DS-2CD5A46G1-IZ(H)S

4 MP IR Varifocal Bullet Network Camera

● 1/1.8” Progressive Scan CMOS

● 2560 × 1440 @ 30fps

● MJPEG up to 1920 × 1080 @ 30fps

● 2.8 to 12 mm/8 to 32 mm motorized lens

● Color: 0.002 Lux @ (F1.2, AGC ON), 0.005 Lux @ (F1.8,

AGC ON), 0 Lux with IR

● H.265, H.265+, H.264, H.264+

● 140dB WDR

● 2.8 to 12 mm lens: IR range up to 50 m, 8 to 32 mm lens:

IR range up to 100 m

● Alarm 2 inputs/2 outputs, audio 1 input/1 output,

RS-485

● IP67, IK10

● 5 streams and up to 5 custom streams

● 6 behavior analyses, 2 exception detections, and face

detection

● Built-in microSD/SDHC/SDXC card slot, up to 256 GB

● Metadata of intrusion detection, line crossing detection,

region entrance detection, region exiting detection,

unattended baggage detection, and object removal are

supported.

Summary of content (8 pages)

PAGE 1
DS-2CD5A46G1-IZ(H)S 4 MP IR Varifocal Bullet Network Camera ● 1/1.8” Progressive Scan CMOS ● IP67, IK10 ● 2560 × 1440 @ 30fps ● 5 streams and up to 5 custom streams ● MJPEG up to 1920 × 1080 @ 30fps ● 6 behavior analyses, 2 exception detections, and face ● 2.8 to 12 mm/8 to 32 mm motorized lens ● Color: 0.002 Lux @ (F1.2, AGC ON), 0.005 Lux @ (F1.
PAGE 2
Function Smooth Streaming Smooth streaming offers solutions to improve the video quality in different network conditions.
PAGE 3
Specifications Camera Image Sensor 1/1.8ʺ Progressive Scan CMOS Min. Illumination Color: 0.002 Lux @ (F1.2, AGC ON), 0.005 Lux @ (F1.8, AGC ON), 0 Lux with IR Shutter Speed 1 s to 1/100,000 s Slow Shutter Yes Day & Night IR cut filter WDR 140 dB Angle Adjustment Bracket, pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360° Lens Lens Type Aperture Motorized lens, 2.8 to 12 mm and 8 to 32 mm optional 2.8 to 12 mm: F1.2 to 2.5 8 to 32 mm: F1.8, Constant F1.
PAGE 4
H.264 Type Baseline Profile/Main Profile/High Profile H.264+ Main stream support H.265 Type Main Profile H.265+ Main stream support Video Bit Rate 32 Kbps to 16 Mbps Scalable Video Coding (SVC) H.264 and H.
PAGE 5
API ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome Smooth Streaming Yes Password protection, complicated password, HTTPS encryption, 802.1X authentication Security (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS1.0, TLS1.1 Simultaneous Live View Up to 20 channels User/Host Up to 32 users.
PAGE 6
-IZS: With extra load: 12 VDC, 1.28 A, max. 15.4 W; PoE (802.3at, 42.5 V to 57 V), 0.36 A to 0.27 A, max. 15.4 W; Without extra load: 12 VDC, 1.08 A, max. 13 W; PoE (802.3at, 42.5 V to 57 V), 0.31 A to 0.23 A, max. 13 W Power Consumption and Current -IZHS: With extra load: 12 VDC, 1.33 A, max. 15.9 W; PoE (802.3at, 42.5 V to 57 V), 0.50 A to 0.37 A, max. 21.2 W; Without extra load: 12 VDC, 1.13 A, max. 13.5 W; PoE (802.3at, 42.5 V to 57 V), 0.42 A to 0.32 A, max.
PAGE 7
Dimension Accessory DS-1475ZJ-SUS Vertical Pole Mount DS-1476ZJ-SUS Corner Mount
