Data Sheet

Specifications
Camera
Image Sensor
1/1.8ʺ Progressive Scan CMOS
Min. Illumination
Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed
1 s to 1/100,000 s
Slow Shutter
Yes
Day & Night
IR cut filter
WDR
140 dB
Angle Adjustment
Bracket, pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type
Motorized lens, 2.8 to 12 mm
Aperture
F1.2 to 2.5
Focus
Auto, semi auto, manual
Auto-Iris
P-iris
FOV
Horizontal FOV 109.2° to 38.9°, vertical FOV 56.2° to 21.9°, diagonal FOV 134.5° to 45°
Lens Mount
Integrated
Illuminator
IR Range
Up to 50 m
Wavelength
850 nm
Video
Max. Resolution
2560 × 1440
Video Stream
5 defined streams and up to 5 custom stream
Main Stream
50Hz: 25fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 30fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Third Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub stream/third stream/fourth stream/fifth stream/custom stream:
H.265/H.264/MJPEG
H.264 Type
Baseline Profile/Main Profile/High Profile
H.264+
Main stream support
H.265 Type
Main Profile
H.265+
Main stream support
