5.1

431

Further information at www.HellermannTyton.co.uk/identiﬁcation

Date of issue: April 2016

Identification Systems

Wire and Cable Markers

MATERIAL

Polyoleﬁn, cross-linked (PO-X)

Operating Temperature -55 °C to +135 °C

Flammability ASTM D2671 B

Recommended Ribbon Type TTDTHOUT

Speciﬁcations

MIL-STD-202G Method 215K,

SAE - AS81531

TAGUL is a specially designed for use in identifying wire and cable bundles

in electronics and general cabling environments. The labels are applied

to cables and harness assemblies with cable ties, and are also suitable for

retroﬁt purposes. The material has been conditioned for printing on both

thermal transfer and laser beam printers. The Tiptags are supplied on a

continuous material roll. Simply print and press out the required Tiptag

and apply with cable ties. Print with HellermannTyton's premium range of

thermal printers and ribbons or a laser beam marking device.

Printers: TT4000

and TT430

Ribbon: TTDTHOUT

Accessories for TT4000

: Cutter (S4000)

Accessories for TT430: Cutter (S430)

Software: TagPrint Pro

Features and Beneﬁts

• TAGUL is a general purpose Tiptag

• Thermal transfer or laser beam printable

• Available in white or yellow

• Meets MIL-STD 202G Method 215 mark permanence tests

• Good mechanical strength and highly ﬂexible

• Delivery in convenient storage boxes

• Easy label design with TagPrint Pro

Identiﬁcation tags for cable bundle "Ladder Style",

thermal transfer

TAGUL.

TAGUL - Standard Tiptags "Ladder Style"

TAG10x51-4

TAG20x51-6

TAG20x51-4

For product speciﬁc approvals and speciﬁcations please refer to the Appendix.

TYPE

Length

(L)

Width

(W)

Pack

Cont. Colour Article-No.

TAGUL10X51-4WH 51.0 10.0 2,000 pcs. White (WH) 556-82000

TAGUL10X51-4YE 51.0 10.0 2,000 pcs. Yellow (YE) 556-82001

TAGUL20X51-4WH 51.0 20.0 1,000 pcs. White (WH) 556-82005

TAGUL20X51-4YE 51.0 20.0 1,000 pcs. Yellow (YE) 556-82004

TAGUL20X51-6WH 51.0 20.0 1,000 pcs. White (WH) 556-82002

TAGUL20X51-6YE 51.0 20.0 1,000 pcs. Yellow (YE) 556-82003

All dimensions in mm. Subject to technical changes.

Minimum Order Quantity (MOQ) may differ from package content.
