Data Sheet

DS-1281ZJ-DM25-B

Inclined Ceiling Mount

Feature

 Aluminum alloy with surface spray treatment

 Cable hole design facilitates cable routing

 Applies to fish eye camera

Dimension

161

.03 mm

(6.34" )

164.47 mm (6.48" )

155

.9 mm

(6.14" )

80.11 mm

(3.15" )

100 mm

(3.94" )

56 mm

(2.20" )

46°

Available Model

DS-1281ZJ-DM25-B

Parameter

Model

Parameters

DS-1281ZJ-DM25-B

Inclined Ceiling Mount

Appearance

Hikvision White

Material

Aluminum Alloy

Dimension

155.9 mm × 164.47 mm × 161.03 mm (6.14" × 6.48" × 6.34")

Weight

Approx. 550 g (1.21 lb.)

Note

 The mount should be installed on the flat surface.

 The wall must be capable of supporting at least 3 times as much as the total weight of the camera, and the

mount.

 The maximum load capacity of the mount is 3 kg (6.6 lb.).

0100001080522

PAGE 1
