User guide

Q617.001

2002 Arctic Cat

375 AUTOMATIC 4X4

Stage 1

For mildly tuned machines using the stock airbox with

stock or aftermarket filter. May also be used with a

good aftermarket exhaust system.

K&N Filter # N/A

1 Main Jet DJ118

1 Main Jet DJ120

1 Main Jet DJ122

1 Main Jet DJ124

1 Main Jet DJ126

1 Main Jet DJ128

1 Main Jet DJ130

1 Main Jet DJ132

1 Main Jet DJ134

1 Fuel Needle DNO348

1 Slide Spring DSP031

2 Adjusting Washers DW0001

1 E-clips DE0001

Parts List

PAGE 1
Q617.001 2002 Arctic Cat 375 AUTOMATIC 4X4 Stage 1 For mildly tuned machines using the stock airbox with stock or aftermarket filter. May also be used with a good aftermarket exhaust system.
PAGE 2
Q617.001 STAGE ONE INSTRUCTIONS 1.Remove vacuum slide from carb. Remove stock needle & spacers, noting order of assembly (Fig.A). 2. Install Dynojet needle on groove #5 for applications below 5000 feet, groove #4 for above 5000 feet, using all stock spacers. Install the Dynojet washers above the E-clip (Fig.A). 3. Install the Dynojet slide springs (DSP031) in place of the stock slide spring. This is Groove # 1 4. Remove stock main jet and replace with Dynojet main jet provided.
