Title: How to set motion detection recording in SD card for HIKVISION IP camera Cameras Product: Version: v1.0 Date: 12/13/2018 Page: 1 of 8 Preparation 1. 2. SD card under 128GB. Camera supports On-board storage. How to set motion detection recording in SD card for HIKVISION IP camera 1. Install the SD card in camera. © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.
Title: Product: How to set motion detection recording in SD card for HIKVISION IP camera Cameras Version: v1.0 Date: 12/13/2018 Page: 2 of 8 2. Run SADP software and then all IP cameras in same LAN will be shown in software. Configure IP address for camera(Such as 10.9.97.19). 3. Input the IP address (10.9.97.19) in IE browser to login it. © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.
Title: Product: How to set motion detection recording in SD card for HIKVISION IP camera Cameras Version: v1.0 Date: 12/13/2018 Page: 3 of 8 4. Go to Configuration> Advanced configuration> Storage> Storage management, and then format the SD card. © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: support@hikvision.com • www.hikvision.
Title: Product: How to set motion detection recording in SD card for HIKVISION IP camera Cameras Version: v1.0 Date: 12/13/2018 Page: 4 of 8 5. Go to Record Schedule, and then enable Record Schedule. 6. Set the recording type to Motion detection，and select record schedule. © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: support@hikvision.com • www.hikvision.
Title: Product: 7. How to set motion detection recording in SD card for HIKVISION IP camera Cameras Version: v1.0 Date: 12/13/2018 Page: 5 of 8 Click Events>Motion detection, enable it and then set the area. © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: support@hikvision.com • www.hikvision.
Title: Product: How to set motion detection recording in SD card for HIKVISION IP camera Cameras Version: v1.0 Date: 12/13/2018 Page: 6 of 8 8. Set all days of arming, and then enable the Notify Surveillance Center and Trigger Recording. Click Save. © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: support@hikvision.com • www.hikvision.
Title: Product: How to set motion detection recording in SD card for HIKVISION IP camera Cameras Version: v1.0 Date: 12/13/2018 Page: 7 of 8 9. Go to Playback, and then we can search recording in SD card. © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: support@hikvision.com • www.hikvision.
Title: Product: How to set motion detection recording in SD card for HIKVISION IP camera Cameras Version: v1.0 Date: 12/13/2018 Page: 8 of 8 First Choice for Security Professionals HIKVISION Technical Support © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: support@hikvision.com • www.hikvision.
