4600g, 4600r, 4800i User’s Guide 2 - 3
* Default for 4600g/4600r/4800iXX 05XX models
** Default for 4600g/4800iXX 03XX models
***Applies to 4600g/4600r/4800iXX 05XX models only. It is best to use the Plug and Play
bar codes, beginning on page 1-9, to program these interfaces, rather than scanning the
terminal ID listed in this table.
Serial Wedge
050
Silicon Graphics Indy, Indigoll
005
Telex 88 key 078, 078A, 79, 80, 191, 196,
1191,1192, 1471, 1472, 1476,
1477, 1483
025
Telex 88 key Data Entry Keyboard
112
Telex 102 key 078, 078A, 79, 80, 191, 196,
1191,1192, 1471, 1472, 1476,
1477, 1483
045
Telex 122 key 078, 078A, 79, 80, 191, 196,
1191,1192, 1471, 1472, 1476,
1477, 1482, 1483
046
USB COM Port Emulation
130
USB PC Keyboard
124***
USB Mac Keyboard
125***
USB HID POS
131***
Wand Emulation (Code 39
Format)
061
Wand Emulation (Same
Code Format)
064
Supported Terminals
Note: See "Imager Models" on page 1-2 to determine which interfaces apply to
your imager.
Terminal Model(s)
Terminal
ID
