Data Sheet

Key Feature

 Up to 8/16-ch IP camera inputs

 H.265+/H.265/H.264+/H.264 video formats

 Up to 1-ch@8 MP/5-ch@1080p decoding capacity

 Up to 80/160 Mbps incoming bandwidth

Professional and Reliability

 H.265+ compression effectively reduces the storage space by up to 75%

HD Video Output

 Provide simultaneous HDMI and VGA outputs

 HDMI video output at up to 4K resolution

Storage and Playback

 2 SATA interfaces for HDD connection (up to 8 TB capacity per HDD)

 Smart search/smart playback to improve the playback efficiency

Smart Function

 Support multiple VCA (Video Content Analytics) events

 Configurable special camera smart functions, such as VCA detection (motion, line crossing, intrusion, etc.), heat map, ANPR, and

people counting

Network & Ethernet Access

 1 self-adaptive 10/100/1000 Mbps Ethernet interface for DS-7616NI-Q2

 Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management

DS-7600NI-Q2 Series NVR

PAGE 1
DS-7600NI-Q2 Series NVR Key Feature  Up to 8/16-ch IP camera inputs  H.265+/H.265/H.264+/H.264 video formats  Up to 1-ch@8 MP/5-ch@1080p decoding capacity  Up to 80/160 Mbps incoming bandwidth Professional and Reliability  H.
PAGE 2
Specification Model DS-7608NI-Q2 DS-7616NI-Q2 8-ch 16-ch Video and Audio IP video input Up to 8 MP resolution Incoming bandwidth 80 Mbps Outgoing bandwidth 80 Mbps HDMI output 160 Mbps 1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz VGA output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz Video output mode HDMI/VGA simultaneous output CVBS output N/A Audio output 1-ch,
PAGE 3
Dimension
PAGE 4
Physical Interface No. Description No.
