2
0510000497.D
7501BL / 7501BL240
ELECTRICAL SCHEMATIC
1:1
11
FV 09/21/16
5086
VWC
INSTALLATION
5139
2016
VWC
120 VAC
POWER IN
GROUND
WHITE (120V) / RED (240V)
BLACK
GREEN
TERMINAL
THERMOSTAT
BLOCK
TRACE
HEAT
SHIELD
CABLE
FOR MODEL 7501BL
240 VAC
FOR MODEL 7501BL240
