Mini Network Speed Dome User Manual UD.
User Manual of Network Speed Dome 1 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to Network Speed Dome. This manual may contain several technical or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. The pictures in the manual are for reference only.
User Manual of Network Speed Dome 2 Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
User Manual of Network Speed Dome 3 Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
User Manual of Network Speed Dome 4 Cautions: Make sure the power supply voltage is correct before using the product. Do not drop the product or subject it to physical shock. Do not install the product on vibratory surface or places. Do not expose it to high electromagnetic radiating environment. Do not aim the lens at the strong light such as sun or incandescent lamp. The strong light can cause fatal damage to the product.
User Manual of Network Speed Dome 5 Table of Contents Chapter 1 Overview .................................................................................................................... 7 1.1 System Requirement ................................................................................................................ 7 1.2 Functions.................................................................................................................................. 7 Chapter 2 2.
User Manual of Network Speed Dome 6 6.3.4 Configuring DDNS Settings................................................................................................. 45 6.3.5 Configuring SNMP Settings ................................................................................................ 47 6.3.6 Configuring 802.1X Settings ............................................................................................... 49 6.3.7 Configuring QoS Settings .......................................
User Manual of Network Speed Dome 7 Chapter 1 Overview 1.1 System Requirement System requirement of web browser accessing is as follows: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 7.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 5 and above version and Google Chrome8 and above versions.
User Manual of Network Speed Dome 8 wide. 3D Positioning In the client software, use the left key of mouse to click on the desired position in the video image and drag a rectangle area in the lower right direction, then the dome system will move the position to the center and allow the rectangle area to zoom in. Use the left key of mouse to drag a rectangle area in the upper left direction to move the position to the center and allow the rectangle area to zoom out.
User Manual of Network Speed Dome 9 the focus and iris are in auto status during the pattern is being memorized. Power Off Memory The dome supports the power off memory capability with the predefined resume time. It allows the dome to resume its previous position after power is restored. Scheduled Task A time task is a preconfigured action that can be performed automatically at a specific date and time.
10 User Manual of Network Speed Dome Chapter 2 Network Connection Before you start: If you want to set the network speed dome via a LAN (Local Area Network), please refer to Section 2.1 Setting the Network Speed Dome over the LAN. If you want to set the network speed dome via a WAN (Wide Area Network), please refer to Section 2.2 Setting the Network Speed Dome over the WAN. 2.
11 User Manual of Network Speed Dome Network Cable Speed Dome Switch or Router PC Figure 2-2 Connecting via a Switch or a Router 2.1.2 Detecting and Changing the IP Address You need the IP address to visit the network speed dome. Steps: 1.
12 User Manual of Network Speed Dome Figure 2-3 SADP Interface 2.2 Setting the Network Speed Dome over the WAN Purpose: This section explains how to connect the network speed dome to the WAN with a static IP or a dynamic IP. 2.2.1 Static IP Connection Before you start: Please apply a static IP from an ISP (Internet Service Provider). With the static IP address, you can connect the network speed dome via a router or connect it to the WAN directly.
User Manual of Network Speed Dome 13 the internet. Figure 2-4 Accessing the Speed Dome through Router with Static IP Connecting the network speed dome with static IP directly You can also save the static IP in the speed dome and directly connect it to the internet without using a router. Refer to Section 2.1.2 Detecting and Changing the IP Address for detailed IP address configuration of the speed dome. Figure 2-5 Accessing the Speed Dome with Static IP Directly 2.2.
User Manual of Network Speed Dome 14 Connecting the network speed dome via a modem Purpose: This speed dome supports the PPPoE auto dial-up function. The speed dome gets a public IP address by ADSL dial-up after the speed dome is connected to a modem. You need to configure the PPPoE parameters of the network speed dome. Refer to Section 6.3.3 Configuring PPPoE Settings for detailed configuration.
User Manual of Network Speed Dome 15 Private Domain Name Resolution Figure 2-8 Private Domain Name Resolution Steps: 1. Install and run the IP Server software in a computer with a static IP. 2. Access the network speed dome through the LAN with a web browser or the client software. 3. Enable DDNS and select IP Server as the protocol type. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration.
16 User Manual of Network Speed Dome Chapter 3 Access to the Network Speed Dome 3.1 Accessing by Web Browsers Steps: 1. Open the web browser. 2. In the address field, input the IP address of the network speed dome, e.g., 192.0.0.64 and press the Enter key to enter the login interface. 3. Select English as the interface language on the top-right of login interface. 4. Input the user name and password and click . The default user name is admin, password is 12345. Figure 3-1 Login Interface 5.
User Manual of Network Speed Dome Figure 3-2 Download and Install Plug-in Figure 3-3 Install Plug-in (2) Figure 3-4 Install Plug-in (3) © Hikvision 17
User Manual of Network Speed Dome 18 You may have to close the web browser to install the plug-in. Please reopen the web browser and log in again after installing the plug-in. 3.2 Accessing by Client Software The product CD contains the client software. You can view the live video and manage the speed dome with the client software. Follow the installation prompts to install the client software and WinPcap. The configuration interface and live view interface of client software are shown bellow.
User Manual of Network Speed Dome 19 Figure 3-6 iVMS-4200 PCNVR Live View Interface If you use third party VMS software, please contact technical support of our branch for camera firmware. For detailed information about client software of our company, please refer to the user manual of the software. This manual mainly introduces accessing to the network speed dome by web browser.
User Manual of Network Speed Dome 20 Chapter 4 Live View 4.1 Live View Page Purpose: The live video page allows you to view live video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network speed dome to enter the live view page, or you can click on the menu bar of the main page to enter the live view page.
21 User Manual of Network Speed Dome Descriptions of the live view page: Menu Bar Click to show or hide PTZ control panel Live View Parameters PTZ control Live view window Preset/patrol/pattern Toolbar Figure 4-1 Live View Page Menu Bar: Click each tab to enter Live View, Playback, Log and Configuration page respectively. Live View Window: Display the live video. Toolbar: Operations on the live view page, e.g., live view, capture, record, audio on/off, two-way audio, etc.
22 User Manual of Network Speed Dome Figure 4-2 Start Live View Table 4-1 Descriptions of the Toolbar Icon Description Icon Live view on Description Live view off Manually capture the pictures Manual recording off Manual recording on Audio on and adjust volume Mute Two-way audio off Two-way audio on 3D zoom Before using the two-way audio or recording with audio functions, please set the Stream Type to Video & Audio referring to Section 6.4.1 Configuring Video Settings.
23 User Manual of Network Speed Dome Hold down the left mouse button and drag the mouse to the upper left on the live video. The corresponding position will be moved to the center of the live video and zoomed out. Please refer to the following sections for more information: Configuring remote recording in Section 7.2 Configuring Recording Schedule. Setting the image quality of the live video in Section 6.1 Configuring Local Parameters and Section 6.4.1 Configuring Video Settings.
24 User Manual of Network Speed Dome Figure 4-3 PTZ Control Panel Table 4-2 Descriptions of PTZ Control Panel Button Description Zoom in/out Focus near/far Iris Open/Close Adjust speed of pan/tilt movements 4.4.2 Setting / Calling a Preset Purpose: A preset is a predefined image position. For the defined preset, you can click the calling button to quickly view the desired image position. Setting a Preset: Steps: 1. In the PTZ control panel, select a preset number from the preset list.
25 User Manual of Network Speed Dome 3. Click to finish the setting of the current preset. 4. You can click to delete the preset. You can configure up to 256 presets. Calling a Preset: In the PTZ control panel, select a defined preset from the list and click preset. to call the Figure 4-5 Calling a Preset For convenient preset selection, refer to the following steps to navigate to the preset you want. Steps: 1. Select any preset from the list. 2. Click the preset number you need on the keyboard.
26 User Manual of Network Speed Dome 39 40 41 42 43 44 45 92 IR cut filter in IR cut filter out Call pattern 1 Call pattern 2 Call pattern 3 Call pattern 4 One-touch patrol Start to set limit stops 100 101 102 103 104 105 106 107 108 Start tilt scan Start panorama scan Call patrol 5 Call patrol 6 Call patrol 7 Call patrol 8 Fan On Fan Off Fan On By Temperature Control Figure 4-6 Special Preset When you calling preset 45 (one-touch patrol), the speed dome patrols from the preset 1 to 32.
27 User Manual of Network Speed Dome Figure 4-7 Adding Presets 4. Configure the preset number, patrol time and patrol speed. Name Description Patrol Time It is the duration staying on one patrol point. The speed dome moves to another patrol point after the patrol time. Patrol Speed It is the speed of moving from one preset to another. 5. Click to save a preset into the patrol. 6. Repeat the steps from 3 to 5 to add more presets. 7. Click to save all the patrol settings.
28 User Manual of Network Speed Dome Buttons on the Patrols interface: Buttons Description Save a patrol Call a patrol Stop a patrol Enter the adding interface of preset Modify a preset Delete a preset Delete all the presets in one patrol 4.4.4 Setting / Calling a Pattern Purpose: A pattern is a memorized series of pan, tilt, zoom, and preset functions. It can be called on the pattern settings interface. There are up to 4 patterns for customizing. Setting a Pattern: Steps: 1.
29 User Manual of Network Speed Dome Buttons on the Patterns interface: Buttons Description Start to record a pattern. Stop recording a pattern. Call the current pattern. Stop the current pattern. Delete the current pattern. These 4 patterns can be operated separately and with no priority level. When configuring and calling the pattern, proportional pan is valid; the limit stops and auto flip will be invalid; and the 3D positioning operation is not supported. 4.
User Manual of Network Speed Dome 30 Chapter 5 PTZ Configuration 5.1 Configuring Initial Position Purpose: The initial position is the origin of PTZ coordinates. It can be the factory default initial position. You can also customize the initial position according to your own demand. Customize an Initial Position: Steps: 1. Enter the Initial Position Configuration interface: Configuration > Advanced Configuration > PTZ > Initial Position Figure 5-1 PTZ Configuration 2.
User Manual of Network Speed Dome 31 5.2 Configuring Basic PTZ Parameters Purpose: You can configure the basic PTZ parameters, including proportional pan, preset freezing, preset speed, etc. 1. Enter the Basic PTZ Parameter Configuration interface: Configuration > Advanced Configuration > PTZ > Basic Figure 5-2 Basic PTZ Configuration Interface 2.
User Manual of Network Speed Dome 32 PTZ OSD: Set the on-screen display duration of the PTZ status. Zoom Status: Set the OSD duration of zooming status as 2 seconds, 5 seconds, 10 seconds, Always Close or Always Open. PT Status: Set the azimuth angle display duration while panning and tilting as 2 seconds, 5 seconds, 10 seconds, Always Close or Always Open.
User Manual of Network Speed Dome 33 2. Click the checkbox of Enable Limit and choose the limit type as manual stops or scan stops. Manual Stops: When manual limit stops are set, you can operate the PTZ control panel manually only in the limited surveillance area. Scan Stops: When scan limit stops are set, the random scan, frame scan, auto scan, tilt scan, panorama scan is performed only in the limited surveillance area. Manual Stops of Limit Type is prior to Scan Stops.
User Manual of Network Speed Dome 34 2. Check the checkbox of Enable Scheduled Task. 3. Set the Park Time. You can set the park time (a period of inactivity) before the dome starts the scheduled tasks. 4. Set the schedule and task details. Steps: (1) Click to edit the task schedule. Figure 5-5 Edit the Schedule and Task Type (2) Choose the day you want to set the task schedule.
35 User Manual of Network Speed Dome Figure 5-6 Task Types (5) After you set the scheduled task, you can copy the task to other days (Optional). (6) Click to save the settings. The time of each task can’t be overlapped. Up to 10 tasks can be configured for each day. 5. Click to save the settings. 5.5 Configuring Park Actions Purpose: This feature allows the dome to start a predefined park action (scan, preset, pattern and etc.) automatically after a period of inactivity (park time).
36 User Manual of Network Speed Dome 3. Set the Park Time as the inactivity time of the dome before it starts the park actions. 4. Choose Action Type the from the drop-down list. Figure 5-8 Action Types 5. Click to save the settings. 5.6 Configuring Privacy Mask Purpose: Privacy mask enables you to cover certain areas on the live video to prevent certain spots in the surveillance area from being live viewed and recorded. Steps: 1.
37 User Manual of Network Speed Dome 3. Click ; click and drag the mouse in the live video window to draw 4. the area. You can drag the corners of the red rectangle area to draw a polygon mask. 5. Click to finish drawing or click to clear all of the areas you set without saving them. 6. Click to save the privacy mask, and it will be listed in the Privacy Mask List area; you can select a mask and click to delete it from the list. Figure 5-10 Privacy Mask List 7.
User Manual of Network Speed Dome 38 Chapter 6 Speed Dome Configuration 6.1 Configuring Local Parameters The local configuration refers to the parameters of the live view and other operations using the web browser. Steps: 1. Enter the Local Configuration interface: Configuration > Local Configuration Figure 6-1 Local Configuration Interface 2. Configure the following settings: Live View Parameters: Set the protocol type, stream type, image size and live view performance.
39 User Manual of Network Speed Dome MULTICAST: It’s recommended to select the protocol type to when using the Multicast function. For other information about Multicast, refer to Section 6.3.1 Configuring TCP/IP Settings. Live View Performance: Set the live view performance to Least Delay, Balanced or Best Fluency. Please set Live View Performance as Best Fluency for the high frame rate speed dome. Rules: You can enable or disable the rules of dynamic analysis for motion here.
40 User Manual of Network Speed Dome Time(DST) functions for setting the time. Time Synchronization consists of auto mode by Network Time Protocol(NTP) server and manual mode. To enter the Time Settings interface: Configuration > Basic Configuration > System > Time Settings Or Configuration > Advanced Configuration > System > Time Settings Figure 6-2 Time Settings Configuring Time Synchronization by NTP Server Steps: (1) Check the radio button to enable the NTP function.
User Manual of Network Speed Dome 41 Address: 210.72.145.44). If the speed dome is set in a customized network, NTP software can be used to establish a NTP server for time synchronization. Configuring Time Synchronization Manually Steps: (1) Check the Manual Time Sync radio button. (2) Click to set the system time from the pop-up calendar. (3) Click to save the settings. You can also check the Sync with local time checkbox to synchronize the time of the speed dome with the time of your computer.
42 User Manual of Network Speed Dome If there is the habit of adjusting clocks forward in your country in certain time period of a year, you can turn this function on. The time will be adjusted automatically when the Daylight Saving Time(DST) comes. Steps: (1) Enter the DST interface by Configuration > Advanced Configuration > System > DST (2) Check to enable the DST function. (3) Set the date of the DST period. (4) Click to save the settings. Figure 6-6 DST Settings 6.
43 User Manual of Network Speed Dome Figure 6-7 TCP/IP Settings 2. Configure the NIC settings, including the IPv4(IPv6) Address, IPv4(IPv6) Subnet Mask and IPv4(IPv6) Default Gateway. 3. Click to save the above settings. If the DHCP server is available, you can check to automatically obtain an IP address and other network settings from that server. The valid value range of Maximum Transmission Unit(MTU) is 500 ~ 1500. The default value is 1500.
44 User Manual of Network Speed Dome The router must support the route advertisement function if you select Route Advertisement as the IPv6 mode. 6.3.2 Configuring Port Settings Purpose: If there is a router and you want to access the speed dome through Wide Area Network (WAN), you need to forward the 3 ports for the speed dome. Steps: 1.
User Manual of Network Speed Dome 45 Configuration >Advanced Configuration > Network > PPPoE Figure 6-10 PPPoE Settings 2. Check the Enable PPPoE checkbox to enable this feature. 3. Enter User Name, Password, and Confirm password for PPPoE access. The User Name and Password should be assigned by your ISP. 4. Click to save and exit the interface. 6.3.
User Manual of Network Speed Dome 46 Figure 6-11 DDNS Settings 2. Check the Enable DDNS checkbox to enable this feature. 3. Select DDNS Type. Three DDNS types are selectable: IPServer, HiDDNS, NO-IP and DynDNS. DynDNS: Steps: (1) Enter Server Address of DynDNS (e.g. members.dyndns.org). (2) In the Domain text field, enter the domain name obtained from the DynDNS website. (3) Enter the Port of DynDNS server. (4) Enter the User Name and Password registered on the DynDNS website.
User Manual of Network Speed Dome 47 The Server Address should be entered with the static IP address of the computer that runs the IP Server software. For the IP Server, you have to apply a static IP, subnet mask, gateway and preferred DNS from the ISP. Figure 6-13 IPServer Settings HiDDNS: Steps: (1) Enter the Server Address: www.hik-online.com. (2) Enter the Domain name of the camera. The domain is the same with the device alias in the HiDDNS server. (3) Click to save the settings.
48 User Manual of Network Speed Dome speed dome information via SNMP port. By setting the Trap Address, the speed dome can send the alarm event and exception messages to the surveillance center. The SNMP version you select should be the same as that of the SNMP software. Steps: 1. Enter the SNMP Settings interface: Configuration > Advanced Configuration > Network > SNMP Figure 6-15 SNMP Settings 2. Check the corresponding version checkbox ( , , ) to enable the feature. 3. Configure the SNMP settings.
49 User Manual of Network Speed Dome 6.3.6 Configuring 802.1X Settings Purpose: The speed dome supports IEEE 802.1X standard. IEEE 802.1X is a port-based network access control. It enhances the security level of the LAN. When devices connect to this network with IEEE 802.1X standard, the authentication is needed. If the authentication fails, the devices don’t connect to the network. The protected LAN with 802.
50 User Manual of Network Speed Dome 1. Connect the network camera to your PC directly with a network cable. 2. Enter the 802.1X Settings interface: Configuration > Advanced Configuration > Network > 802.1X Figure 6-17 802.1X Settings 3. Check the Enable IEEE 802.1X checkbox to enable it. 4. Configure the 802.1X settings, including user name and password. The EAP-MD5 version must be identical with that of the router or the switch. 5.
51 User Manual of Network Speed Dome 2. Configure the QoS settings, including video / audio DSCP, event / alarm DSCP and Management DSCP. The valid DSCP value ranges from 0 to 63. The DSCP value is bigger, the priority is higher. 3. Click to save the settings. Make sure that you enable the QoS function of your network device (such as a router). It will ask for a reboot for the settings to take effect. 6.3.
User Manual of Network Speed Dome 52 Figure 6-20 Parent Directory Child directory: It is a sub-folder which can be created in the parent directory. The files will be saved in a sub-folder in FTP server. The name of folder can be defined as shown in following Figure 6-21. Figure 6-21 Child Directory Upload type: To enable uploading the captured picture to the FTP server. 3. Click to save the settings.
User Manual of Network Speed Dome 53 6.3.10 Configuring NAT (Network Address Translation) Settings Steps: 1. Set the port mapping mode: To port mapping with the default port numbers: Choose To port mapping with the customized port numbers: Choose And you can customize the value of the port number by yourself. 2. Click to save the settings. 6.3.11 Configuring Email Settings Purpose: The system can be configured to send an Email notification to all designated receivers if an alarm event is detected, e.g.
User Manual of Network Speed Dome 54 Figure 6-23 Email Settings 2. Configure the following settings: Sender: The name of the email sender. Sender’s Address: The email address of the sender. SMTP Server: The SMTP Server IP address or host name (e.g., smtp.263xmail.com). SMTP Port: The SMTP port. The default TCP/IP port for SMTP is 25. Enable SSL: Check the checkbox to enable SSL if it is required by the SMTP server.
User Manual of Network Speed Dome 55 Authentication (optional): If your email server requires authentication, check this checkbox to use authentication to log in to this server and enter the login user name and password. Receiver: Select the receiver to which the email is sent. Up to 2 receivers can be configured. Receiver: The name of the user to be notified. Receiver’s Address: The email address of user to be notified. 3. Click © Hikvision to save the settings.
User Manual of Network Speed Dome 56 6.4 Configuring Video and Audio Settings 6.4.1 Configuring Video Settings Steps: 1. Enter the Video Settings interface: Configuration >Basic Configuration > Video / Audio > Video Or Configuration > Advanced Configuration > Video / Audio > Video Figure 6-24 Configure Video Settings 2. Select the Stream Type of the speed dome to main stream (normal) or sub-stream.
User Manual of Network Speed Dome 57 When bitrate type is selected as Variable, 6 levels of video quality are selectable. Frame Rate: The frame rate is to describe the frequency at which the video stream is updated and it is measured by frames per second (fps). A higher frame rate is advantageous when there is movement in the video stream, as it maintains image quality throughout. Max. Bitrate: Set the max. bitrate to 32~12288Kbps.
User Manual of Network Speed Dome 58 6.4.3 Configuring ROI Settings Before you start: ROI (Region of Interest) encoding is used to enhance the quality of images which are specified in advance. Stream Type: You can set the ROI function for main stream or sub stream. Select a stream type and then configure the ROI settings. Fixed Region: The fixed region encoding is the ROI encoding for the manually configured area.
User Manual of Network Speed Dome 59 Figure 6-26 Region of Interest 6.5 Configuring Image Settings 6.5.1 Configuring Display Settings Purpose: You can set the image quality of the speed dome, including brightness, contrast, saturation, sharpness, etc. The parameters in Display Settings interface vary depending on the models of speed dome. You can double click the live view to enter full screen mode and double click it again to exit. Steps: 1.
User Manual of Network Speed Dome 60 Figure 6-27 Display Settings Image Adjustment Brightness This feature is used to adjust brightness of the image. The value ranges from 0 to 100. Contrast This feature enhances the difference in color and light between parts of an image. The value ranges from 0 to 100. Saturation This feature is used to adjust color saturation of the image. The value ranges from 0 to 100.
61 User Manual of Network Speed Dome The Exposure Mode can be set to Auto, Iris Priority, Shutter Priority, Manual. Auto: The iris, shutter and gain values will be adjusted automatically according to the brightness of the environment. Iris Priority: The value of iris needs to be adjusted manually. The shutter and gain values will be adjusted automatically according to the brightness of the environment. Figure 6-28 Manual Iris Shutter Priority: The value of shutter needs to be adjusted manually.
62 User Manual of Network Speed Dome Auto: The speed dome focuses automatically at any time according to objects in the scene. Semi-auto: The speed dome focuses automatically only once after panning, tilting and zooming. Manual: In Manual mode, you need to use on the control panel to focus manually. Min. Focus Distance This function is used to limit the minimum focus distance. The value can be set to 1.5m, 3m, 6m, 10cm and 50cm.
63 User Manual of Network Speed Dome Only the IR speed domes support IR Light Mode. When the IR Light Mode is auto, the day/night mode is adjusted automatically according to the IR Light Mode. Manually setting the day/night mode is invalid. When the IR Light Mode is manual and the IR Light Bright is 0, you can set the day/night mode manually. When the IR Light Mode is manual and the IR Light Bright is not 0, the night mode is set as the default mode.
User Manual of Network Speed Dome 64 demand as shown in Figure 6-34. Figure 6-34 Manual White Balance Outdoor You can select this mode when the speed dome is installed in outdoor environment. Indoor You can select this mode when the speed dome is installed in indoor environment. Fluorescent Lamp You can select this mode when there are fluorescent lamps installed near the speed dome. Sodium Lamp You can select this mode when there are sodium lamps installed near the speed dome.
User Manual of Network Speed Dome 65 You can set the Video Standard to 50hz(PAL) or 60hz(NTSC) according to the video system in your country. This function varies depending on the models of speed dome. Capture Mode You can disable this function or set the value as 1280*720@30fps or 1280*960@30fps. This function varies depending on the models of speed dome. Other Lens Initialization The lens operates the movements for initialization when you check the check box of Lens Initialization.
66 User Manual of Network Speed Dome Figure 6-36 OSD Settings 2. Check the corresponding checkbox to select the display of speed dome name, date or week if required. 3. Edit the speed dome name in the text field of Camera Name. 4. Select from the drop-down list to set the time format, date format and display mode. 5. You can use the mouse to click and drag the text frame view window to adjust the OSD position.
67 User Manual of Network Speed Dome 6. Click to activate above settings. 6.5.3 Configuring Text Overlay Settings Purpose: You can customize the text overlay. Steps: 1. Enter the Text Overlay Settings interface: Configuration > Advanced Configuration > Image > Text Overlay 2. Check the checkbox in front of textbox to enable the on-screen display. 3. Input the characters in the textbox. 4. Use the mouse to click and drag the red text frame in the live view window to adjust the text overlay position. 5.
User Manual of Network Speed Dome 68 6.6 Configuring and Handling Alarms Purpose: This section explains how to configure the network speed dome to respond to alarm events, including motion detection, video tampering and exception. These events can trigger the alarm actions, such as Notify Surveillance Center, Send Email, Trigger, etc. For example, when motion detection is triggered, the network speed dome sends a notification to an e-mail address. 6.6.
69 User Manual of Network Speed Dome Figure 6-39 Enable Motion Detection (3) Click . Click and drag the mouse on the live video image to draw a motion detection area. You can draw up to 8 motion detection areas on the same image. (4) Click to finish drawing. You can click to clear all of the areas. (5) Move the slider detection. 2. Set the Arming Schedule for Motion Detection. Steps: to set the sensitivity of the (1) To edit the arming schedule as shown in Figure 6-41, click in Figure 6-40.
User Manual of Network Speed Dome (5) Click 70 to save the settings. The time of each period can’t be overlapped. Up to 4 periods can be configured for each day. Figure 6-41 Arming Time Schedule 3. Set the Alarm Actions for Motion Detection. Purpose: You can specify the linkage method when an event occurs. The following contents are about how to configure the different types of linkage method. Figure 6-42 Linkage Method Check the checkbox to select the linkage method.
User Manual of Network Speed Dome 71 an event occurs. Send Email Send an email with alarm information to a user or users when an event occurs. To send the Email when an event occurs, you need to refer to Section 6.3.10 Configuring Email Settings to set the Email parameters. Upload to FTP Capture the image when an alarm is triggered and upload the picture to a FTP server. You need a FTP server and set FTP parameters first. Refer to Section 6.3.8 Configuring FTP Settings for setting FTP parameters.
User Manual of Network Speed Dome 72 Figure 6-43 Tampering Alarm 2. Check Enable Video Tampering checkbox to enable the tampering detection. 3. Set the tampering area. Refer to Step 1 Set the Motion Detection Area in Section 6.6.1 Configuring Motion Detection. 4. Click to edit the arming schedule for tampering. The arming schedule configuration is the same as the setting of the arming schedule for motion detection. Refer to Step 2 Set the Arming Schedule for Motion Detection in Section 6.6.
User Manual of Network Speed Dome 73 1. Enter the Exception Settings interface: Configuration > Advanced Configuration> Events > Exception 2. Check the checkbox to set the actions taken for the Exception alarm. Refer to Step 3 Set the Alarm Actions Taken for Motion Detection in Section 6.6.1 Configuring Motion Detection. Figure 6-44 Exception Settings 3. Click © Hikvision to save the settings.
User Manual of Network Speed Dome 74 Chapter 7 Record Settings Before you start: To configure record settings, please make sure that you have the network storage device within the network or the Micro SD card inserted in your speed dome. 7.1 Configuring NAS Settings Before you start: The network disk should be available within the network and properly configured to store the recorded files, log files, etc. Steps: 1.
75 User Manual of Network Speed Dome (1) Enter the HDD Settings interface (Advanced Configuration > Storage > Storage Management), in which you can view the capacity, free space, status, type and property of the disk. (2) If the status of the disk is Uninitialized as shown in Figure 7-3, check the corresponding checkbox to select the disk and click to start initializing the disk.
User Manual of Network Speed Dome 76 are stored in the SD card (if supported) or in the network disk. Steps: 1. Enter the Record Schedule Settings interface: Configuration > Advanced Configuration> Storage > Record Schedule Figure 7-6 Recording Schedule Interface 2. Check the checkbox of Enable Record Schedule to enable scheduled recording. 3. Set the record parameters of the speed dome.
User Manual of Network Speed Dome 77 The Post-record time can be configured as 5 s, 10 s, 30 s, 1 min, 2 min, 5 min or 10 min. Overwrite: If you enable his function and the HDD is full, the new record files overwrite the oldest record files automatically. The Pre-record and Post-record parameters vary depending on the speed dome model. 4. Click to edit the record schedule. Figure 7-8 Record Schedule 5. Choose the day to set the record schedule.
User Manual of Network Speed Dome 78 Record Triggered by Motion Detection If you select Motion Detection, the video will be recorded when the motion is detected. Besides configuring the recording schedule, you have to set the motion detection area and check the checkbox of Trigger Channel in the Linkage Method of Motion Detection Settings interface. For detailed information, please refer to the Step 1 Set the Motion Detection Area in the Section 6.6.1 Configuring Motion Detection.
79 User Manual of Network Speed Dome Figure 7-9 Edit Record Schedule (3) Check the checkbox and click to copy settings of this day to the whole week. You can also check any of the checkboxes before the date and click (4) Click . to save the settings and exit the Edit Record Schedule interface. 6. Click to save the settings. 7.3 Configuring Snapshot Settings Purpose: You can configure the scheduled snapshot and event-triggered snapshot. You can upload the captured pictures to a FTP server.
80 User Manual of Network Speed Dome details to configure FTP parameters. 2) Check the Enable Timing Snapshot checkbox. Upload event-triggered snapshots to FTP Steps: 1) Configure the FTP settings and check checkbox in FTP Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more details to configure FTP parameters. 2) Check checkbox in Motion Detection Settings or Alarm Input interface. Please refer to Step 3 Set the Alarm Actions Taken for Motion Detection in Section 6.
81 User Manual of Network Speed Dome Chapter 8 Playback Purpose: This section explains how to view the remotely recorded video files stored in the network disks or SD cards. Task 1: To play back the video files Steps: 1. Click on the menu bar to enter playback interface. Figure 8-1 Playback Interface 2. Select the date and click .
82 User Manual of Network Speed Dome 3. Click to play the video files found on this date. The toolbar on the bottom of Playback interface can be used to control playing process.
83 User Manual of Network Speed Dome Figure 8-5 Progress Bar The different colors of the video on the progress bar stand for the different video types as shown in Figure 8-6. Figure 8-6 Video Types Task 2: To download the video files Steps: 1. Click on the playback interface. The pop-up menu is shown in Figure 8-7. 2. Set the start time and end time. Click Search. The corresponding video files are listed on the left. Figure 8-7 Video Downloading interface 3. Check the checkbox 4.
84 User Manual of Network Speed Dome to turn pages. Task 3: To download the captured pictures Steps: 1. Click on the playback interface. The pop-up menu is shown in Figure 8-8. 2. Set the linkage type of capturing the pictures as timing, alarm, motion, etc.. 3. Set the start time and end time. Click Search. The corresponding picture files are listed on the left. 4. Check the checkbox 5. Click in front of the files that you need to download. to download the files.
85 User Manual of Network Speed Dome Chapter 9 Log Searching Purpose: The operation, alarm, exception and information of the speed dome can be stored in log files. You can also export the log files on your demand. Before you start: Please configure network storage for the speed dome or insert a SD card in the speed dome. Steps: 1. Click on the menu bar to enter log searching interface. Figure 9-1 Log Searching Interface 2.
User Manual of Network Speed Dome 4. To export the log files, click © Hikvision 86 to save the log files in your computer.
User Manual of Network Speed Dome 87 Chapter 10 Others 10.1 Managing User Accounts Enter the User Management interface: Configuration >Basic Configuration> Security > User Or Configuration > Advanced Configuration> Security > User The admin user has access to create, modify or delete other accounts. Up to 32 user accounts can be created. Figure 10-1 User Information Add a User Steps: 1. Click to add a user. 2. Input the new User Name, select Level and input Password.
88 User Manual of Network Speed Dome Figure 10-2 Add a User Modify a User Steps: 1. Left-click to select the user from the list and click . 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click to finish the user modification.
89 User Manual of Network Speed Dome Figure 10-3 Modify a User Delete a User Steps: 1. Left-click the user name you want to delete and click 2. Click . on the pop-up dialogue box to delete the user.
User Manual of Network Speed Dome 90 10.2 Configuring RTSP Authentication Purpose: You can specifically secure the stream data of live view. Steps: 1. Enter the RTSP Authentication interface: Configuration> Advanced Configuration> Security > RTSP Authentication Figure 10-5 RTSP Authentication 2. Select the Authentication type basic or disable in the drop-down list to enable or disable the RTSP authentication. 3. Click to save the settings. 10.
User Manual of Network Speed Dome 91 Figure 10-7 Login Interface 10.4 Configuring IP Address Filter With this function on, the camera allows certain IP addresses whether to log in or not. Filter Type Description Forbid the IP addresses added in Forbidden the IP Address Filter interface to log in. Allow only the IP addresses Allowed added in the IP Address Filter interface to log in. Figure 10-8 IP Address Filter 10.
User Manual of Network Speed Dome 92 Version, Encoding Version, Number of Channels, Number of HDDs, Number of Alarm Input and Number of Alarm Output are displayed. The information cannot be changed in this menu. It is the reference for maintenance or modification in future. Figure 10-9 Device Information 10.6 Maintenance 10.6.1 Rebooting the Speed Dome Steps: 1.
93 User Manual of Network Speed Dome 1. Enter the Maintenance interface: Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance 2. Click or Clicking to restore the default settings. restores all the parameters to default settings including the IP address and user information. Please use this button with caution. Figure 10-11 Restore Default Settings 10.6.3 Importing/Exporting Configuration File Steps: 1.
User Manual of Network Speed Dome 94 10.6.4 Upgrading the System Steps: 1. Enter the Maintenance interface: Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance 2. Click to select the local upgrade file and then click to start remote upgrade. The upgrading process will take 1 to 10 minutes. Please don't disconnect power of the speed dome during the process. The speed dome reboots automatically after upgrading.
95 User Manual of Network Speed Dome Appendix Appendix 1 SADP Software Introduction Description of SADP SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices. You can also modify the basic network information of the devices using this software.
96 User Manual of Network Speed Dome You can click you can click or on each column heading to order the information; to expand the device table and hide the network parameter panel on the right side, or click to show the network parameter panel. Modify network parameters Steps: 1. Select the device to be modified in the device list and the network parameters of the device will be displayed in the Modify Network Parameters panel on the right side. 2. Edit the modifiable network parameters, e.g.
User Manual of Network Speed Dome 97 Appendix 2 Port Mapping The following settings are for TP-LINK router (TL-R410). The settings vary depending on different models of routers. Steps: 1. Select the WAN Connection Type, as shown below: Figure A.2.1 Select the WAN Connection Type 2. Set the LAN parameters of the router as in the following figure, including IP address and subnet mask settings. Figure A.2.2 Set the LAN parameters 3. Set the port mapping in the virtual severs of Forwarding.
98 User Manual of Network Speed Dome client software. In the speed dome, the 8200~8210 ports change with the 8000 port with a constant value of 200. E.g. if the 8000 port is changed to 8005, then the 8200~8210 ports should be changed to 8205~8215. Example: When the speed domes are connected to the same router, you can forward the ports of a speed dome as 80, 8000, 8200~8210 and 554 with IP address 192.168.1.23, and the ports of another speed dome as 81, 8001, 8201~8211 and 555 with IP 192.168.1.24.
User Manual of Network Speed Dome same as the management port.
