Hikvision DS-2DF8225IX-AEL(W) 2MP 25× Network IR

Speed Dome adopts 1/1.8" progressive scan CMOS chip.

With the 25× optical zoom lens, the camera offers more

details over expansive areas.

This series of cameras can be widely used for wide

ranges of high-definition, such as the rivers, forests,

roads, railways, airports, ports, squares, parks, scenic

spots, stations and large venues, etc.

Key Features

 1/1.8" progressive scan CMOS

 Up to 1920 × 1080 resolution

 Min. Illumination

Color: 0.002 Lux @(F1.5, AGC ON)

B/W: 0.0002 Lux @(F1.5, AGC ON)

0 Lux with IR

 25× optical zoom, 16× digital zoom

 120dB WDR, 3D DNR, HLC, Smart IR

 24 VAC & Hi-PoE

 Up to 200 m IR distance

 Support H.265+/H.265 video compression

 Support rapid focus

 Deep-learning-based target classification

algorithm for auto-tracking 2.0 and perimeter

protection

 IP67, IK10

DS-2DF8225IX-AEL(W) (B)

2MP 25× Network IR Speed Dome

Summary of content (5 pages)

PAGE 1
DS-2DF8225IX-AEL(W) (B) 2MP 25× Network IR Speed Dome Hikvision DS-2DF8225IX-AEL(W) 2MP 25× Network IR Key Features Speed Dome adopts 1/1.8" progressive scan CMOS chip.    With the 25× optical zoom lens, the camera offers more details over expansive areas. 1/1.8" progressive scan CMOS Up to 1920 × 1080 resolution This series of cameras can be widely used for wide Min. Illumination Color: 0.002 Lux @(F1.5, AGC ON) ranges of high-definition, such as the rivers, forests, B/W: 0.0002 Lux @(F1.
PAGE 2
Specification Camera Module Image Sensor Min. Illumination Shutter Time White Balance AGC Day & Night Digital Zoom Privacy Mask Focus Mode 3D DNR BLC HLC WDR Optical Defog EIS Regional Exposure Regional Focus Rapid Focus Lens Focal Length Zoom Speed Field of View Working Distance Aperture Range PTZ Movement Range (Pan) Pan Speed Movement Range (Tilt) Tilt Speed Proportional Zoom Presets Patrol Scan Pattern Scan Power-off Memory: Park Action PTZ Status Display Preset Freezing Scheduled Task 1/1.
PAGE 3
Smart Record ROI IR IR Distance Smart IR Network Max.
PAGE 4
Weight Approx. 8 kg (17.64 lb) DORI The DORI (detect, observe, recognize, identify) distance gives the general idea of the camera ability to distinguish persons or objects within its field of view. It is calculated based on the camera sensor specification and the criteria given by EN 62676-4: 2015. DORI Detect Observe Recognize Identify Definition 25 px/m 63 px/m 125 px/m 250 px/m Distance (Tele) 1493.3 m (4899.4 ft) 592.6 m (1944.2 ft) 298.7 m (979.9 ft) 149.3 m (489.
PAGE 5
Accessory Included: Installation Adapter Optional: DS-1604ZJ Wall Mount DS-1604ZJ-box DS-1604ZJ-box-pole DS-1604ZJ-box-corner Wall Mount with Junction Vertical Pole Mount with Corner Mount with Box Junction Box Junction Box DS-1660ZJ DS-1619ZJ DS-1661ZJ DS-1662ZJ Parapet Mount Gooseneck Mount Pendant Mount Pendant Mount DS-1663ZJ Ceiling Mount DS-1667ZJ Extendable Pole for Pendant Mount DS-1673ZJ Horizontal Pole Mount DS-1682ZJ Extendable Pole for Pendant Mount TEAC-66-243000V (EU) L
