Data Sheet

Key Features

 2.0 megapixel high-performance CMOS

 HD analog output, up to 1080p resolution

 2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed focal lens

 True Day/Night

 EXIR 2.0, smart IR, up to 40 m IR distance

 IP66

 PoC.af

 Up the coax (HIKVISION-C)

DS-2CE16D0T-IT3E

HD 1080p PoC Bullet Camera

PAGE 1
DS-2CE16D0T-IT3E HD 1080p PoC Bullet Camera Key Features  2.0 megapixel high-performance CMOS  HD analog output, up to 1080p resolution  2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed focal lens  True Day/Night  EXIR 2.0, smart IR, up to 40 m IR distance  IP66  PoC.
PAGE 2
Specification Camera Image Sensor 2.0 megapixel progressive scan CMOS Signal System PAL/NTSC PAL: 1080p@25fps NTSC: 1080p@30fps Frame Rate Resolution 1920 (H) × 1080 (V) Min. illumination 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s Shutter Time Lens 2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed lens Horizontal Field of View 103.55° (2.8 mm), 82.63° (3.6 mm), 54.38° (6 mm), 37.96° (8 mm), 24.
PAGE 3
Order Model DS-2CE16D0T-IT3E Dimension 226 mm (8.9") 81.6 mm (3.2") 86.7 mm (3.4") 3-Φ 4.2 mm (0.17") 120 ° Accessory DS-1280ZJ-XS Junction Box 0° 12 DS-1H18 Video Balun 020000181219 Φ 55 mm (2.
