Data Sheet
DS-2CD5585G1-IZ(H)S
8 MP IR Varifocal Dome Network Camera
●
1/1.8” Progressive Scan CMOS
●
3840 × 2160 @ 30fps
●
MJPEG up to 1920 × 1080 @ 30fps
●
2.8 to 12 mm/8 to 32 mm motorized lens
●
Color: 0.007 Lux @ (F1.2, AGC ON), 0.016 Lux @ (F1.8,
AGC ON), 0 Lux with IR
●
H.265, H.265+, H.264, H.264+
●
120dB WDR
●
2.8 to 12 mm lens: IR range up to 30 m, 8 to 32 mm lens:
IR range up to 50 m
●
Alarm 1 input/1 output, audio 1 input/1 output
●
Anti-IR Reflection
●
IP67, IK10
●
5 streams and up to 5 custom streams
●
6 behavior analyses, 3 exception detection, and face
detection
●
Built-in microSD/SDHC/SDXC card slot, up to 256 GB
●
Metadata of intrusion detection, line crossing detection,
region entrance detection, region exiting detection,
unattended baggage detection, and object removal are
supported.
