF_1 5-6
2 VSAF_2 5-6
3 VSAF_3 5-6
Secondary Interface Selections
Secondary Interface
*Disable 2IF_EN0 6-1
Enable 2IF_EN1 6-1
Secondary RS-232 Con-
nection
RS-232 Interface 2IFTYP0 6-2
Secondary Code 39
Wand Emulation
Wand Emulation Same Code
Format
2IFTYP64 6-2
Wand Emulation Code 39 For-
mat
2IFTYP61 6-2
Wand Emulation Multi
Block
Delay Between Blocks
5 ms WNDDLY0 6-3
*50 ms WNDDLY1 6-3
150 ms WNDDLY2 6-3
500 ms WNDDLY3 6-3
Overall Checksum
On WNDCHK1 6-3
*Off WNDCHK0 6-3
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
