Q.Peak BLK 295 Specifications

The new high-performance module Q.PEAK BLK-G4.1 is the ideal solu-
tion for residential buildings thanks to its innovative cell technology
Q.ANTUM. The world-record cell design was developed to achieve
the best performance under real conditions – even with low radiation
intensity and on clear, hot summer days.
Q.ANTUM TECHNOLOGY: LOW LEVELIZED COST OF ELECTRICITY
Higher yield per surface area and lower BOS costs and higher power
classes and an efficiency rate of up to 18.0 %.
INNOVATIVE ALL-WEATHER TECHNOLOGY
Optimal yields, whatever the weather with excellent low-light
and temperature behaviour.
ENDURING HIGH PERFORMANCE
Long-term yield security with Anti LID Technology,
Anti PID Technology
1
, Hot-Spot Protect and Traceable Quality Tra.Q™.
EXTREME WEATHER RATING
High-tech aluminium alloy frame, certified for
high snow (5400 Pa) and wind loads (4000 Pa).
MAXIMUM COST REDUCTIONS
Up to 10 % lower logistics costs due to higher
module capacity per box.
A RELIABLE INVESTMENT
Inclusive 12-year product warranty and 25-year linear
performance warranty
2
.
THE IDEAL SOLUTION FOR:
Rooftop arrays on
residential buildings
1
APT test conditions: Cells at -1500 V
against grounded, with conductive
metal foil covered module surface,
25 °C, 168 h
2
See data sheet on rear for further
information.
ANTI PID TECHNOLOGY
(APT)
HOT-SPOT PROTECT
(HSP)
TRACEABLE QUALITY
(TRA.Q™)
YIELD SECURITY
ANTI LID TECHNOLOGY
(ALT)
EN
174 modules tested
Best polycrystalline
solar module 2014
Q.PRO-G2 235
MOD:27898
photon.info/laboratory
www.VDEinfo.com
ID. 40032587
Quality Tested
high reliability
low degradation
optimized durability
continous line monitoring




11/2016
EN
Q.PEAK BLK-G4.1 285-295
Q.ANTUM SOLAR MODULE
