Section 13 – Receiver, Battery and Fuel Tank Installation
29
Step 6
Assemble the tank per the instructions included with
the tank. Be sure to use the gas-compatible stopper
and fuel tubing.
Step 7
Place foam on the floor of the tank compartment.
Secure the tank in place by wrapping rubber bands
or Velcro straps around the tank and tank floor. Cup
hooks can be used to hook the rubber bands to the
tank floor. Later we will run the fuel lines.
Step 8
Mount the receiver switch in a convenient location in
the side of the fuselage.
