‘ Camera HD-SDI Camera User Manual UD.
HD-SDI Camera·User Manual Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to DS-2CC11D3S-IR, DS-2CC51D3S-VPIR. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. We will readily improve or update the products or procedures described in the manual.
HD-SDI Camera·User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
HD-SDI Camera·User Manual equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
HD-SDI Camera·User Manual Warnings In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with AC 24V or DC 12V according to the IEC60950-1 standard. Please refer to technical specifications for detailed information.
HD-SDI Camera·User Manual Do not touch senor modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently. If the camera will not be used for an extended period, please replace the lens cap to protect the sensor from dirt. Do not aim the camera at the sun or extra bright places. Blooming or smearing may occur otherwise (which is not a malfunction), and affect the endurance of sensor at the same time.
HD-SDI Camera·User Manual Table of Contents 1 Introduction ...................................................................................................... 9 1.1 Product Features .............................................................................. 9 1.2 Overview ........................................................................................ 10 2 Installation ...................................................................................................... 12 2.
HD-SDI Camera·User Manual 3.5.8 Version ................................................................................ 35 3.6 ADJUST ........................................................................................... 36 3.6.1 Sharpness ............................................................................ 36 3.6.2 Monitor ............................................................................... 37 3.6.3 OSD ...............................................................................
HD-SDI Camera·User Manual 1 Introduction 1.1 Product Features This series of camera adopts high-sensitive sensor and advanced circuit board design technology. It features high resolution, low distortion, and low noise features, etc., which make it extremely suitable for surveillance system and image process system. The main features of HD-SDI cameras are as follows: 2 Megapixel high-performance CMOS sensor Clear and detailed image of up to 1080P resolution Low illumination: 0.01Lux @ (F1.
HD-SDI Camera·User Manual 1.2 Overview 7 1 OK 8 2 9 6 10 3 4 5 Figure 1-1 Overview of HD-SDI Bullet Camera Table 1-1 Description No. Description No.
HD-SDI Camera·User Manual 1 4 6 OK 5 2 3 9 10 8 7 Figure 1-2 Overview of HD-SDI Dome Camera Table 1-2 Description No. Description No.
HD-SDI Camera·User Manual 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is power-off during the installation. Check the specification of the products for the installation environment. Check whether the power supply is matched with your AC outlet to avoid damage. If the product does not function properly, please contact your dealer or the nearest service center.
HD-SDI Camera·User Manual φ4 φ55 Cutting line φ68 Screw Hole Template Figure 2-1 Drill Template 2. Route the corresponding cables. 3. Fix the camera to the wall with the supplied P A4 screws.
HD-SDI Camera·User Manual 4. Connect the video output cable to the monitor. Connect the power cable to the power supply. 5. Adjust the Lens. 1). Loosen the adjustable nut. 2). Adjust the camera from pan direction which is 0~360°adjustable. 3). Adjust the camera from tilt direction which is 0~90°adjustable. 4). Rotate 0~360° to adjust the lens to the surveillance angle. 5). Tighten the adjustable nut to complete the installation.
HD-SDI Camera·User Manual Hole Ceiling Mounting Hole Hole Figure 2-4 Drill Template 2. Loosen the set screws with a hex key (supplied) to remove the lower dome.
HD-SDI Camera·User Manual 3. Fix the mounting base on the ceiling with screws. Figure 2-6 Fix the Mounting Base Note: If required, you can route cables through the side opening on the side of the mounting base. Side Opening Figure 2-7 Side Opening 4. Loosen the tilt lock screws, adjust the tilting position in a range of 65 degrees, and tighten the tilt lock screws.
HD-SDI Camera·User Manual 5. Rotate the black liner to adjust the panning position in a range of 180 degrees until you get the desired surveillance angle. PAN Tilt Lock Screw Black Liner TILT Figure 2-8 Angle Adjustment Note: As the lens has already been factory adjusted to the best imaging effect, you just need to adjust the panning position and tilting position to get the desired surveillance angle. 6. Reinstall the lower dome and tighten the screws.
HD-SDI Camera·User Manual 3 Menu Description Figure 3-1 Main Menu Overview Notes: The OK button on the cable is used to control the menu. Press the OK button up/down to select the menu item. Press the OK button left/right to adjust the value. OK button is also used to confirm a selection. 3.1 LENS The camera is equipped with a fixed lens, which is not configurable.
HD-SDI Camera·User Manual 3.2 EXPOSURE EXPOSURE SHUTTER AGC SENS-UP BRIGHTNESS ACCE DEFOG BACKLIGHT RETURN AUTO OFF -----|------ 40 OFF OFF OFF RET Figure 3-2 Exposure Exposure describes the brightness-related parameters. You can adjust the image brightness by the SHUTTER, AGC, SENS-UP, BRIGHTNESS, ACCE, BACKLIGHT, etc. in different light conditions. 3.2.1 Shutter Shutter denotes the speed of the shutter.
HD-SDI Camera·User Manual 3.2.2 AGC It’s a form of amplification where the camera will automatically boost the image received in much lower light conditions than standard in order to optimize the clarity of image in poor light scene. OFF, LOW, MIDDLE, and HIGH are selectable for the AGC value. Note: The noise will be amplified if the AGC is on. 3.2.3 SENS-UP SENS-UP increases the exposure on a signal frame, which makes a camera more sensitive to light so it can produce images even in low lux conditions.
HD-SDI Camera·User Manual 3.2.6 Defog DEFOG is used in special environment such as fog or rain or in high illumination, which have lower dynamic range than ordinary environment. OFF, LOW, MIDDLE, and HIGH are selectable. 3.2.7 Backlight You can set the Backlight to OFF, BLC, and HSBLC. Backlight Compensation (BLC) If there’s a strong backlight, the object in front of the backlight will appear silhouetted or dark.
HD-SDI Camera·User Manual 3. Press the OK button up/down/left/right to define the BLC size. 4. Press OK to confirm the selection. ↑ ← POSITION→ ↓ Figure 3-4 Define a BLC Area HSBLC HSBLC SELECT DISPLAY LEVEL MODE BLACK MASK DEFAULT RETURN AREA 1 ON ---|------ 40 ALL DAY ON RET Figure 3-5 HSBLC HSBLC masks strong light sources that usually flare across a scene. This makes it possible to see the detail of the image that would normally be hidden.
HD-SDI Camera·User Manual 1. Select HSBLC by setting the OK button to left/right, and press OK to enter the edit interface. 2. Move the cursor to SELECT and select the area by pressing the OK button to left/right. Four areas are selectable. 3. Set the display as ON to display the HLC area. 4. Press OK button to enter the position/size edit interface. 5. Press the OK button up/down/left/right to define the position/size. 6. Press OK button to confirm the configuration.
HD-SDI Camera·User Manual 3.2.8 White Balance (WB) White balance is the white rendition function of the camera to adjust the color temperature according to the environment. It can remove the unrealistic color casts in the image INDOOR, OUTDOOR, MANUAL, ATW (Auto-tracking White Balance), AWC→SET are selectable. INDOOR Indoor mode is applicable to the environment whose color temperature change is relatively slight.
HD-SDI Camera·User Manual ATW ATW mode means the white balance is continuously being adjusted in real-time according to the color temperature of the scene illumination. AWC→SET The camera will adjust the white balance according to a certain environment. If the environment is changed, you need to use AWC→SET to adjust the color temperature again. 3.3 Day & Night Color, B/W, and EXT are selectable for DAY and NIGHT switches. COLOR The image is color in color mode all the time.
HD-SDI Camera·User Manual 3.4 NR NR (Noise Reduction) is used to reduce the noise in the video stream. Move the cursor to NR, and press confirm to enter the NR submenu. 2D&3D NR 2DNR 3DNR LEVEL SMART NR RETURN OFF ON ---|------ 50 ON RET Figure 3-7 NR 2D NR: 2D NR reduces the noise in a single frame to get a gentle image. You can set it ON or OFF by pressing the OK button left/right.
HD-SDI Camera·User Manual 3D NR S-LEVEL E-LEVEL RETURN |--------- 0 |--------- 0 RET Figure 3-8 3D NR The NR Level ranges from 0 to 100. SMART NR Smart NR usually takes effect in cooperation with 3D NR. You can set it to ON to improve the image fluency. And set it to OFF to disable the SMART NR. 3.5 SPECIAL In the SPECIAL sub-menu, you can set the camera name, the digital effect of the image, the motion detection, privacy task, language, dead pixel correction, and check the version of the camera.
HD-SDI Camera·User Manual SPECIAL ON CAM TITLE D-DFFECT MOTION PRIVACY LANGUAGE DEFECT RS485 VERSION RETURN OFF OFF ENG 121005 RET Figure 3-9 Special 3.5.1 Camera Title You can name your camera by configuring the CAM TITLE. Move the cursor to CAM TITLE, set it to ON, and press OK button to enter the edit interface. Up to 15 characters can be selected. OFF: The camera title will not be displayed. ON: The camera title will be displayed.
HD-SDI Camera·User Manual 1. Move the cursor to ←or →, and press OK button to decide the character position on the dotted line. 2. Move the cursor to select the needed characters, numbers, and symbols. 3. Press OK button to confirm. The selected character will be displayed on the dotted line below. 4. Move the cursor to POS to edit the camera title position on the screen. 1). Move the cursor to POS. 2). Press OK button to enter the CAM TITLE position setting interface. 3).
HD-SDI Camera·User Manual FREEZE You can set the freeze function as ON or OFF. When you set it as on, the image is frozen as still. The live view will stay on the moment you set the freeze ON. Note: The mirror function will be disabled if the FREEZE is ON. MIRROR This series of camera supports MIRROR function. OFF, MIRROR, V-FLIP, and ROTATE are selectable. OFF: The mirror function is disabled. MIRROR: The image flips 180 degree horizontally V-FLIP: The image flips 180 degree vertically.
HD-SDI Camera·User Manual MOTION SELECT DISPLAY SENSITIVITY MOTION VIEW DEFAULT RETURN AREA 1 ON ----|---- 30 ON RET Figure 3-12 Motion Detection Set a Motion Detection Area: Steps: 1. Move the cursor to DISPLAY, and press OK button to enter the motion detection edit interface. 2. Press the OK button to up/down/left/right to define the position of the selected motion area. 3. Press OK button again to enter the area size configuration interface after the position is defined. 4.
HD-SDI Camera·User Manual DISPLAY Display the selected motion area or not. SENSITIVITY The sensitivity of the motion detection. The sensitivity value ranges from 0 to 60, and the higher the sensitivity causes the better response of the detection. MOTION VIEW You can choose whether to show the motion view. When you choose ON, once motion occurred, you can see the transparent red mosaic flickering to show the exact location where the motion occurs. DEFAULT Restore the settings of motion detection.
HD-SDI Camera·User Manual Set a Privacy Area: Steps: 1. Move the cursor to DISPLAY, and press OK button to enter the privacy mask edit interface. 2. Press the OK button to up/down/left/right to define the position of the selected privacy mask area. 3. Press OK button again to enter the area size configuration interface after the position is defined. 4. Press the OK button up/down/left/right to define the size of the selected area. 5.
HD-SDI Camera·User Manual 3.5.6 Defect DEFECT LIVE DPC LEVEL STATIC DPC START LEVEL SENS-UP RETURN ON ---|-----30 ON ---|-----25 X8 RET Figure 3-14 Dead Pixel Correction LIVE DPC You can choose ON, OFF and AUTO. If auto is selected, the level is not configurable. LEVEL The level of the LIVE DPC, which ranges from 0 to 60. STATIC DPC You can set the static DPC as ON or OFF. START Start to correct the dead pixels.
HD-SDI Camera·User Manual SENS-UP Adjust the sensor. X2, X4, X6, X8, X10, X15, X20, X30, and X60 are selectable. 3.5.7 RS485 If you want to configure the menu items remotely, you have to set the RS485 parameters of control device the same as those of camera. RS485 CAM ID ID DISPLAY BAUDRATE RETURN 1 OFF 38400 RET Figure 3-15 RS485 Camera ID ranges from 0 to 255, which is used to recognize the corresponding camera. You can set the camera ID to ON/OFF to display the camera ID or not.
HD-SDI Camera·User Manual 3.6 ADJUST In the Adjust sub-menu, you can set the sharpness, the image quality on monitor, the OSD settings, the Lens Shadow Compensation, and the Video output standard. ADJUST LCD OFF PAL RET SHARPNESS MONITOR OSD LSC NTSC/PAL RETURN Figure 3-16 Adjust 3.6.
HD-SDI Camera·User Manual Sharpness determines the amount of detail an imaging system can reproduce. You can set the sharpness as ON and OFF, when sharpness is on, the images appears clearer and sharper. LEVEL The sharpness level is between 0 and 100. RESOLUTION You can set the resolution as ON and OFF. 3.6.2 Monitor Monitor CRT, and Monitor LCD are selectable.
HD-SDI Camera·User Manual RED GAIN 0 to 100 are selectable. MONITOR LCD USER 1 ----|----50 ----|----50 RET GAMMA BLUE GAIN RED GAIN RETURN Figure 3-19 Monitor LCD GAMMA Gamma is the name of a nonlinear operation used to code and decode luminance or tristimulus values in video or still image system 1.00, 0.95, 0.90, 0.85, 0.80, 0.75, 0.70, 0.65, 0.60, 0.55, 0.50, 0.45, USER1, USER2, and AUTO are selectable. BLUE GAIN The value of the blue gain is between 0 and 100.
HD-SDI Camera·User Manual 3.6.3 OSD OSD 1 ON RET TEXT COLOR OUTLINE RETURN Figure 3-20 OSD Configuration TEXT COLOR There are 8 colors configurable for the OSD menu. Press the OK button to Left or right to change the color of the OSD. OUTLINE You can set whether there is an outline of the text. Press the OK button left or right to set it ON or OFF. 3.6.4 LSC Lens Shading Correction (LSC) corrects the phenomenon where the image gets darkened or blurred on the periphery. ON and OFF are selectable.
HD-SDI Camera·User Manual NTSC, short for the National Television System Committee, is the analog television system that is used in most of North America, parts of South America Myanmar, South Korea, etc. 3.7 RESET Reset all the settings to the factory default. 3.8 EXIT Move the cursor to EXIT and click OK button to exit from the menu.
