12 - 18 4600g, 4600r, 4800i User’s Guide
EAN/JAN-13 2 Digit
Addenda
2 Digit Addenda On E13AD21 7-26
*2 Digit Addenda Off E13AD20 7-26
5 Digit Addenda On E13AD51 7-26
*5 Digit Addenda Off E13AD50 7-26
EAN/JAN-13 Addenda
Required
*Not Required E13ARQ0 7-26
Required E13ARQ1 7-26
EAN/JAN-13 Addenda
Separator
Off E13ADS0 7-26
*On E13ADS1 7-26
ISBN Translate
*Off E13ISB0 7-27
On E13ISB1 7-27
EAN/JAN-8
Default All EAN/
JAN 8 Settings
EA8DFT 7-27
EAN/JAN-8
Off EA8ENA0 7-27
*On EA8ENA1 7-27
EAN/JAN-8 Check Digit
Off EA8CKX0 7-27
*On EA8CKX1 7-27
EAN/JAN-8 Addenda
*2 Digit Addenda Off EA8AD20 7-28
2 Digit Addenda On EA8AD21 7-28
*5 Digit Addenda Off EA8AD50 7-28
5 Digit Addenda On EA8AD51 7-28
EAN/JAN-8 Addenda
Required
*Not Required EA8ARQ0 7-28
Required EA8ARQ1 7-28
EAN/JAN-8 Addenda
Separator
Off EA8ADS0 7-28
*On EA8ADS1 7-28
MSI Default All MSI Settings MSIDFT 7-29
MSI
*Off MSIENA0 7-29
On MSIENA1 7-29
MSI Check Character
*Validate Type 10, but Don’t
Transmit
MSICHK0 7-29
Validate Type 10 and
Transmit
MSICHK1 7-29
MSI Message Length
Minimum (4 - 48) *4 MSIMIN## 7-30
Maximum (4 - 48) *48 MSIMAX## 7-30
Plessey Code Default All Plessey Settings PLSDFT 7-30
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
