Excerpt from:

User Manual MMI3G with Headphone P102

ENGLISH – DRAFT/correction copy/for internal use

statements FCC part 15.19 and 15.21:

"This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation."

"Changes or modifications not expressly approved by the party responsible for compliance could void

the user's authority to operate the equipment."

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Headphones

Switch wireless headphones on/off (Applies only to vehicles with Rear Seat Entertainment)

Figure 105 wireless headphones on and off

Wireless headphones on

► To switch on the wireless headset, press the power button (1) Figure 105 on the right earpiece (R)

for about 3 seconds until the diode (2) starts to flash. The connection between Rear Seat

Entertainment and the wireless headset is established after short time. When the connection is

established, the diode (2) flashes slowly.

Wireless headphones off

► To turn off the wireless headset, press the power button (1) until the diode (2) is off.

CAUTION

- Use the headphones as a driver for security reasons only when the vehicle is standing – accident!

- Place the headphones while driving, so that in case of breaking or accident nobody can be injured.

Note

- In case of connection was not successful, turn off the wireless headphone off and repeat the

coupling process. Other problem solutions are described below.

- At too high and too low volume level, the wireless headset will be automatically set to a fixed value

while coupling the process.

- After turning the RSE off the wireless headset will switch after about five minutes automatically off.

Teach and mark the wireless headphone

The wireless headphones have to be unique trained and identified to the RSE. The programming

Summary of content (4 pages)

PAGE 1
Excerpt from: User Manual MMI3G with Headphone P102 ENGLISH – DRAFT/correction copy/for internal use statements FCC part 15.19 and 15.21: "This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
PAGE 2
procedure must be run separately for the left / right wireless headphones. Depending on which side of the RSE control unit to start the learning process, the wireless headset to the left / right RSE display is assigned. The assignment of the headphones to the left / right RSE display is marked with a sticker. Figure 106 Wireless Headphones feature teach wireless Headphones Prerequisite: The protective film of the battery cover is removed - see Figure 107 - and the wireless headset is off.
PAGE 3
Figure 107 connector for the charger / battery Charging Akkus ► Connect the charger cable to the connector (1) - Figure 107, which is located on the underside of the left earpiece (L). ► Then connect the charger to the cigarette lighter 12-volt power supply in the center console in the rear. The batteries of the headphones are loaded. Change batteries ► Turn the cover (2) on the left earpiece (L) right to left. The battery compartment is opened. ► Replace the batteries.
PAGE 4
Wireless headphones on and off – Troubleshooting Drahtlose Kopfhörer ein-/ausschalten - Problembehebung Cause Possible Solution The wireless headset is not in the correct turn off the wireless headset and repeat the connection status switching on process.
