Owner manual

Q429.001

2006-2009 Yamaha

350 Wolverine

Stage 1

For mildly tuned machines using the stock airbox with

stock or aftermarket filter. May also be used with a

good high flow aftermarket exhaust system.

Parts List

1 Main Jet DJ120

1 Main Jet DJ124

1 Main Jet DJ128

1 Main Jet DJ132

1 Main Jet DJ136

1 Fuel Needle DNO490

1 Needle Spring DSP77

1 Adjusting Washer DW0001

1 E-Clip DE0001

1 Screw DS0001

1 Plug Drill DD 5/32

PAGE 1
Q429.001 2006-2009 Yamaha 350 Wolverine Stage 1 For mildly tuned machines using the stock airbox with stock or aftermarket filter. May also be used with a good high flow aftermarket exhaust system.
PAGE 2
STAGE ONE INSTRUCTIONS Q429.001 1. Remove vacuum slide from carb. Remove stock needle & spacers, noting order of assembly (Fig.A). 2. Install Dynojet needle on groove #4 for applications below 5000 feet, groove #3 for above 5000 feet, using all stock spacers (Fig.A). NOTE: The DSP77 spring does not have to be used, it is supplied in case the stock spring is misplaced.The Dynojet washer (DW0001) does not need to be installed at this time, it is for half step adjustments.
