12 - 16 4600g, 4600r, 4800i User’s Guide
Code 11
*Off C11ENA0 7-16
On C11ENA1 7-16
Code 11 Check Digits
Required
1 Check Digit C11CK20 7-16
*2 Check Digits C11CK21 7-16
Code 11 Message Length
Minimum (1 - 80) *4 C11MIN## 7-16
Maximum (1 - 80) *80 C11MAX## 7-16
Code 128
Default All Code 128
Settings
128DFT 7-17
Code 128
Off 128ENA0 7-17
*On 128ENA1 7-17
ISBT Concatenation
*Off ISBENA0 7-17
On ISBENA1 7-17
Code 128 Message
Length
Minimum (0 - 80) *0 128MIN## 7-18
Maximum (0 - 80) *80 128MAX## 7-18
Code 128 Code Page Code 128 Code Page (*2) 128DCP## 7-18
Telepen
Default All Telepen
Settings
TELDFT 7-19
Telepen
*Off TELENA0 7-19
On TELENA1 7-19
Telepen Output
*AIM Telepen Output TELOLD0 7-19
Original Telepen Output TELOLD1 7-19
Telepen Message Length
Minimum (1 - 60) *1 TELMIN## 7-19
Maximum (1 - 60) *60 TELMAX## 7-19
UPC-A
Default All
UPC-A Settings
UPADFT 7-20
UPC-A
Off UPAENA0 7-20
*On UPAENA1 7-20
UPC-A Check Digit
Off UPACKX0 7-20
*On UPACKX1 7-20
UPC-A Number System
Off UPANSX0 7-20
*On UPANSX1 7-20
UPC-A 2 Digit Addenda
*Off UPAAD20 7-21
On UPAAD21 7-21
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
