Datasheet

2.1
200
Further information at www.HellermannTyton.com/insulation
Date of issue: October 2015
Insulation
Heat Shrinkable Tubing
MATERIAL
Polyolefin, cross-linked (PO-X)
Shrink Ratio 2:1 3:1
Operating Temperature -55 °C to +135 °C
Minimum Shrink
Temperature
+100 °C
Longitudinal change
after shrinkage
+/-5 % max.
Dielectric Strength 20 kV/mm according to ASTM D 150
Flammability UL224 VW-1
Specifications
CSA, SAE - AMS - DTL-23053/5 Class 1
and 3, SAE - AMS - DTL-23053/5 Class 2
(clear), UL224 125 °C 600V VW-1
TREDUX thin wall heat shrink tubing is used for general electrical
insulation and mechanical protection of cables and wires.
Features and Benefits
• Thin walled, flexible, cross-linked polyolefin tubing
• 1m shrink tubing lengths delivered in handy display carton
• 9 sizes from 1.5 mm to 101.6 mm
• Colours: black and yellow/green
One Step to the Web!
Heat Shrinkable Tubing up to 3:1 - 1 m lengths
TREDUX shrinks a maximum of 3:1.
TREDUX thin wall
More colours on request.
Please contact us!
For product specific approvals and specifications please refer to the Appendix.
TYPE
Supplied
Ø D min.
Recov.
Ø d max.
Wall
(WT)
Length
(L)
Pack
Cont. Colour
Shrink
Ratio Article-No.
TREDUX-1.5/0.5
1.5 0.5 0.50 1.0 m 20 pcs. Black (BK) 3:1 319-00150
1.5 0.5 0.50 1.0 m 20 pcs. Green-Yellow (GNYE) 3:1 319-00157
TREDUX-3/1
3.0 1.0 0.60 1.0 m 20 pcs. Black (BK) 3:1 319-00300
3.0 1.0 0.60 1.0 m 20 pcs. Green-Yellow (GNYE) 3:1 319-00307
TREDUX-6/2
6.0 2.0 0.70 1.0 m 15 pcs. Black (BK) 3:1 319-00600
6.0 2.0 0.70 1.0 m 15 pcs. Green-Yellow (GNYE) 3:1 319-00607
TREDUX-12/4
12.0 4.0 0.85 1.0 m 10 pcs. Black (BK) 3:1 319-01200
12.0 4.0 0.85 1.0 m 10 pcs. Green-Yellow (GNYE) 3:1 319-01207
TREDUX-24/8
24.0 8.0 1.20 1.0 m 5 pcs. Black (BK) 3:1 319-02400
24.0 8.0 1.20 1.0 m 5 pcs. Green-Yellow (GNYE) 3:1 319-02407
TREDUX-38.1/19.1
38.1 19.1 1.02 1.0 m 6 pcs. Black (BK) 2:1 319-03800
38.1 19.1 1.02 1.0 m 6 pcs. Green-Yellow (GNYE) 2:1 319-03807
TREDUX-50.8/25.4 50.8 25.4 1.14 1.0 m 6 pcs. Black (BK) 2:1 319-05100
TREDUX-76.2/38.1 76.2 38.1 1.27 1.0 m 3 pcs. Black (BK) 2:1 319-07600
TREDUX-101.6/50.8 101.6 50.8 1.40 1.0 m 2 pcs. Black (BK) 2:1 319-10200
All dimensions in mm. Subject to technical changes.
Minimum Order Quantity (MOQ) may differ from package content.
Heat Shrinkable Tubing 2:1
L
Heat Shrinkable Tubing 3:1
L
