Mobile DVR Quick Start Guide
Mobile Digital Video Recorder (-SD) Quick Start Guide CONTENTS Chapter 1 Installation and Connection ........................................................................................... 6 1.1 Before You Start ................................................................................................................... 6 1.2 Environment ........................................................................................................................ 6 1.3 Install SIM Card .................
Mobile Digital Video Recorder (-SD) Quick Start Guide Quick Start Guide COPYRIGHT © 2018 Hangzhou Hikvision Digital Technology Co., Ltd. ALL RIGHTS RESERVED. Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
Mobile Digital Video Recorder (-SD) Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
Mobile Digital Video Recorder (-SD) Quick Start Guide Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.
Mobile Digital Video Recorder (-SD) Quick Start Guide Safety Instructions Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information.
Mobile Digital Video Recorder (-SD) Quick Start Guide Chapter 1 Installation and Connection 1.1 Before You Start Take out the device from the package. Check the device and accessories status. Please contact us if something is missing or damaged. 1.2 Environment Consider the following environment conditions when installing the device. Anti-vibration Normal vehicle: Install the device on the part with weak vibration (such as the part behind the driver’s seat, the part behind the passenger’s seat, etc.
Mobile Digital Video Recorder (-SD) Quick Start Guide All the screws in the fixing positions must be fastened tightly to avoid device falling during the vibration in driving. 1.3 Install SIM Card Install the 3G/4G SIM card to realize wireless communication. Before you start: Prepare the tools and components for installation: SIM card Key to front panel lock Step 1 Wear antistatic gloves. Step 2 Insert the key and turn counterclockwise to unlock the front panel.
Mobile Digital Video Recorder (-SD) Quick Start Guide Step 1 Wear antistatic gloves. Step 2 Insert the key and turn counterclockwise to unlock the front panel. Step 3 Insert SD card into SD card slot till you hear a click. SD Card Slot Figure 1-3 SD Card Slot Step 4 Cover the front panel, and turn the key clockwise to lock the front panel. 1.5 Install Antenna Connect antennas to corresponding antenna interfaces.
Mobile Digital Video Recorder (-SD) Quick Start Guide Figure 1-4 Positioning Antenna Installation (on Automobile Roof) Follow the instructions below in case that you need to install positioning antenna inside your automobile. Install antenna on platform under the front windshield. Windshield Antenna Figure 1-5 Install Positioning Antenna Inside Automobile Fix antenna with neutral silica gel.
Mobile Digital Video Recorder (-SD) Quick Start Guide Chapter 2 Device Wiring 2.1 Power Cord Wiring In order to ensure the safety of your automobile and device, a fuse is required for wiring of automobile power and device power. Do not connect the power cord to the device before all the cables are connected. 2.1.1 Shutdown Delay Purpose The device starts up when your automobile ignites and shuts down after automobile is off.
Mobile Digital Video Recorder (-SD) Quick Start Guide Fuse DC IN + Fuse Holder DC IN ACC Fuse DC IN + Fuse Holder DC IN ACC Figure 2-1 Install Fuse for Two Types of Power Supply Device ACC Automobile Power System DC IN + Wiring of Device Point of Connection - Automobile Power Switch Negative Pole Automobile Ignition Switch Automobile Battery Figure 2-2 Shutdown Delay 11 Positive Pole
Mobile Digital Video Recorder (-SD) Quick Start Guide Please contact the automobile manufacturer for the connection information of starting switch. The automobile ignition switch, also called car key, controls the startup and shutdown of your automobile. Most of automobiles adopt positive pole ignition switch currently. The normal automobile power refers to the main power of the automobile power supply system.
Mobile Digital Video Recorder (-SD) Quick Start Guide Device ACC Automobile Power System DC IN Wiring of Device Point of Connection + - Automobile Power Switch Positive Pole Negative Pole Automobile Battery Figure 2-4 Scheduled Shutdown 2.2 Alarm Input Connection The device adopts the high/low-level electrical signals triggering (high level: 6 to 36 VDC; low level: 0 to 5 VDC) to realize alarm input.
Mobile Digital Video Recorder (-SD) Quick Start Guide Left-turn Right-turn Reversing 2 16 1 IO 15 Braking Figure 2-6 Sensor-In Wiring 2.4 Power on Device Connect to power supply after all the above installations are finished. You can view the indicators to get knowledge about the device status. The indicator types vary with different models. Here the most comprehensive indicators are introduced. Power indicator (PWR): Solid green: Device is powered on. Solid red: Device is standby.
Mobile Digital Video Recorder (-SD) Quick Start Guide Red: Alarm occurs.
Mobile Digital Video Recorder (-SD) Quick Start Guide Chapter 3 Activation For the first-time access, you need to activate the device by setting an admin password. No operation is allowed before activation. 3.1 Default Settings Device default IP address and user name are as follows: Default IP address: 192.168.1.64. Default user name: admin. 3.
Mobile Digital Video Recorder (-SD) Quick Start Guide Chapter 4 Basic Operation 4.1 Login Purpose: You can get access to the device via web browser. Step 1 Open web browser, input the IP address of the device and then press Enter. Step 2 Enter the user name and password in the login interface and click Login. Figure 4-1 Login Step 3 Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. 4.
Mobile Digital Video Recorder (-SD) Quick Start Guide Figure 4-2 3G/4G Dialing Step 4 Click Save and reboot the device to activate the new settings. Step 5 Optionally, go to Wireless Dial-up Status tab to view dialing status. 4.3 Mobile Surveillance Platform Connection Purpose: The device can be remotely accessed via mobile surveillance platform. For details of platform configuration, you can refer to platform user manual.
Mobile Digital Video Recorder (-SD) Quick Start Guide Figure 4-3 Platform Settings Step 2 Check Enable. Step 3 Select Platform Access Mode as Ehome Platform. Step 4 Configure the following parameters. Server Address Type: IP Address and Domain Name are selectable. Server Address: Enter the static IP address of iVMS server. Server Port: The default value for mobile surveillance platform is 7660. Device ID: The ID of the device registered on the eHome platform.
Mobile Digital Video Recorder (-SD) Quick Start Guide Step 3 Click Activation. Step 4 Enter the same password in New Password and Confirm. Step 5 Click OK. 4.4.2 Add IP Camera You can add the activated IP cameras. Ensure the device and IP cameras are in the same network segment. Before you start: The record and the camera to add must be in the same network segment. Step 1 Go to Configuration > System > Camera Management.
Mobile Digital Video Recorder (-SD) Quick Start Guide Appendix A FAQ A1 Why does my device fail to start up after connecting the power? Check power supply specification. If PWR indicator is unlit, check power supply and fuse installation. A2 Why does my device dialing fail? Check 3G/4G antenna connection. Place 3G/4G antenna away from metal objects. Check your SIM card balance. Ensure 3G/4G dial parameters are correct.
