![](/manual/handheld/4600r/2-user-guide-english/images/img-191.png)
4600g, 4600r, 4800i User’s Guide 12 - 15
Interleaved 2 of 5 Check
Digit
*No Check Char. I25CK20 7-11
Validate, But Don’t
Transmit
I25CK21 7-11
Validate, and Transmit I25CK22 7-11
Interleaved 2 of 5 Mes-
sage Length
Minimum (2 - 80) *4 I25MIN## 7-11
Maximum (2 - 80) *80 I25MAX## 7-11
Code 93
Default All Code 93
Settings
C93DFT 7-12
Code 93
Off C93ENA0 7-12
*On C93ENA1 7-13
Code 93 Message Length
Minimum (0 - 80) *0 C93MIN## 7-12
Maximum (0 - 80) *80 C93MAX## 7-12
Code 93 Code Page C93DCP 7-12
Straight 2 of 5 Industrial
Default All Straight 2 of 5
Industrial
Settings
R25DFT 7-13
Straight 2 of 5 Industrial
*Off R25ENA0 7-13
On R25ENA1 7-13
Straight 2 of 5 Industrial
Message Length
Minimum (1 - 48) *4 R25MIN## 7-13
Maximum (1 - 48) *48 R25MAX## 7-13
Straight 2 of 5 IATA
Default All Straight 2 of 5 IATA
Settings
A25DFT 7-14
Straight 2 of 5 IATA
*Off A25ENA0 7-14
On A25ENA1 7-14
Straight 2 of 5 IATA Mes-
sage Length
Minimum (1 - 48) *4 A25MIN## 7-14
Maximum (1 - 48) *48 A25MAX## 7-14
Matrix 2 of 5
Default All Matrix 2 of 5
Settings
X25DFT 7-15
Matrix 2 of 5
*Off X25ENA0 7-15
On X25ENA1 7-15
Matrix 2 of 5 Message
Length
Minimum (1 - 80) *4 X25MIN## 7-15
Maximum (1 - 80) *80 X25MAX## 7-15
Code 11
Default All Code 11
Settings
C11DFT 7-15
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
