Settfemont of
Outdoor Unit -
" Anchor
the outdoor unit with
a
bolt and nut (e10mm)
tightly
and
horizontally on a
concrete
or
rigid
mount.
" When installing
on the
wall,
roof
or rooftop, anchor
the
mounting
base securely with a nail or wire
assuming the
influence
of wind and
earthquake.
" in
the
case
when the vibration of the unit is conveyed
to the house, settle the unit with an anti-vibration
rubber.
Evaluation
of
the_performance
Bolt
i.
i
Tubing connection
Operate unit for 15-20 minutes, then
check the
system refrigerant charge:
(1)
Measure
the pressure
of
the gas side service valve.
(2) Measure the
outside
ambient airtemperature.
(3)
For
reference; the gas side pressure of optimum condition
is
as Below;
Outside
ambient TEMP.
The Pressure of the gas side service valve
35-C(95°F)
4-Skg/om2(56.8-71.0 P.S.I.G)
NOTE If
the actual pressure are higher
than shown,
the
system is most likely over-charged,
and
charge should be
removed. If the actual pressure
are
lower than shown,
the system is
most
likely undercharged, and charge
should be added.
The air conditioner is
now ready for
actual
operation.
