Data Sheet

Specification
Model
DS-7608NI-Q2
DS-7616NI-Q2
Video and Audio
IP video input
8-ch
16-ch
Up to 8 MP resolution
Incoming bandwidth
80 Mbps
160 Mbps
Outgoing bandwidth
80 Mbps
HDMI output
1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz,
1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
VGA output
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video output mode
HDMI/VGA simultaneous output
CVBS output
N/A
Audio output
1-ch, RCA (Linear, 1 KΩ)
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding
Decoding format
H.265+/H.265/H.264+/H.264
Recording resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback
8-ch
16-ch
Capability
1-ch@8 MP (30 fps)/5-ch@1080p (30 fps)
Stream type
Video, Video & Audio
Audio compression
G.711ulaw/G.711alaw/G.722/G.726
Network
Remote connection
64
Network protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI,
ISUP, UPnP™, HTTP, HTTPS
Network interface
1, RJ-45 10/100 Mbps self-adaptive
Ethernet interface
1, RJ-45 10/100/1000 Mbps self-adaptive
Ethernet interface
Auxiliary Interface
SATA
2 SATA interfaces
Capacity
Up to 8 TB capacity for each disk
USB interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
General
Power supply
12 VDC, 3.33 A
Consumption (without HDD)
≤ 15 W
Working temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working humidity
10% to 90%
Dimension (W × D × H)
385 × 315 × 52 mm (15.2"× 12.4" × 2.0")
Weight (without HDD)
≤ 1.8 kg (4.0 lb)
Certification
FCC
Part 15 Subpart B, ANSI C63.4-2014
CE
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
