1 - 8 4600g, 4600r, 4800i User’s Guide
9. To set up the serial wedge terminal ID, use the serial terminal ID 050 and
follow the instructions on page 2-1.
10. Program the port for data transmission using the bar codes on page 1-12.
Programming the Interface - Plug and Play
Plug and Play bar codes provide instant imager set up for commonly used
interfaces.
Note: After you scan one of the codes, power cycle the host terminal to have the
interface in effect.
Note: See "Imager Models" on page 1-2 to determine which interfaces apply to
your imager.
Keyboard Wedge Connection
If you want your system programmed for an IBM PC AT and compatibles
keyboard wedge interface with a USA keyboard, scan the bar code below.
Keyboard wedge is the default interface.
Laptop Direct Connect
For most laptops, scanning the
Laptop Direct Connect
bar code allows
operation of the imager in parallel with the integral keyboard. The following
Laptop Direct Connect bar code also programs a carriage return (CR) suffix, and
turns on Emulate External Keyboard (page 2-7).
IBM PC AT and Compatibles
with CR suffix
Laptop Direct Connect
with CR suffix
