Data Sheet

Web Browser
Plug-in required live view: IE8+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+
Local service: Chrome57.0+，Firefox52.0+
Interface
Communication Interface
1 RJ45 10M/100M/1000M self-adaptive Ethernet port
Alarm
2 inputs, 2 outputs (max. 24 VDC, 1A)
Video Out
1Vp-p composite output (75 Ω/CVBS), only for adjustment
On-board storage
Built-in micro SD/SDHC/SDXC slot, up to 256 GB
General
Firmware Version
5.6.0
Web Client Language
32 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,
French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian,
Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai,
Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Embedded Open Platform
Yes. The camera supports installation and running up to 4 extra applications.
General Function
Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy masks,
flash log, password reset via e-mail, pixel counter, HTTP listening
Reset
Reset via reset button on camera body, web browser and client software
Startup and Operating
Conditions
-30 °C to 65 °C (-22 °F to 149 °F), -H: -40 °C to 65 °C (-40 °F to 149 °F)
Humidity 95% or less (non-condensing)
Storage Conditions
-30 °C to 65 °C (-22 °F to 149 °F)
Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 20%, three-core terminal block; reverse polarity protection, PoE (802.3at,
type 2, class 4)
Power Consumption and Current
-IZS: 12 VDC, 1.08 A, Max: 13.0W; PoE: (802.3at, 42.5 V to 57 V), 0.31 A to 0.23 A, Max:
13.0W, class 4
-IZHS: 12 VDC, 1.13 A, Max: 13.5W; PoE: (802.3at, 42.5 V to 57 V), 0.42 A to 0.32 A,
Max: 18.0W, class 4
Heater
-H: yes
Material
Metal
Dimensions
Camera: Φ140 × 351 mm (Φ5.5" × 13.8")
With package: 405 × 190 × 180 mm (15.9" × 7.5" × 7.1")
Weight
Camera: approx. 2.20 kg (4.80 lb.)
With package: approx. 2.70 kg (5.95 lb.)
Approval
EMC
47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013,
EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32:
2015, KN 35: 2015
Safety
UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am
1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
Chemistry
2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
