User Manual
Table Of Contents
- Table of Contents
- Using the Manual
- Contents of Kit
- Other Items Needed (not included in the kit)
- Additional Required Equipment
- Additional Required Tools and Adhesives
- Optional Hangar 9 1/3 Scale Hardware Package
- Servo Selection
- Before Starting Assembly
- Warning
- Warranty Information
- Section 1 - Aileron Servo Installation
- Section 2 - Aileron Control Horn Installation
- Section 3 - Hinging and Sealing the Control Surfaces
- Section 4 - Sealing the Hinge Gaps
- Section 5 - Aileron Linkage Installation
- Section 6 - Wing Tube Installation
- Section 7 - Rudder and Elevator Servo Installation
- Section 8 - Elevator Linkage Installation
- Section 9 - Rudder Linkage Installation
- Section 10 - Landing Gear Installation
- Section 11 - Wheel Pant Installation
- Section 12 - Tail Wheel Installation
- Section 13 - Receiver, Battery and Fuel Tank Installation
- Section 14 - Mounting the Engine and Cowl
- Section 15 - Hatch Assembly
- Section 16 - Balancing the Model
- Section 17 - Radio Setup
- Section 18 - Control Throws
- Preflight at the Field
- Setup and Flying
- Extra 330S - 3D at its Best
- 2003 Official AMA National Model Aircraft Safety Code
3
Contents of Kit
Large Parts
A. Fuselage w/Hatch HAN1176
B. Right Wing Panel w/Aileron HAN1177
C. Left Wing Panel w/Aileron HAN1178
D. Right Stabilizer w/Elevator HAN1179
E. Left Stabilizer w/Elevator HAN1180
F. Rudder HAN1181
G. Canopy HAN1182
H. Painted Cowl HAN1184
I. Aluminum Landing Gear HAN1185
Additional Required Equipment
Radio Equipment
• 4-channel radio system (minimum)
• 1 standard servo for throttle (JRPS537
recommended or equivalent)
• 8 hi-torque servos (JRPS8411
recommended or equivalent)
Recommended JR™ Systems
• PCM10X
• XP8103
• X-378
• XP662
• XF631
• XF421
• Quattro
Recommended Engines
•G-62, GT-80
JR XP8103
JR PCM 10X
Zenoah
®
GT-80
ZENE80T
Zenoah
®
G62
ZENE62A
A
B
C
D
E
Other Items Needed (not included in the kit)
• Propeller (consult engine instructions)
• 12" Servo Extension (JRPA098)
• 18" Servo Extensions (JRPA099) (4)
• 24" Servo Extensions (JRPA102) (5)
• 1/8" light plywood
• Y-Harness (JRPA133) (2)
• MatchBox™ (JRPA900) (4)
F
G
H
I
Items not shown:
Canopy Hatch HAN1183
Landing Gear Fairing HAN1186
Decal Set HAN1187
