13 - 2 4600g, 4600r, 4800i User’s Guide
4600r
Parameter Specification
Dimensions (Typical):
Height
6.2 inches (15.7 cm)
Length
5.3 inches (13.5 cm)
Width
3.2 inches (8.1 cm)
Weight
6.5 ounces (184.3 g)
Illumination:
Scan LEDs
Aiming LEDs
617nm +
30nm
526nm +
30nm
VGA, 640x480 (4X00); 752x480 (5X00). Binary, TIFF,
or JPEG output.
Skew Angle ±40 degrees
Pitch Angle ±40 degrees
Motion Tolerance:
Streaming Presentation Trigger
Other Trigger Selections
20 inches (50 cm) per second
4 inches (10 cm) per second
Symbol Contrast Grade 1.0 (20% or greater)
Voltage Requirements 4 - 14 VDC at imager
Current Draw (Typical):
Input
Scanning Standby Inrush Low Power
5V 354mA 80mA 500mA 100µA
12V 180mA 55mA
Power Supply Noise Rejection Maximum 100mV peak to peak, 10 to 100 kHz
Temperature Ranges:
Operating
+32°F to +122°F (0°C to +50°C)
Storage
-40°F to +140°F (-40°C to +60°C)
Humidity 0 to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 6 feet
(1.8 m) to concrete
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Tolerance 15 kV to any external surface
Agency Compliance
FCC Class A, CE EMC Class A, CE Low
Voltage Directive, IEC60825-1 LED Safety: Class 1,
UL, cUL listed, TÜV Certified to EN60950, C-Tick,
NOM
